Actuator with IC Advanced - with BusLink
I/O specifications:
Input/Output
Description
Brown
Blue
Red
Black
Green
Yellow
Specification
Easy to use interface with integrated
power electronics (H-bridge).
The actuator can also be equipped with
electronic circuit that gives an absolute or
relative feedback signal.
IC Advanced provides a wide range of pos-
sibilities for customisation.
The version with "IC option" cannot be
operated with PWM (power supply).
See connection diagram,
fig. 10, page 30
12-24VDC + (VCC)
Connect Brown to positive
12V ± 20%
24V ± 10%
12V, current limit 15A
24V, current limit 10A
12-24VDC - (GND)
Connect Blue to negative
12V ± 20%
24V ± 10%
Extends the actuator
Retracts the actuator
Endstop signal out
Endstop signal in (Option 1)
Constantly high (Option 2)
Comments
Note: Do not change the power supply
polarity on the brown and blue wires!
Power supply GND (-) is electrically
connected to the housing
Current limit levels can be adjusted
through BusLink
If the temperature drops below 0°C,
all current limits will automatically
increase to:
On/off voltages:
> 67% of V
< 33% of V
Input current ≈ 10mA
Output voltage min. V
Source current max. 100mA
Endstop signals are NOT potential free.
Endstop signals can be configured with
BusLink software according to any
position needed
When configuring virtual endstop, it is
not necessary to choose the position
feedback
EOS and virtual endstop will work even
when feedback is not chosen
Page 30 of 76
M
H-Bridge
20A for 12V
15A for 24V
= ON
IN
= OFF
IN
- 2V
IN
