Dimensions and weights
KITE CR
Size ØA
125 125
160 160
200 200
250 250
315 315
Size of the opening = 520 x 520
KITE CR with ALS - One step
Size A B
125-600 595 282
160-600 595 342
200-600 595 404
250-600 595 504
315-600 595 622
KITE CR with ALS - Two steps
Size A B
160-600 595 342
200-600 595 404
250-600 595 504
315-600 595 622
CL = Centreline
Figure 6. KITE Ceiling with ALS.
SAR K frame
Size
600
Weight, kg
3.3
3.3
3.2
3.2
3.1
C ØD Ød E1
217 99 125 225
252 124 160 249
288 159 200 284
332 199 250 324
388 249 315 385
C ØD Ød E1
252 99 160 225
288 124 200 249
332 159 250 284
388 199 315 324
L Weight, kg
595 1
14/07/2020
Figure 5. KITE Ceiling.
E2 F1 F2 G1
182 83 40 145
206 83 40 158
241 83 40 175
281 83 40 195
342 83 40 220
E2 F1 F2 G1
182 83 40 145
206 83 40 158
241 83 40 175
281 83 40 195
Figure 7. KITE Ceiling with ALS. Low installation height.
Figure 8. Frame SAR K.
Swegon reserves the right to alter specifications.
KITE Ceiling
ØA
G2 H K Weight, kg
102 270 80 5.2
115 315 80 5.9
132 375 100 6.8
152 465 115 8.2
177 575 140 10.9
G2 H K Weight, kg
102 315 80 5.5
115 355 80 6.2
132 450 100 7.4
152 550 115 9.7
3
