About This Manual
How to Use This Manual
Related Documentation From Texas Instruments
This user's guide describes the EVM used to evaluate ten different serial
analog-to-digital converters. These converters are the TLC4541/5,
TLC3541/5, TLC2551/2/5, and TLV2541/2/5; 16-bit, 14-bit, 12-bit, and 12-bit
devices respectfully. A complete circuit description as well as a schematic and
bill of materials are included.
This document contains the following chapters:
Chapter 1 - EVM Overview
Chaper 2 - Layout
Chapter 3 - EVM Bill of Materials and EVM Schematic
To obtain a copy of any of the following TI documents, call the Texas
Instruments Literature Response Center at (800) 477 - 8924 or the Product
Information Center (PIC) at
this booklet by its title and literature number. Updated documents can also be
obtained through our website at WWW.TI.COM.
Data Sheets
TLV2541/2/5
TLC2551/2/5
TLC3541/5
TLC4541/5
OPA132
REF102
SN74HC1G125DBV
Related Documentation From Texas Instruments
Read This First
(972) 644- 5580.
When ordering, please identify
Literature Numbers
SLAS245
SLAS276
SLAS345
SLAS293
SBOS054
SBVS003
SCLS377
