Poly Studio Feature Descriptions
Reference Feature
1 Camera
2 Microphone array
3 LED light indicators
4 Speakers
5 Privacy shutter lever
6 Remote control pairing
7 Reset

Basic Poly Studio LED Indicators

The Poly Studio USB video bar provides an LED light bar above the camera to help you understand the
system's behaviors.
Basic Poly Studio LED Indicators and Status
Indicator
Chasing white
Blinking blue
Solid blue for three seconds
Solid amber
Blinking green or white
Solid green or amber
Solid green or white
Solid white for three seconds
Solid red
Feature Description
Camera with a privacy shutter that enables or
disables the video input as you choose
Stereo microphone that captures audio
Indicate the status and the tracked speaker
Stereo audio output
Covers or uncovers the camera lens
Enables the Bluetooth remote control pairing mode
Resets the Poly Studio USB video bar to the factory
software version or clears all saved configurations
Position
All while alternating
Two in the middle
Two in the middle
Two in the middle
All
Two in the middle
One or two (when in the middle),
indicating the tracked speaker or
the direction of the camera
Two in the middle
All
Getting Started
Status
Boot initialization in progress
Bluetooth in discovery
Bluetooth paired
Eight in the middle
Incoming call
Outgoing call
Four to eight (when in the middle),
indicating the tracked speaker or
the direction of the camera
Twelve in the middle
Muted microphone
