  • Page 1 PIKO SmartControl – light die digitale Zukunft der Modellbahn steuerung! Modellbahn steuerung! Modellbahn steuerung! BEDIENUNGSANLEITUNG INSTRUCTION MANUAL...
  • Page 2 PIKO SmartControl light Questi possono essere trovati su www.piko-shop.de/?a=scl Attentie: Naast deze handleiding bestaat er een uitgebreide gebruiksaanwijzing, waarin uitvoerig uitleg wordt gegeven over de vele mogelijkheden die het PIKO PIKO SmartControl systeem biedt. Deze light kunnen u vinden onder www.piko-shop.de/?a=scl Uwaga: Oprócz niniejszej instrukcji obsługi istnieje również...
  • Page 3 PIKO SmartControl System light Bedienungsanleitung...
  • Page 4: Table Of Contents

    Inhalt Eigenschaften .......................... 5 Anschlüsse ..........................6 PIKO SmartControl in Betrieb nehmen ................6 light Die Bedienelemente des PIKO SmartController ............... 7 light Die Bedienung des PIKO SmartController ................ 8 light 3.1. Start ............................8 3.2. Eine neue Lokomotive anlegen ....................9 3.3.
  • Page 5: Eigenschaften

    Der PIKO SmartController ist ein intelligenter Handregler für das PIKO SmartControl System light light und kann über den PIKO Lok-Netz Converter #55044 auch als zusätzlicher, kabelgebundener Handregler für das PIKO SmartControl System oder andere Digitalzentralen über LocoNet ® eingesetzt werden.
  • Page 6: Anschlüsse

    Gleis schw. schw. rot grün 15V- Netzteil Nun schalten Sie die Betriebsspannung ein, indem Sie das Steckernetzteil in eine Steckdose stecken. Eine schaltbare Steckdosenleiste ist hier von Vorteil. Die grüne Kontroll-LED leuchtet und im PIKO SmartController erscheint der Lokmodus. light...
  • Page 7: Die Bedienelemente Des Piko Smartcontroller

    2. Die Bedienelemente des PIKO SmartController light Übersicht der Bedienelemente Display Fahrregler mode down Ziffernblock stop / löschen Enter Display Hochauflösendes Display mit Informationen zum momentanen Gerätemodus und der Lok- oder Basisadresse. Im mittleren Bereich stehen die Grundinformationen zur jeweils gesteuerten Lok und im unteren Bereich, je nach gewähltem Modus, die Schaltfunktionen.
  • Page 8: Die Bedienung Des Piko Smartcontroller

    Sie nun im Sinne eines echten Plug-and-Play Aufbaus sofort mit dem Betrieb auf Ihrer Modellbahn starten, da werkseitig die Triebfahrzeuge des Start-Sets schon in den PIKO SmartController eingepflegt sind. light Adressen der Fahrzeuge aus den PIKO SmartControl Start-Sets light Triebfahrzeug Adresse...
  • Page 9: Eine Neue Lokomotive Anlegen

    Haben Sie ein PIKO SmartControl Basis Set erworben oder möchten Sie eine digitalisierte light Lokomotive steuern, die nicht im Umfang eines PIKO SmartControl Start-Sets enthalten ist, so light müssen Sie diese Lokomotive zunächst im PIKO SmartController in der Lokdatenbank anlegen.
  • Page 10 Loksymbol ausgewählt. Dieses Symbol muss über die [↩] – Taste bestätigt werden. Über das Untermenü [3] „LOKNAME“ kann jeder Lokadresse ein individueller Lokname (in unserem Beispiel „PIKO ICE Test“) zugeordnet werden. Die Position des Eingabecursors für das erste Zeichen wird durch Drehen des Fahrreglers ausgewählt. Anschließend wird der Drehregler gedrückt. Jetzt kann das erste Zeichen durch Drehen des Fahrreglers ausgewählt werden.
  • Page 11: Cvs Programmieren

    light Tastfunktion: Wird die Taste betätigt und festgehalten, so ist die Funktion eingeschaltet. Mit Loslassen der Taste wird die Funktion ausgeschaltet. Mit der [▲] - oder [▼] - Taste kann eine der beiden Möglichkeiten ausgewählt und mit der [↩] - Taste bestätigt werden.
  • Page 12: Magnetartikel Schalten

    Nummer der jeweiligen Weichenliste (1 - 4). Wie Sie Weichen eine entsprechende Adresse zuordnen können, entnehmen Sie bitte der Bedienungsanleitung des Weichendecoders. Alle Einstellungen, die beim PIKO SmartController einmal gemacht werden, bleiben dauerhaft light erhalten, auch wenn das Gerät länger nicht eingeschaltet wird.
  • Page 13: Anzeige Betriebszustände

    • max. Belastung LocoNet -T: 500 mA ® • Gehäusemaße: 104 x 58 x 33 mm b. PIKO SmartController light • Hochauflösendes Display • Das hochauflösende Display hat eine Größe von 38 x 20 mm und ermöglicht eine detaillierte Darstellung im Klartext oder als Symbol.
  • Page 14: Sicherheitshinweise

    IV. FAQs An dieser Stelle möchten wir auf unsere FAQ Infoseite im Internet verweisen. Sie finden diese im PIKO Webshop unter www.piko-shop.de/?a=faq. Dort finden Sie immer die aktuellsten Informationen zum Umgang mit dem PIKO SmartControl System. Sollten Sie einmal nicht weiterkommen finden light Sie am Ende dieser Webseite auch ein Kontaktformular.
  • Page 15: Technische Hotline

    V. Technische Hotline Für technische Fragen zu PIKO Produkten erreichen Sie unsere technische Hotline Dienstags von 16 bis 18 Uhr Donnerstags von 16 bis 18 Uhr unter 03675 / 8972 - 42. Sie können uns aber auch ein Fax unter der Nummer 03675 / 8972 - 50 schicken oder schreiben Sie uns eine E-Mail an hotline@piko.de!
  • Page 16 System light PIKO SmartControl System light Instruction Manual...
  • Page 17 Products, specifications and availability subject to change. Duplications and reproductions of this documentation are strictly forbidden and need to be allowed by PIKO in writing. LocoNet is a registered trademark of Digitrax Inc., Panama City FL, USA...
  • Page 18: Features

    PIKO SmartControl system. light light By using a PIKO #55044 Loco-Net converter it can also be used as an additional corded hand controller for the PIKO SmartControl system or other digital central stations with LocoNet ® Features •...
  • Page 19: Ports

    Next, turn on the operating voltage by plugging the power supply into the power outlet. A switchable multi-socket outlet can be beneficial. The green control LED should now be turned on and the PIKO SmartController should display the light...
  • Page 20: The Control Elements Of The Piko Smartcontroller

    System light 2. The control elements of the PIKO SmartController light Overview display speed regulator mode down keypad stop / delete Enter Display The clearly structured high definition display shows the symbol of the current operating mode and the locomotive or base address at the top of the display. In the middle it shows basic information about the currently controlled locomotive.
  • Page 21: Operating The Piko Smartcontroller

    All locomotives of the starter-sets are already included in the database of the PIKO SmartController light Addresses of the trains included in the PIKO SmartControl starter sets light train...
  • Page 22: Save A New Loco

    PIKO SmartController light 3.2. Save a new loco You can save your own loco datasets in the loco database of the PIKO SmartController . Here you light can assign loco symbols, addresses, names and symbols for special functions. You can choose from over 60 loco symbols and over 160 symbols for special functions.
  • Page 23 / down ([▲] / [▼] keys to select a suiting loco symbol. Confirm the symbol by pressing [↩]. By pressing [3] you can change the loco name (in our example “PIKO ICE TEST” in the sub-menu “LOCONAME”. The position of the cursor can be changed by turning the throttle knob. Then, please press down the throttle knob.
  • Page 24: Program Cvs

    System light Pusher function (momentary): If you press the key and hold it, the function is turned on. By letting go of the key, the function turns off. With the [▲] and [▼] keys you can choose between one of the two possibilities and confirm it with the [↩] key.
  • Page 25: Switch Magnetic Accessories

    The address field displays the currently used turnout list (1-4). To learn how to assign addresses to turnouts, please consider the instruction manual of your turnout decoder. All configurations made for the PIKO SmartController once, are permanently saved on the device, light...
  • Page 26: Display Operating Status

    • Dimensions: 180 x 80 x 35 mm III. Safety warnings • Please read the safety warnings and this instruction manual before using the devices. • Always treat your PIKO SmartControl devices with care! The devices contain sensitive light electronics; therefore, you should avoid exposing them to harsh impacts, moisture and extreme temperatures.
  • Page 27: Faq

    • Keep this instruction manual in a safe place. IV. FAQ If you have any questions, please visit our FAQ website. You can find it on the PIKO web shop under www.piko-shop.de/?a=faq. There, we provide you with the newest information about the PIKO SmartControl system.
  • Page 28 PIKO Modellbahnen – für jede Anlage! PIKO model trains – for every layout! PIKO Spielwaren GmbH Lutherstr. 30 96515 Sonneberg, GERMANY www.piko.de · hotline@piko.de...
