Belastungsdiagramm der
Rundschalteinheit RSE-K-9-...
Legende
m
Masse
r
Radius
Belastungsart
Flächenlast
Belastungsart
Ringlast
Massenträgheitsmoment
Pneumatische Endlagendämp-
fung:
Hydraulische Endlagendämp-
fung:
80
70
60
50
40
30
20
10
0
100
150
0,2734 kgm²
1,1 kgm²
Betriebsanleitung Rundschalteinheiten
Rundschalteinheiten RSE-K-6 und RSE-K-9
Load diagram of the RSE-K-9-... rotary
unit
r [mm]
200
250
Legend
m
Mass
r
Radius
Load type
Surface load
- - - - -
mit hydraulischer Endlagen-
dämpfung / with hydraulic
limit position damper
______
mit pneumatischer Endlagen-
dämpfung / with pneumatic
limit position damper
Load type
Closed loop load
..........
mit hydraulischer Endlagen-
dämpfung / with hydraulic
limit position damper
- -- - --
mit pneumatischer Endlagen-
dämpfung / with pneumatic
limit position damper
Moment of inertia
Pneumatic limit positi-
on damper:
Hydraulic limit position
damper:
0,2734 kgm²
1,1 kgm²
www.mader.eu
1
1
2
2
3
3
4
4
5
5
5
6
7
8
60
