- Page 1 User Manual Gas Detector Alpa EcoTerm XT Product code: PW-100-NG POD-044-ENG R01...
- Page 2 We design, manufacture, implement and support: Systems for Monitoring, Detection and Reduction of gas hazards We invite you to familiarize yourself with our offer on www.atestgaz.pl Atest Gaz A. M. Pachole sp. j. ul. Spokojna 3, 44-109 Gliwice Poland tel.: +48 32 238 87 94 fax: +48 32 234 92 71 e-mail: contact@atestgaz.pl...
- Page 3 www.atestgaz.pl Remarks and reservations Read and understand this manual prior to connection and operation of the device. Keep the User Manual with the device for future reference. The manufacturer shall not be held responsible for any errors, damage or defects caused by improper selection of suitable devices or cables, errors in installation of equipment or any misuse due to failure to understand the document content.
-
Page 4: Table Of Contents
12 List of accessories..........................26 13 Product marking..........................26 14 Appendices............................26 List of Tables Table 1: Priorities of the Alpa EcoTerm XT Gas Detector................7 Table 2: Electric interface description......................10 Table 3: Indication of operating conditions....................12 Table 4: Signalling archive status (SW3 in position 1).................12 Table 5: Signalling archive status (SW3 in position 2).................12... - Page 5 www.atestgaz.pl List of Figures Figure 1: The construction of the device and its dimensions..............10 Figure 2: Connection with the Alpa MOD LED8 control unit into a star-shaped system......13 Figure 3: Connection with the Alpa MOD LED1 control unit into an open bus system.......13 Figure 4: Connection with the Alpa MOD LED1 control unit into a closed bus system.......13 Figure 5: Connecting into two open bus systems servicing two zones............14 Figure 6: Settings of the configuration switch....................15...
-
Page 6: Preliminary Information
Description of operation The Alpa EcoTerm XT Gas Detector is one of the elements of the gas detection system. It performs cyclical measurements of gas concentration in the air. Information about exceeding a certain threshold is transmitted using the controls located on the bottom side part of the housing (see figure 1) and output current signal. -
Page 7: Table 1: Priorities Of The Alpa Ecoterm Xt Gas Detector
5 (lowest) Correct operation of the detector Warm-up Table 1: Priorities of the Alpa EcoTerm XT Gas Detector The type of gas, the thresholds and the corresponding current value for a specific detector should be checked in the calibration certificate. -
Page 8: Safety
www.atestgaz.pl 1.2.3 Alarm (threshold 3) This state occurs when the gas concentration exceeds the alarm threshold (3rd threshold). Actions to be taken: remove bystanders from the danger zone, as far as possible, allow the airing of the endangered rooms – by opening windows and doors (if the control unit does not automatically switch on the ventilation). - Page 9 www.atestgaz.pl Although switching power supply of the Gas Detection System off, there is a possibility that a dangerous voltage can exist on the terminals of the Control Unit. It can originate from another system like for an example ventilation system that uses one of the output pins of Control Unit.
-
Page 10: Description Of The Construction
www.atestgaz.pl Description of the construction „TEST” button Configuration switch Mounting holes Light intensity Configuration switch switch Securing screw control Measuring Head Figure 1: The construction of the device and its dimensions Input-output interfaces Electric interfaces The appearance of the terminal strip is shown in Figure 1. Oznaczenie portu Nazwa Zacisk... - Page 11 www.atestgaz.pl The indicator lamps presents: current status of the detector, stored (historical) events affecting status of the detector, i.e. warning and/or alarms reported by the detector as well as detector failures. The detector also makes it possible to adjust intensity of LED indicator light designed to present correct operation of the detector (see details in Section 7.2).
-
Page 12: System Architectures
www.atestgaz.pl Status of indicator LEDs Status of the Status of Meaning detector interconnections operation check Failure Failure Detector damage The detector also indicates an interruption of electric interconnections or incorrect values of electric current (see details is Section 8) Table 3: Indication of operating conditions When the detector works properly it is possible to view historical events associated with exceeding of warning /alarm thresholds or detector failures. -
Page 13: Star System
www.atestgaz.pl Star system In the conventional system each detector is individually connected to the control unit. This solution requires the input of a large number of wires to the control unit, which can be a serious impediment to the assembly –... -
Page 14: Device Configuration
www.atestgaz.pl Bus 2 Bus 1 Alpa MOD LED8 Alpa Alpa Alpa Alpa EcoTerm XT EcoTerm XT EcoTerm XT EcoTerm XT Figure 5: Connecting into two open bus systems servicing two zones Device configuration Detector location For correct operation of the system, it is necessary to configure the detectors by appropriately setting the configuration switch SW2 located in the detector (see Figure 1, 6). -
Page 15: Adjustment Of The Led Indicator Intensity
www.atestgaz.pl Next detectors or control unit Intermediate Last detector detector Figure 6: Settings of the configuration switch Adjustment of the LED indicator intensity Depending on a facility where the detectors are installed it is possible to adjust intensity of light indications emitted by the detector. -
Page 16: Life Cycle
www.atestgaz.pl Indicator Additional conditions Possible cause of the problem Indications The detector works as Damaged XT T-shaped connector or inappropriate connection in the according an intermediate one places indicated in the figure: sequence provided Possible improper connection in Table 3 (status of the interconnections check –... -
Page 17: Set-Up
www.atestgaz.pl Set-up 9.2.1 Location of detectors The location of detectors should be determined by the designer of the system, taking into consideration the following principles: methane detectors should be installed less than 30 cm below the topmost point of the facility roof. -
Page 18: Figure 7: Example Connection Of Cables To The Device
www.atestgaz.pl The detector should be mounted with the use of Ø6 rawl bolts or M5 screws using the mounting holes accessible after the housing is open, so that the gas inlet is directed downwards. The housing dimensions, mounting hole spacing and the arrangement of the elements are shown in the figure 1. -
Page 19: Figure 8: Connection Into The Star System
www.atestgaz.pl 9.2.2.1 Star system Control Unit - - - - - Unused terminal S2 Figure 8: Connection into the star system The configuration switch is always set in position 2 (last detector). For details, see section 7. Distribute connection cables in the facility, leaving appropriate reserve for connecting the detectors. -
Page 20: Figure 9: Open Bus System
www.atestgaz.pl Turn on the power supply when connecting all the detectors to the control unit. "WORK" should be indicated on all the channels of the control unit. Measure the power supply voltage on the sensor furthest from the control unit while pressing "TEST". It should not be less than 10 V. 9.2.2.2 Open alarm loop Control Unit... -
Page 21: Figure 10: Closed Alarm Loop
www.atestgaz.pl detector, and the control unit should signal the failure of the detector (no detector at the end of the loop). Turn off the power supply. Repeat these steps for the next T-connectors and detectors. In the detectors, set the configuration switch in position 1. In the last detector, set the configuration switch in position 2 (see Figure 6). -
Page 22: Start-Up
www.atestgaz.pl Start-up 9.3.1 Handover inspection After performing the power supply and signal installation of the detectors, it is necessary to check and start the installation. Checking is based on further addition of detectors (or their simulator – see below) to the installation and checking the reaction of the control unit. -
Page 23: Periodical Operations
(calibration frequency is specified in the Calibration Certificate – see Table 8). These services should be carried out for the Alpa EcoTerm XT Gas Detectors by a competent service company authorized by the manufacturer. The calibration can be carried out in several ways:... -
Page 24: Utilization
www.atestgaz.pl fasten the locking screw, switch on the power voltage for the detector. 9.4.3 Periodical inspections It is recommended to conduct periodical inspections every 3 months. Within the scope of a periodical inspections, it is necessary to conduct the visual inspection of the external installations and system devices, as well as to conduct the detector operation test: press and hold the "TEST"... -
Page 25: Technical Specification
www.atestgaz.pl Technical specification Power supply • V 10 – 42 V • 160 mA Environment In-operation Storage • Ambient temperatures -20 – 50 -20 – 50 • Humidity 10 – 90% long term 20 – 80% long term 0 – 99% short term •... -
Page 26: List Of Consumables
DEZG116-ENG – EC Declaration of Conformity – Alpa EcoTerm XT PU-Z-054-ENG – Parameters of gas setectors with catalytic sensor PU-Z-106-ENG – Maximum quantity of Alpa EcoTerm XT detectors by cable type PU-Z-039-ENG – Classification of chemicals used at Atest Gaz When working in residential buildings, public utilities, car parks and garages s. - Page 27 EU Declaration of Conformity Atest Gaz A. M. Pachole sp. j. declares with full responsibility, that the product: (Product description) (Trade name) (Type identifier or Product code) Gas Detector Alpa EcoTerm XT PW-100 complies with the following Directives and Standards: in relation to Directive 2014/30/EU –...
-
Page 28: Table Of Contents
www.atestgaz.pl Parameters of gas detectors with catalytic sensors Table of contents 1 Detected substances..........................2 2 Principle of operation..........................2 3 Impact of environmental conditions......................3 3.1 Composition of the controlled atmosphere..................3 3.1.1 Impact of the presence of a working gas or other reaction gas............3 3.1.2 Effect of oxygen concentration value....................4 3.2 Influence of temperature........................4 3.3 Influence of pressure..........................4... -
Page 29: Detected Substances
www.atestgaz.pl Detected substances Detectors equipped with catalytic sensors are used for measuring and detecting the presence of gases and flammable gases in the range of up to 100% LEL. Principle of operation The catalytic sensor (figure 1) consists of two components: an active and a passive one, heated to a high temperature. -
Page 30: Impact Of Environmental Conditions
www.atestgaz.pl Impact of environmental conditions Never exceed the rated operating parameters of the detector. These parameters can be found in the detector calibration certificate. The detector must be used in accordance with the provisions in the User's Manual. Composition of the controlled atmosphere It is assumed that the standard composition of the atmosphere is a mixture of gases with the proportions indicated in table 1. -
Page 31: Effect Of Oxygen Concentration Value
www.atestgaz.pl concentrations over 100% LEL, even temporarily persistent ones, can lead to a physical wear of the sensor. For these reasons, detectors operating in places where such conditions may occur are / should be equipped with mechanisms to prevent the negative effects of high concentrations, a very high concentration of combustible gas (well above 100% LEL) leads to a decrease in oxygen concentration –... -
Page 32: Influence Of Vibrations, Impacts
www.atestgaz.pl Influence of vibrations, impacts Vibrations and impacts affect the detector's operation, as they may cause: damage to delicate parts of the sensor (e. g. detector element, compensation element), shift of the sensor's zero. It should be ensured that the detector is not exposed to shock and vibration in excess of the amplitude of vibrations amounting to 0.15 mm of the frequencies of over 10 Hz. - Page 33 L2 [m] Quantity of detectors L1 [m] L2 [m] Quantity of detectors Table 1: Maximum quantity of Alpa EcoTerm XT detectors – open loop configuration Atest-Gaz A. M. Pachole sp. j. tel.: +48 32 238 87 94 p. 1/3 Appendix: PU-Z-106-ENG R01 ul.
- Page 34 L2 [m] Quantity of detectors L1 [m] L2 [m] Quantity of detectors Table 4: Maximum quantity Alpa EcoTerm XT detectors – closed loop configuration Atest-Gaz A. M. Pachole sp. j. tel.: +48 32 238 87 94 p. 2/3 Appendix: PU-Z-106-ENG R01 ul.
- Page 35 Cross-section of a single System with backup battery supply (U = 20 V) IN(min) cable conductor One Alpa EcoTerm XT Gas Detector at the end of the line L2 [m] 1400 1400 1400 Table 7: Maximum length of cables – star configuration Atest-Gaz A.
- Page 36 www.atestgaz.pl Classification of chemicals used at Atest-Gaz Because of the need to present a consistent and high level of maintenance services, to ensure the safety of the calibration process and to create a basis for a rational calculation of the costs of this process, Atest-Gaz developed the "Classification of Chemical Substances"...
- Page 37 www.atestgaz.pl Category Description Terms of facility calibration No precipitations, no strong winds, Cylinder gases, temperature over – 10 C¹. stable environment In other cases, calibration at a location that meets the above conditions (necessary to remove the detectors). No precipitations, no strong winds, Cylinder gases, temperature over + 10...
