SunSetter EasyShade Owner’s Manual & Installation Instruction page 12

Problem
My Motorized EasyShade
retracts but will not fully
close into the Aluminum
Housing.
Fabric is stuck inside the
Aluminum Housing
My Motorized EasyShade
rolls out and keeps going
and the Fabric Panel begins
to sag.
Can I program multiple
Motorized EasyShades to
operate on one master
Remote Transmitter?
Can I use more than one
Remote Transmitter to
control one Motorized
EasyShade?
What if I lose my Remote
Transmitter or it becomes
damaged?
Do I need to reprogram my
motor?
The Motorized EasyShade
only operates while the
UP or DOWN button is
being pressed.
TROUBLESHOOTING
Operation (continued)
Solution
Adjust the Up Limit on your EasyShade motor. See Appendix A, Adjusting the
Up and Down Position Limits of the Motor.
If the Fabric Panel has been replaced, new Up and Down Position Limits
may need to be set for the Motor. If so, see Appendix B, Programming the
EasyShade's Stop Position Settings.
In extreme cold conditions, verify the EasyShade Fabric Panel is not "frozen"
inside the housing.
A light tug on the Leading Bar in the bottom Pleat of the Fabric Panel may
overcome slight freezing conditions.
If the Motor stops on its own at a programmed Stop Position, then adjust the
Down position stop limit according to instructions in Appendix A.
If the Motor will not stop on its own and you must press the "my" button to
stop the motor, then set new Up and Down Stop Position Limits according to
instructions in Appendix B.
Yes. Each channel on the Remote Transmitter can control one or more
Motorized EasyShades.
See Appendix C, Programming Instructions - Multi Channel Remote
Transmitter.
See Appendix C, Programming Instructions - Multi Channel Remote
Transmitter, to mix and match multiple Motorized EasyShades with multiple
Multi Channel Remote Transmitters.
It is recommended to always unplug all Motorized EasyShades except the one
you are currently programming, to simplify the process.
The original Remote Transmitter shipped with your Motorized EasyShade can
be easily replaced. Please call Customer Service at 800-670-7071 to purchase a
replacement.
The Programmed Up and Down Stop Limits are permanently stored in the
Motor. These settings do not need to be reset or changed due the addition or
removal of Remote Transmitters.
Instructions for replacing the Remote Transmitter are included with the
replacement Remote Transmitter.
The Motor is in Programming Mode. Complete the Programming procedure:
1. Unplug the Motor, for 2 seconds, then plug it back in.
2. Press and Hold the UP and DOWN buttons until the Motor jogs.
3. Press and Hold the PROGRAMMING button (inside the small opening on
the rear of the Remote Transmitter) until the Motor jogs.
4. Test operation by pressing and releasing the UP or DOWN button.
If the problem persists, please call Customer Service for assistance at
800-670-7071.
