- Page 1 Valve terminal type 15 Brief description Clean design valve terminal CDVI... (type 15) with multipin connector – English 8080200 2017-12d [8080193]...
- Page 2 Translation of the original instructions Documentation on the product For all available product documentation è www.festo.com/pk Copyright: Festo SE & Co. KG Ruiter Straße 82 73734 Esslingen Germany Internet: http://www.festo.com E-Mail: service_international@festo.com Reproduction, distribution or sale of this document or communication of its contents to others without express authorization is prohibited.
- Page 3 Please note Commission only a valve terminal which has been fitted and wired completely. Please observe the instructions for connecting the “pressure compensation” in the manual P.BE-CDVI-..Festo CDVI... 2017-12d English...
- Page 4 Long signal lines reduce the immunity to interference. Do not exceed the maximum permitted signal line length of 10 m. Festo CDVI... 2017-12d English...
- Page 5 Notes on the following table: – Designation of the core colours as per DIN/IEC 757 – The multi-pin cable has 27 cores. Only 26 cores are used. The remaining core can be cut back (core colour see following table). Festo CDVI... 2017-12d English...
- Page 6 1 Bi-expansion block = 2 addresses 1 Mo-expansion block = 1 address Complete the assignment list (following table) according to the expansion blocks used on your valve terminal. Please note Maximum 8 addresses can be addressed in the exten sion. Festo CDVI... 2017-12d English...
- Page 7 Apply 0 V with positive-switching control signals; apply 24 V with negative-switching control signals. Mixed operation is not permitted. The contacts B10 and C10 are connected internally. This core is not used and can be cut back. ) Unused Festo CDVI... 2017-12d English...
- Page 8 In the case of valves with two pilot solenoids, pilot solenoid 14 occupies the lower-value address and pilot solenoid 12 occupies the higher-value address. – In the case of valves with only one pilot solenoid on Bi-blocks, the higher-value address remains unused. Festo CDVI... 2017-12d English...
- Page 9 4-group manifold block Addresses of the solenoid coils 2 Bi-expansion block Reserve location on the 2 Mo-expansion block Mo-expansion block (occupies 1 address) 1 Bi-expansion block Reserve location on the 4-group manifold block (occupies 2 addresses) Festo CDVI... 2017-12d English...
-
Page 10: Technical Specifications
2) The CDVI valve terminal is intended for industrial usage. 3) The maximum permitted signal line length is 10 m. 4) For exclusive use of Bi-blocks in the extension 5) For exclusive use of Mo-blocks in the extension Festo CDVI... 2017-12d English...
