Zoeller FM2102 Owner's Manual

NOTICE TO INSTALLER: Instructions must remain with installation.
Product information presented
here re fl ects con di tions at time
of publication. Consult factory
re gard ing dis crep an cies or
in con sis ten cies.
ZOELLER ON-SITE WASTEWATER PROD UCTS
Effl uent Turbine Submersible Pumps
Congratulations on the purchase of the Zoeller
Effl uent Turbine Submersible Pump. For over sixty years the name
Zoeller has rep re sent ed the standard for sub mers ible sump and
sew age pumps. The same high quality workmanship and easy
maintenance design has been incorporated into this line of on-site
waste wa ter products. This Zoeller system will provide years of
trou ble-free service when installed according to the manufacturer
recommendations.

Table of Contents

Safety Instructions .......................................................................... 1
Limited Warranty............................................................................. 2
Preinstallation Information .............................................................. 2
Pump Performance Data .............................................................3-4
Electrical Data ............................................................................... 5
Major Components ........................................................................ 5
Pump Installation and Wiring Diagram ........................................... 6
System Wiring Instructions ............................................................. 6
Splicing Underground Wires ........................................................... 7
Start-up and Maintenance .............................................................. 7
Troubleshooting & Service Checklist .............................................. 7
Typical Installations ....................................................................... 8
Owner's Information
Model Number: ______________________ Date Code: _________________
Job Name: ______________________________________________________
Dealer: _________________________________________________________
Date of Purchase: _______________________________________________
Contractor: _____________________________________________________
Date of Installation: _______________________________________________
System Readings During Operation: Voltage __________ Amps _________
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
(502) 778-2731 • 1 (800) 928-PUMP • FAX (502) 774-3624
OWNER'S MANUAL
and service instructions into one doc u ment to aid in the own er ship
of a Zoeller on-site wastewater product. Please read and review this
manual be fore in stall ing the product. Many items con tained within,
when fol lowed correctly, will not only ensure a long and problem-free
life for the system, but also save time and money during in stal la tion.
Should further as sis tance be nec es sary please call our Tech ni cal
Service de part ment at 1-800-928-PUMP.
TO AVOID SERIOUS OR FATAL PERSONAL INJURY OR MA JOR
PROPERTY DAMAGE, READ AND FOLLOW ALL SAFETY
INSTRUCTIONS IN MANUAL AND ON PUMP.
THIS MANUAL IS INTENDED TO ASSIST IN THE IN STAL LA TION
AND OPERATION OF THIS UNIT AND MUST BE KEPT WITH
THE PUMP.
THOROUGHLY REVIEW ALL INSTRUCTIONS AND WARNINGS
PRIOR TO PERFORMING ANY WORK ON THIS PUMP.
MAINTAIN ALL SAFETY DECALS.
© Copyright 2007 Zoeller Co. All rights reserved.
This manual in cor po rates the in stal la tion, operation, main te nance,
Safety Instructions
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the pump or in the
man u al, look for one of the following signal words
and be alert to the potential for personal injury or
property damage.
Warns of hazards that WILL cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause personal injury
or prop er ty damage.
Indicates special instructions which are very
important and must be followed.
FM2102
1207
Supersedes
visit our web site:
www.zoeller.com
020216
1107
