We wish you every success and pleasure with your new battery

charger.

Contents

Chapter

General safety notes ...........................................16

Contents ................................................................17

1.1

Recommended accessories .............................17

General description .............................................18

Specification ........................................................18

Controls ................................................................19

4.1

Function of controls ........................................19

Using the charger for the first time ..................20

5.1

Selecting the menu language ...........................20

Menu structure ....................................................21

Memory name menu ..........................................22

Data display menu ..............................................23

User settings menu .............................................24

10. Cycle data menu ..................................................24

11.

Mode select (charge/discharge/cycle) ...........24

12. Connecting a battery ..........................................26

13. Starting a charge/discharge process ..............26

14. Screen displays during a process ....................26

14.1 Screen displays during charge/discharge and

cycle processes .............................................26

14.2 Equalizer display ............................................27

15. Screen displays after a process ........................27

15.1 Text displays ..................................................27

16. Programming a BID chip or key ........................27

16.1 Starting charge/discharge processes with

BID chip/key .................................................28

16.2 Reading out the data on a BID chip ..................28

17.

USB PC socket ....................................................28

18. Error messages ...................................................28

19. Guarantee ............................................................29

20. Liability exclusion ...............................................29

21. Disposal of used equipment .............................29

22. CE conformity declaration ................................29

Operating Instructions

Power Peak E7 EQ-BID

Dear customer,

Thank you for purchasing the Power Peak

battery charger from the range - a high-performance 400 W

charging/discharging station for the demanding modeller. Two

outputs, each with 200 watts power and up to 20 A charge cur-

Page

rent in a single case. The Power charger which can recharge

your LiPo batteries on the move and at home - and very quickly.

Despite being extremely easy to use, this charger is a sophistica-

ted, high-quality unit which requires a certain level of knowledge

from the user.

rect or inappropriate manner can cause packs to explode and

catch fire.

• Never place the charger and connected batteries on an inflam-

mable surface.

• Never operate the unit in the vicinity of inflammable materials or

gases.

● Do not leave the device unattended when in use. It is normal

for the charger to become quite hot in normal operation.

• Check regularly for damage to the casing and leads.

• Take particular care when handling battery packs with a large

number of cells. Ensure good insulation to prevent the risk of

electric shock.

• The Power Peak®

discharging and equalizing rechargeable NiCd / NiMH / Lead-

acid and Lithium batteries. Never attempt to recharge dry

cells: explosion hazard.

• The charger is designed only for operation with a 10.5 - 18 V

DC source or 230 V AC power. Never operate the charger on a

different voltage.

• Protect the charger from dust, dirt and moisture.

• Do not expose the charger to excessively low or high tempera-

tures as well as direct sunlight.

• Avoid subjecting the unit to shock and pressure, and do not

expose it to severe vibration.

• Ensure the cooling vents are always clear to allow air to circu-

late freely.

• When not used for a long periods of time, unplug the charger

from the power source and disconnect any batteries.

• Do not charge rechargeable batteries twice in quick succes-

sion.

• Do not charge batteries that are at a high temperature. Allow

batteries to cool down to ambient temperature.

• Only cells of the same capacity and of the same make may be

charged together.

• Never charge two NiCd or NiMH batteries connected in parallel

to one output. Connect only one rechargeable battery pack at a

time.

Handling batteries and battery chargers in an incor-
