5. PIP Menu

These functions are available only when the input mode is PC and the PIP source is
Video or S-Video.
FUNCTION
PIP Source
PIP Size
PIP Position
H. Position
V. Position
More Options
Brightness
Contrast
Color
Tint
Sharpness
System
Selects the source for the PIP.
Enables use of the 3 / 4 key to scroll through the four alter-
natives: Off, Small, Medium, Large.
PIP-Source PIP-Pos PIP-Size
Selects a desired position for the PIP.
PIP-Source PIP-Pos PIP-Size
Adjusts the horizontal position of the PIP image.
Adjusts the vertical position of the PIP image.
Enables use of the 3 / 4 key to select more PIP functions
including Brightness, Contrast, Color, Tint, Sharpness and Sys-
tem.
Adjusts the brightness of the PIP image.
Adjusts the degree of difference between dark and light for the
PIP image.
Increases or decreases the color range (R, G, B) of the image.
Adjusts the image to make it appear more red or blue.
Adjusts the image to make it appear sharper or softer
Selects PIP image systems: Auto, NTSC, PAL, SECAM
BOXLIGHT CD-725c User's Guide
DESCRIPTION
PIP image
PIP image
PIP image
Operation
19
