BOXLIGHT CD-725c User's Guide

2. Image Menu

FUNCTION
Ratio
H-position
V-position
Color
Temp.
Information
System
Sharpness
Color
Tint
16 Operation
Users have 3 options for the image ratio.
1. 1:1 2. 4:3 3. 16:9
Adjusts the horizontal position of the projected image.
Adjusts the vertical positon of the projected image.
Adjusts the color temperature to fit your preference.
Shows the current resolution.
System information will be shown:
1. Auto 2.NTSC 3. PAL 4.SECAM
*The default setting for System is Auto.
Adjusts the image to make it look sharper or softer.
*This function is not available when the input mode is PC or YP
Increases or decreases the color range (R, G, B) of the image.
*This function is not available when the input mode is PC.
Adjusts the image to make it appear more red or blue.
*This function is not available when the input mode is PC.
DESCRIPTION
P .
B R
