s s I e u C u a
After installation, the unit 1. The power source is not turned ON.
doesn't work?
2. The power line and the cable locking connector is
3. The switch board and control board wirings
4. The switch board or control board is
Light works, but motor is 1. The motor is defective, possible seized.
not turning.
2. The thermally protected system detects if the motor
3. Damaged condenser.
1. The motor is not secure in place.
The unit is vibrating.
2. Damaged blower wheel.
3. The hood is not secured in place.
1. Defective halogen bulb.
The motor is working,
but the lights are not.
2. The light bulb is loose.
3. The light bulb is not making a full contact.
The hood is not venting 1. The hood might be hanging to high from the
out properly.
2. The wind from the opened windows or opened
3. Blocking in the duct opening or ductwork.
4. The direction of duct opening is against the wind.
5. Using the wrong size of ducting.
Metal filter is vibrating.
1. Metal filter is loose.
e s
not connecting properly.
are disconnected.
defective.
is too hot to operate and shuts the motor down.
cook top.
doors in the surrounding area are affecting the
ventilation of the hood.
15
W h t a o t o d
1. Make sure the circuit breaker and the unit's
power is ON.
2. Check the power connection with the unit is
connected properly.
3. Make sure the wirings between the switch
board and control board are connected properly.
4. Change the switch board or control board.
1. Change the motor.
2. The motor will function properly after the
thermally protected system cool down.
3. Change the condenser.
1. Tighten the motor in place.
2. Change the blower wheel.
3. Check the installation of the hood.
1. Change the halogen bulb.
2. Tighten the light bulb.
3. Remove the bulb and disable power to the
hood. Bend the two metal brackets inside the
bulb opening and bend them outwards to lower
the socket and make a complete contact.
1. Adjust the distance between the cook top
and the bottom of the hood within 24" and
32" range.
2. Close all the windows and doors to eliminate the
outside wind flow.
3. Remove all the blocking from the duct work or
duct opening.
4. Adjust the duct opening direction.
5. Change the ducting to at least 8" or higher.
1. Change the metal filter.
