1. Athlete starts on a socket next to the mat, hands on hip, and jumps down onto the mat.
2. On landing on the mat, the athlete jumps up as high as he can.
3. The TIMY3 measures the contact time and the fly time.
Printer Output:
0003 C0
Drop
Drop
Drop

4.4 Power Test 15s, 30s and 60s

This test measures how many jumps the athlete can execute in a certain period. The printer
outputs the time on the mat, the time in the air and the jump height for each jump.
1. Athlete starts on the mat and jumps as often as he can until the interval is elapsed.
2. The TIMY3 measures the fly time and the contact time between each jump.
Printer Output:
0005 C0
1 Pow15
1 Pow15
2 Pow15
2 Pow15
2 Pow15
3 Pow15
3 Pow15
3 Pow15
5

Interface for Display Board

Output format: 1 start-bit, 8 data-bit, no parity-bit, 1 stop-bit
factory setting 2400 baud (necessary for ALGE-TIMING GAZ display board)
Bit rate:
2400, 4800, 9600, 19200, 28800, 38400
Transmission protocol: ASCII
You can see the number of attempts and the height in cm on the display board.
The best height can be shown on address "A".
Each line ends with a carriage return (CR)
Output by RS232 or USB for power test 15 seconds:
12345678901234567890123456 character counter
0008 C0 16:04:13,1768 00
0008 Pow15 0,4736 fly 01
0008 Pow15
0008 Pow15 0,9523 con 01
0008 Pow15 0,5084 fly 02
0008 Pow15
0008 Pow15 0,9761 con 02
0008 Pow15 0,4564 fly 03
Manual
TIMY3 – Jumping
13:41:02.1706
0.3483 con
0.5134 fly
32 cm
13:53:11.1796
0.5134 fly
32 cm
0.3572 con
0.6208 fly
47 cm
0.3572 con
0.6079 fly
45 cm
028 cm 01
032 cm 02
Page 7
time of day when jump happens
time on the mat
time in the air
jumping height
time of day when jump happens
st
1 jump, power test for 15 sec., time in the air
st
1 jump, power test for 15 sec., jumping height
nd
2 jump, power test for 15 sec., time on the mat
nd
2 jump, power test for 15 sec., time in the air
nd
2 jump, power test for 15 sec., jumping height
rd
3 jump, power test for 15 sec., time on the mat
rd
3 jump, power test for 15 sec., time in the air
rd
3 Jump, Power Test for 15 sec., jumping height
