10.4 Composite input termination
The composite input can be set to high-impedance (for "daisy-chain" operation) or 75 ohm
termination. The input termination is set in the menu – see page xx for more information.
10.5 SD/HD/3G-SDI Prompter and Talent Inputs
The SDI inputs will configure themselves automatically according to the SDI format presented. The
inputs are compliant with SMPTE 259M-C, SMPTE 292M and SMPTE424M standards.
Prompter Connector type:
Mating (cable) connector:
10.6 SD/HD/3G-SDI Auxiliary output
The Auxiliary SDI output is set in the menu – see page 13 for more information.
Prompter Connector type:
Mating (cable) connector:
10.7 HDMI In
Prompter Connector type:
10.8 Cue Light (Optical) Sensor In
When the CueScript Cuelight sensor is installed, it allows the on-board Cue lights to illuminate when
the sensor sees sufficient light. Typically the sensor is affixed with a Velcro ring around the camera
tally light LED. There are two additional ways the Cue Lights may be triggered:
Ground the sensor input (through a relay or transistor switch).
Apply a voltage (5-24 VDC) to the +Logic Tally input (Tally Sensor In pin 2).
Sensor:
75 Ohm BNC Socket
75 Ohm BNC Plug
Pin
Description
Center
SD/HD-SDI In
Outer
Ground
75 Ohm BNC Socket
75 Ohm BNC Plug
Pin
Description
Center
SDI Out
Outer
Ground
19 pin HDMI socket: Pin connections are standard HDMI. The input is
compatible with HDMI 1.3 / 1.4 / 1.4a.
Photocell device. 16K Ω to 33K Ω @ 10 lux. 1M Ω or more at 0 lux.
