12.9

Main H offset

Horizontal picture offset will move the display position horizontally in either direction. The default
value is for nominal centre
12.10

Main V offset

Vertical picture offset will move the display position vertically in either direction. The default value is
for nominal centre
12.11

Cuelight Sensor

Sets the sensitivity of the cue light sensor. In high ambient light areas, it may be necessary to reduce
the sensitivity to reduce the risk of false transmission indication.
12.12

Tally switch

Sets the polarity of the logic input pin on the sensor connector
12.13

Flip/mirror

Switches the display in a 4-position cycle (normal/mirror/invert/mirror)
12.13.1: Factory Reset:
Hold this button when powering on the monitor to reset all factory defaults.
12.14

Overscanning

Increases/decreases in 1% increments the image size
12.15

Aspect ratio

Normally set to 4:3
12.16

USB-A Mode

Mode 1 (CSTD/CSTN) drives the Cuescript proprietary timecode display with data and a Red/Green
switch
Mode 2 (Keyboard) allows the user to connect a standard pc keyboard to the internal CueTalk
module
12.17

TC source

Three sources of time code may be used:
LTC – linear time code supplied to the three-pin Mini-XLR connector
VITC – vertical interval time code derived from the incoming composite video signal
D-VITC – digital vertical interval time code demultiplexed from the incoming SDI signal

12.18 Powersave idle

Sets the time from the start of a period of display inactivity after which the display will power down.
