2. Warnings

Disconnect all power sources before attempting installation. Electricity can be very
Battery and wiring safety.
Wiring connections.
Work safely.
Observe correct polarity
at all times.
Do not exceed the GPR-25
and Voltage

3. Tools and Materials Needed

Drill with 3/32" and 3/8 bits
Keyhole or Jigsaw
Phillips Screwdriver
#8 Flat Washers
Pencil or Marking Implement
* If the GPR-25 Charger Controller was purchased with a Go Power! Electric RV Solar Kit then UV resistant
wire is included. For instructions regarding RV Charger Kit installation, please refer to the RV Charger Kit
Installation Guide provided with the Kit.

4. Choosing a Location

The GPR-25 is designed to be mounted flush against a wall, out of the way and easily visible.
The GPR-25 should be:
• mounted as close to the battery as possible.
• mounted on a vertical surface to optimize cooling of the unit.
• indoors, protected from the weather.
In an RV, the most common regulator location is above the refrigerator. The wire from the solar modules
most commonly enters the RV through the fridge vent on the roof.
directly to the regulator. Battery connections should connect directly from the regulator to the batteries.
Do not tie the regulator wiring in with the refrigerator wiring or any other DC wiring.
If the flush mount option is not used, ensure that the optional knockout box (Model: GPR-25-KBox) is
securely mounted to the wall before proceeding with the installation of the GPR-25 Regulator.
dangerous. Installation should be performed only by a licensed
electrician or qualified personnel.
Observe all safety precautions of the battery manufacturer when
handling or working around batteries. When charging, batteries may
produce hydrogen gas, which is highly explosive. Work only in a well
ventilated area and use caution when making or removing electrical
connections. Ensure wires are disconnected from their power sources
when wiring. Do not expose battery to open flame, cigarettes, or sparks.
Shield skin and eyes from battery acid.
Ensure all connections are tight and secure. Loose connections may
generate sparks.
Wear protective eyewear and appropriate clothing during installation.
Use extreme caution when working with electricity and when handling
and working around batteries.
Any contact in reverse polarity, however brief, will cause the
regulator fuse to blow and may damage the unit.
The current rating of the solar system is the sum of the short Current
circuit currents (Isc) of the solar modules in parallel.
resulting system Isc current is not to exceed 25 A. The voltage
of the array is the rated open circuit voltage (Voc) of the solar module
and is not to exceed 26 V. If your solar system exceeds these ratings,
contact your dealer for a suitable regulator alternative.
UV Wire (Module(s) to GPR-25)*
Battery Wire (GPR-25 to Battery)*
Wire Cutters
Wire Strippers
Electrical Tape
Carmanah Technologies Corp. Copyright © 2007
GPR-25 Regulator
Owner's Manual |
Solar connections should connect
Document number: GPR-25_Manual_v4.doc
Last revised: June 21, 2007
The ratings
