4.4.1 Operating Steps

1 Install the power supply and antenna according to 4.2 Installation Guide,
connect the board and switch on EVK.
2 File -> connect the serial port and set the baud rate. The default baud rate of
UT4B0 is 115200bps.
3 Click the "receiver setting" button, configure NMEA message output and
click "Send". It is recommended to configure GPGGA, GPGSV and other
statements.
UC-00-M24 EN R2
Figure 4- 5 Uprecise View
Figure 4- 6
Serial Port Configuration
