- Page 1 INSTALLATION AND OPERATION USER MANUAL WWW.UNICORECOMM.COM UM220-INS GNSS Integrated Navigation and Positioning Module Copyright© 2009-2020, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 Revision History Version Revision History Date Initial Edition Feb. 2020 Copyright © Copyright 2009-2020 Unicore Communications, Inc. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the express written permission of the copyright owner.
-
Page 3: Table Of Contents
UM220-INS Series Module User Manual Contents CONTENTS ............................II OVERVIEW ..........................1 COPE ............................ 1 UDIENCE ..........................1 INTRODUCTION ........................1 RODUCT ESCRIPTION ......................1 EATURES ........................2 NTERFACES ..........................4 SYSTEM INSTALLATION ....................... 5 REREQUISITES ........................5 YSTEM NSTALLATION ...................... -
Page 4: Overview
This document describes the information of the hardware, installation, specification and the use of Unicore UM220-INS series product. 1.2 Audience This document is intended to present an overview of Unicore UM220-INS series products. The audience is expected to possess the expertise on GNSS receivers. 2 Introduction 2.1 Product Description... -
Page 5: Key Features
UM220-INS Series Modules User Manual Data Specification System Interface Update Rate Variant UM220-INS 2310408000012 ● ● ● ● ● ● ● ● UM220-INS 2310408000014 ● ● ● ● ● 1. The BDS system cannot run in parallel with the GLONASS system. - Page 6 Data Output NMEA 0183, Unicore Protocol Only supported by UM220-INS NL Only supported by UM220-INS NL Statistical values within one hour, not recommended for timing application User configurable. See Unicore UM220-INS Protocol Specification for more details. UC-00-M10 EN R1 Introduction...
-
Page 7: Interfaces
Figure 2-2 UM220-INS Series Modules Block Diagram UART UM220-INS series modules support two configurable UART ports. COM1 is the main serial port, which supports data transfer and firmware upgrade function, the signal input/output is LVTTL. The default baud rate is 115200bps, and can be configured up to 230400bps. -
Page 8: System Installation
Please check carefully whether the module has obviously loose or damaged. Please contact us or the local dealer for any problems. Figure 3-1 shows the typical installation of UM220-INS series modules with EVK suites. UC-00-M10 EN R1 System Installation... -
Page 9: System Installation
Step 3: Select the GNSS antenna with appropriate gain, fix it in the non-block area, using the appropriate cable to connect the antenna with UM220-INS EVK; Step 4: Connect the PC to the EVK serial port through the serial cable;... -
Page 10: Technical Specifications
4 Technical Specifications 4.1 Electrical Specifications Absolute Maximum Ratings Item Unit Description Power Supply (VCC) -0.5 Main power Backup Voltage (V_BCKP) -0.5 Backup power supply for RTC Voltage of the digital signal Digital IO (RXD1，RXD2) -0.5 pins RF_IN Max input power of antenna Storage Temperature T °... -
Page 11: Dimensions
UM220-INS Series Modules User Manual 4.3 Dimensions Symbol Min (mm) Type (mm) Max (mm) 15.9 16.0 16.5 12.2 12.4 Figure 4-1 Mechanical Layout UC-00-M10 EN R1 Technical Specifications... -
Page 12: Pin Definition
4.4 Pin Definition (Top View） Figure 4-2 Pin Assignment Pin No Name Electrical Level Description Reset nRESET LVTTL Low active, bypass if not in use Reserved TIMEPULS LVTTL Time pulse (1PPS) Odometer speed pulse, bypass if not in use. It is strongly recommended to use, the maximum acceptable pulse frequency is 5KHz, and the minimum WHEELTIC... -
Page 13: Pcb Packaging
Ground 4.5 PCB Packaging Figure 4-3 UM220-INS Series Modules Recommended PCB Packaging（unit: mil, in brackets: mm） In the design of PCB solder, make sure the area below the UM220-INS series modules are fully covered with solder layer. UC-00-M10 EN R1... -
Page 14: Hardware Design
5 Hardware Design 5.1 Design in Considerations It’s required to connect the following signals correctly to make UM220-INS series modules work properly. The VCC module is of good monotonicity, and undershoot and ringing are required to be guaranteed within 5% VCC. If VCC is powered off and then rebooted, the power off time must be greater than 10ms. -
Page 15: Antenna
VCC_RF Figure 5-1 UM220-INS Active Antenna (+3V) Solution If the UM220-INS series modules use an active antenna other than +3V, the bias voltage V_BIAS required by the antenna is used to power the antenna through the feeding inductor. Figure 5-2 UM220-INS NF Active Antenna (Other than +3V) Solution If the UM220-INS series modules use a passive antenna, connect the antenna to the RF_IN directly, and VCC_RF can be left floating. -
Page 16: Serial Port
5.3 Serial Port The serial ports of UM220-INS series modules are of LVTTL level, use a RS232 converter for the PC connection. UART1 RS232 1 UM220 RS232 -INS Converter UART2 RS232 2 Figure 5-4 Connect COM to PC 5.4 Odometer Installation UM220-INS series modules support direction (FWD) and velocity pulse (WHEELTICK) signals connecting with odometer. - Page 17 UM220-INS Series Modules User Manual Figure 5-6 Module Coordinate System Figure 5-7 Car Coordinate System 1. The normal direction of the shield is Z axis, the long axis is Y and the short axis is X. 2. The coordinate of the module must be consistent with the vehicle’s, which means: X-axis and R-axis are parallel in the same direction, Y-axis and F-axis are parallel in the same direction, and Z-axis and U-axis are parallel in the same direction.
-
Page 18: Installation Of The Module
5.6 Installation of the Module UM220-INS series modules must be rigidly connected to the vehicle body and firmly fixed. 1. The antenna should be installed with the front facing up as much as possible and firmly fixed; ensure that the elevation angle of the environment where the antenna is located is greater than 15 ° and the space is unobstructed. -
Page 19: Installation Options Of The Module
Free Installation (Default Mode) UM220-INS series modules integrate a three-axis gyroscope and a three-axis accelerometer, with a built-in self-calibration algorithm, which supports the free installation of the module with respect to any installation angle of the vehicle coordinate system, such as, the completely horizontal installation, inclined installation at a certain angle, and flip installation. -
Page 20: Reference Messages
5.6.4 Reference Messages 1. CFGROTAT Message format: $ CFGROTAT,angleR, angleF, angleU, mode Description: Set or output the installation angle configurations of the module with respect to the vehicle coordinate system. Parameters: ◆ angleR, angleF and angleU, refer to the 5.6.2 for details with the unit of 0.01° ◆... - Page 21 UM220-INS Series Modules User Manual -1: Odometer device failure 0: Disabled 1: Initialize the scale factor 2: The scale factor initialization is completed 3: The scale factor calibration is completed ◆ InstallState 0: In the progress of the calibration 1: The current quality of satellite information is insufficient and better satellite conditions are required 2: The current maneuver conditions of the carrier are insufficient and it’s required to...
-
Page 22: Module Calibration And Notice
5.6.5 Module Calibration and Notice Self-Calibration After the installation of the UM220-INS series modules, the self-calibration is required to ensure the accuracy of the module output. In the process of the self- calibration, the module estimates installation status parameters and sensor parameters. -
Page 23: Disassembly
Product QR Code (serial number) 7.2 Package Description The UM220-INS series modules use carrier tape and reel (suitable for mainstream surface mount equipment), packaged in vacuum-sealed aluminum foil antistatic bags, with a desiccant inside to prevent moisture. When using reflow welding process to weld modules, please strictly comply with IPC standard to conduct humidity control on modules. -
Page 24: Clean
2.0mm Carrier tape Space between: 20mm UM220-INS series modules are rated at MSL level 3, refer to the relevant IPC/JEDEC standards for baking requirements. Please access to the website www.jedec.org to download for details. The shelf life of UM220-INS series modules is one year. -
Page 25: Reflow Soldering
UM220-INS Series Modules User Manual 9 Reflow Soldering In order to avoid device falling off, the module should be placed on the top of the main board during welding. Reflow soldering temperature curve is recommended as shown in figure 9-1 below (M705-GRN360 is recommended for solder paste). - Page 26 和芯星通科技（北京）有限公司 Unicore Communications, Inc. 北京市海淀区丰贤东路7号北斗星通大厦三层 F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China, 100094 www.unicorecomm.com Phone: 86-10-69939800 Fax: 86-10-69939888 info@unicorecomm.com www.unicorecomm.com...
