Bowers & Wilkins Signature HTM Specification Sheet

Signature HTM
TM
Magnetically shielded centre channel loudspeaker system
Product Summary
Superbly finished in piano gloss Tigers Eye veneer, this superbly crafted centre speaker
n
matches the other Signature products in an audiophile-quality Home Theatre system.
Derived from the Nautilus HTM1, the 3-way Signature HTM freaures twin paper/Kevlar®
n
cone bass drivers, one each side of the central midrange driver. This FST midrange driver
and the free-mounted tweeter on top both incorporate the latest developments made for
the Signature 800.
Technical highlights
Tweeter on top: B&W's Tweeter on top technology ensures that the sound
remains focused and time-sensitive and that the stereo-image is presented with
unparalleled three dimensional accuracy.
Kevlar®: B&W developed and patented the method of using Kevlar® for
loudspeaker cones to reduce unwanted standing waves. DuPont originally
created Kevlar® for use in bulletproof vests.
Flowport™: Golf ball aerodynamics theory points the way towards lower
distortion reflex ports. Dimples improve the way the air flows over the surface of
any object. In the case of reflex ports, they offer a significant improvement over
simply flaring the port ends in reducing air flow turbulence at each end of the
port; so you get less chuffing noise and less compression at high sound levels.
Matrix™: The basic construction of nearly all loudspeakers is exactly the same -
panels of wood-based materials, bonded to form a rectangular box. B&W
studied and evaluated how each aspect of cabinet behaviour and the efficiency
of various materials and construction methods affects sound.
Description 3-way closed-box system
Drive units 1 x 25mm metal dome high-frequency
1 x 150mm woven Kevlar
midrange
2 x 165mm Paper/Kevlar
Frequency response 49Hz - 23kHz ± 2db on reference
axis
Sensitivity 90db spl (2.83V, 1m)
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
Nominal impedance 8
Power handling
cone FST
TM
®
Dimensions
cone bass
®
Finishes
w w w. b w s p e a k e r s . c o m
(minimum 3.0 )
50W - 250W into 8 on unclipped
material
Height:318mm Width: 783mm
Depth: 316mm
Cabinet: Grey Tigers Eye real wood
veneer, Grile: Black cloth
