2002
Stand-mount/Bookshelf loudspeaker system
Product Summary
A two-way fourth-order vented box of just 8.4litres volume, the 2002 rewards the purchaser with
more realism and greater power handling is common in this sector.
Shelf or wall mounted, the compact dimensions and curved baffle combine to produce excellent
dispersion and absence of unwanted resonances and coloration
Technical highlights
As the name of the 2000 Series suggests, these loudspeakers have been designed to meet
the needs of the consumer between now and the 21st Century.
Contoured front baffle to overcome diffraction
Acoustically transparent frameless grilles with specially developed low coloration drive units.
Also produced in a magnetically shielded version 2002 ZMF
Drive Units
1 x 30mm diameter high frequency with
alloy diaphragm, 19mm dia. high
temperature voice coil and magnetic
fluid cooling.
1 x 135mm diameter bass/midrange
with acyrilic damped fibre cone, low
hysteresis rubber surround and 25mm
dia. high temperature voice coil.
Frequency Response
74Hz – 20kHz ± 2dB
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
88dB spl (2.83V,1m)
Sensitivity
4 ohms
Nominal Impedance
20W – 80W into 4 ohms undistorted
Power Handling
speech and music programme
Height: 346mm Width: 180mm
Dimensions
Depth: 200mm
Black ash vinyl or white vinyl
Finish
www.bwspeakers.com
