DM560
Stand-mount/Bookshelf loudspeaker system
Product Summary
The two way front vented system encompasses the same design technology of the DM550
with its rigid one-piece baffle construction, but offers a noticeable extended bass – thanks to
a bigger 8in bass/midrange driver and increased enclosure size.
Technical highlights
B&W's Tweeter technology ensures that the sound remains focused and time sensitive and
that the stereo image is presented with unparalleled three dimensional accuracy.
The cabinets feature a specially designed high density front baffle which achieves almost
Matrix-like stability in strengthening overall enclosure construction. The bevel edges of the front
moulding reduce diffraction and improve dispersion.
The crossover components use heavy gauge wire throughout and new drivers guarantee not
only high reliability but ensure that top specifications are met.
Drive Units
1 x 26mm high-frequency with
aluminium dome, 26mm coil on
aluminium dome former, wound with
polymide resin and heat cured
1 x 200mm bass/midrange with
composite short fibre cone, 26mm coil
on high temperature former, wound with
polymide resin and heat cured
Frequency Response
65Hz – 20kHz ± 2.5dB on reference
axis
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
Sensitivity
90dB spl(2.83V 1m)
Nominal Impedance
8 ohms
Power Handling
10W – 75W into 8 ohms on
unclipped programme
Height: 490mm Width: 236mm
Dimensions
Depth: 302mm
Finish
Black ash or walnut vinyl
www.bwspeakers.com
