2000IFS
Magnetically shielded centre channel loudspeaker system
Product Summary
The 2000IFS with ZMF completes a whole range of audio components to enable the assembly
of a top quality audio/video surround sound system at home.
The new 2000 IFS centre channel speaker has been designed to facilitate crisp, highly image-
specific dialogue reproduction. Its arrival brings an important dimension to voice localisation.
Technical highlights
As the name of the 2000 Series suggests, these loudspeakers have been designed to meet
the needs of the consumer between now and the 21st Century.
Affordable, high performance audio/video loudspeakers with ZMF (Zero Magnetic Field)
Contoured front baffle to overcome diffraction
Acoustically transparent frameless grilles with specially developed low coloration drive units.
Drive Units
1 x 25mm diameter high frequency unit
polymide diaphragm and magnetic fluid
cooled voice coil
2 x 165mm bass/midrange with acrylic
damped fibre cone, low hysteresis
rubber surround and 25mm dia. high
temperature voice coil.
Frequency Response
± 3dB at 95Hz – 20kHz
Sensitivity
88dB spl(2.83V,1m)
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
8 ohms
Nominal Impedance
25W – 100W into 8 ohms of
Power Handling
undistorted speech and music
programme
Height: 150mm Width: 450mm
Dimensions
Depth: 240mm
Black ash vinyl or White vinyl
Finish
www.bwspeakers.com
