Stark 61006 Owner's Manual And Safety Instructions

Plate compactor
Hide thumbs Also See for 61006:

Advertisement

PLATE COMPACTOR
ITEM: 61006/61007
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 4900 MON-FRI 9AM TO 3PM PST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 61006 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stark 61006

  • Page 1 PLATE COMPACTOR ITEM: 61006/61007 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH...
  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY WARNING DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as owner’s manuals, service manuals or instruction sheets supplied with this product or optional equipment.
  • Page 3 The Manufacturer does not assume responsibility for any accident due to equipment modifications and will also void the warranty. NEVER use accessories or attachments that are not recommended by STARK for this model of plate compactor. DO NOT add fuel to the plate compactor if it placed on top of a plastic surface such as a pickup truck bed with a plastic liner.
  • Page 4: Operation

    OPERATION PRE-START INSPECTION: The following Pre-start-up inspection must be performed before the start of each work session or after every four hours of use, whichever is first. If any fault is discovered, the compactor must not be used until the fault is rectified 1.
  • Page 5 OPERATION 5. Taking a firm hold of the control handle with one hand,grasp the recoil starter handle with the other. Pull the recoil starter until engine esistance is felt, then let starter return. 6. Taking care not to pull the starter’s cope fully out, pull the starter handle briskly. 7.
  • Page 6: Care And Maintenance

    CARE AND MAINTENANCE Check the oil level in the motor crankcase daily. Check the vibrator oil level weekly. Inspect the rubber anti vibration mounts for wear or deterioration. If the optional water tank is fitted inspect the water hose and its connections to ensure that they do not leak.
  • Page 7 CARE AND MAINTENANCE CHANGING VIBRATOR OIL When changing the vibrator oil, remove the drain plug located at the bottom-right of the vibrator, and simply tip the compactor to drain the oil. Note that the oil will drain more easily while it is hot. Replace the oil with 200ML of 10W-3C motor oil.
  • Page 8: Specifications

    SPECIFICATIONS MOTOR: MODEL #61006 Chinese Petrol Engine, 4.8 kW output. MODEL #61007 Petrol, Honda GXl60, 4.0 kW output. GOVERNED SPEED: 3,500r/min DRIVE BELT: 1 x ’A’ section v belt VIBRATOR FREQUENCY: 5,500 Vibration/min VIBRATOR CENTRIFUGAL FORCE: 13.0kN OPERATION MASS: 84kgs...
  • Page 9: Troubleshooting

    TROUBLESHOOTING...
  • Page 10: Parts Diagram

    PARTS DIAGRAM...
  • Page 11: Parts List

    PARTS LIST...
  • Page 12: Please Read The Following Carefully

    PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
