FORWARD PLATE COMPACTOR 79CC 2000LBS
ITEM: 61014
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 4900 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stark 61014
Summary of Contents for Stark 61014
- Page 1 FORWARD PLATE COMPACTOR 79CC 2000LBS ITEM: 61014 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. WARNING DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as owner’s manuals, service manuals or instruction sheets supplied with this product or optional equipment. - Page 3 The Manufacturer does not assume responsibility for any accident due to equipment modifications and will also void the warranty. NEVER use accessories or attachments that are not recommended by STARK for this model of plate compactor. DO NOT add fuel to the plate compactor if it placed on top of a plastic surface such as a pickup truck bed with a plastic liner.
-
Page 4: Operation
OPERATION The machine is best suited to the compaction of bituminous and granular materials e.g. granular soils, gravels and sands or mixtures of both. Cohesive soils such as silt and clay are best compacted using the impact force produced by a vibrating rammer. Where possible the site should be graded and levelled before commencing compaction. -
Page 5: Prior To Operation
OPERATION PRIOR TO OPERATION Make sure that all dirt, mud, etc., are thoroughly removed from the unit prior to operation. Special effort should be given to the button face of the vibrating plate and those areas adjacent to the cooling air inlet of engine, carburetor, and air cleaner. -
Page 6: Gas Engine
OPERATION GASOLINE ENGINE STARTING THROTTLE LEVER 1. Turn the STOP SWITCH clock-wise to the position “1”(ON). FIG. 5D 2. Open the fuel cock. OPEN 30 DEGREES 3. Set the speed control lever 1/3 to 1/2 of the way towards the high speed position. - Page 7 OPERATION When compacting asphalt, it is advisable to paint the bottom face of the vibrating plate with gas fuel. This will assist in preventing the plate from sticking to the as halt. When shutting off the vibrator, turn the speed control lever from the HIGH to LOW position.
-
Page 8: Maintenance
MAINTENANCE Monthly Service Change the oil in the vibrator assembly. Storage When storing the compactor for long periods after operation. Thoroughly drain the fuel from the fuel tank fuel pipe and carburetor. Pour a few drops of motor oil into the cylinder by removing the spark plug. -
Page 9: Parts List
TROUBLESHOOTING TROUBLESHOOTING PARTS LIST... -
Page 10: Parts Information
PARTS INFORMATION 35 24... - Page 11 OF NOTE THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
