The product turns on within a set pressure range (OUT1: from P1L to P1H, OUT2: from P2L to P2H) during
window comparator mode. Set P1L/P2L, the lower limit of the switch operation, and P1H/P2H, the upper
limit of the switch operation and WH1/WH2 (hysteresis) following the instructions given on page 21.
(When reversed output is selected, the sub display (left) shows [n1L]/[n2L] and [n1H]/[n2H].)
Please refer to the "List of output modes" on page
32
for the relationship between the set values and
operation.
: Setting of the normal/reverse output switching and hysteresis/window comparator mode switching are
performed with the function selection mode [F 1] Setting of OUT1, [F 2] Setting of OUT2.
-22-
No.PS※※-OMU0012-A
