V L T A u t o m a t i o n D r i v e E t h e r N e t / I P
- T r o u b l e s h o o t i n g -
B i t E x t e n d e d s t a t u s w o r d 2
( P a r 1 6 - 9 5 )
( H e x ) F C 1 0 0 o n l y ! !
0 0 0 0 0 0 0 1 O f f
0 0 0 0 0 0 0 2 H a n d / A u t o
0 0 0 0 0 0 0 4 P R O F I b u s O F F 1 a c t i v e
0 0 0 0 0 0 0 8 P R O F I b u s O F F 2 a c t i v e
0 0 0 0 0 0 1 0 P R O F I b u s O F F 3 a c t i v e
0 0 0 0 0 0 2 0 R e l a y 1 2 3 a c t i v e
0 0 0 0 0 0 4 0 S t a r t P r e v e n t e d
0 0 0 0 0 0 8 0 C o n t r o l r e a d y
0 0 0 0 0 1 0 0 D r i v e r e a d y
0 0 0 0 0 2 0 0 Q u i c k S t o p
0 0 0 0 0 4 0 0 D C B r a k e
0 0 0 0 0 8 0 0 S t o p
0 0 0 0 1 0 0 0 S t a n d B y
0 0 0 0 2 0 0 0 F r e e z e O u t p u t R e q u e s t
0 0 0 0 4 0 0 0 F r e e z e O u t p u t
0 0 0 0 8 0 0 0 J o g R e q u e s t
0 0 0 1 0 0 0 0 J o g
0 0 0 2 0 0 0 0 S t a r t R e q u e s t
0 0 0 4 0 0 0 0 S t a r t
0 0 0 8 0 0 0 0 S t a r t A p p l i e d
0 0 1 0 0 0 0 0 S t a r t D e l a y
0 0 2 0 0 0 0 0 S l e e p
0 0 4 0 0 0 0 0 S l e e p B o o s t
0 0 8 0 0 0 0 0 R u n n i n g
0 1 0 0 0 0 0 0 B y p a s s
0 2 0 0 0 0 0 0 F i r e M o d e
0 4 0 0 0 0 0 0
0 8 0 0 0 0 0 0
1 0 0 0 0 0 0 0
2 0 0 0 0 0 0 0
4 0 0 0 0 0 0 0
8 0 0 0 0 0 0 0
M G . 9 0 . J 1 . 0 2 – V L T i s a r e g i s t e r e d D a n f o s s t r a d e m a r k
R e s e r v e d
R e s e r v e d
R e s e r v e d
R e s e r v e d
R e s e r v e d
R e s e r v e d
