V L T A u t o m a t i o n D r i v e E t h e r N e t / I P
( 1 2 - 0 0 ) I P A d d r e s s A s s i g n m e n t
O p t i o n :
* M a n u a l
D H C P
B O O P T
F u n c t i o n :
S e l e c t s t h e I P A d d r e s s a s s i g n m e n t m e t h o d .
I f i s s e l e c t e d , t h e I P - a d d r e s s c a n b e s e t
M a n u a l
i n p a r . 1 2 - 0 1
I P A d d r e s s .
( 1 2 - 0 1 ) I P A d d r e s s
R a n g e :
* 0 0 0 . 0 0 0 . 0 0 0 . 0 0 0 - 2 5 5 . 2 5 5 . 2 5 5 . 2 5 5
F u n c t i o n :
C o n f i g u r e t h e I P a d d r e s s o f t h e o p t i o n .
R e a d - o n l y i f p a r . 1 2 - 0 0 s e t t o D H C P o r B O O T P
( 1 2 - 0 2 ) S u b n e t M a s k
R a n g e :
* 0 0 0 . 0 0 0 . 0 0 0 . 0 0 0 - 2 5 5 . 2 5 5 . 2 5 5 . 2 5 5
F u n c t i o n :
C o n f i g u r e t h e I P s u b n e t m a s k o f t h e o p t i o n .
R e a d - o n l y i f p a r . 1 2 - 0 0 s e t t o D H C P o r B O O T P .
( 1 2 - 0 3 ) D e f a u l t G a t e w a y
R a n g e :
* 0 0 0 . 0 0 0 . 0 0 0 . 0 0 0 – 2 5 5 . 2 5 5 . 2 5 5 . 2 5 5
F u n c t i o n :
C o n f i g u r e t h e I P d e f a u l t g a t e w a y o f t h e o p t i o n .
R e a d - o n l y i f p a r . 1 2 - 0 0 s e t t o D H C P o r B O O T P .
( 1 2 - 0 4 ) D H C P S e r v e r
O p t i o n :
* 0 0 0 . 0 0 0 . 0 0 0 . 0 0 0 – 2 5 5 . 2 5 5 . 2 5 5 . 2 5 5
F u n c t i o n :
R e a d o n l y .
D i s p l a y s t h e I P a d d r e s s o f t h e f o u n d D H C P o r
B O O T P s e r v e r .
N . B . :
A p o w e r - c y c l e i s n e c e s s a r y a f t e r s e t t i n g
t h e I P p a r a m e t e r s m a n u a l l y .
- P a r a m e t e r s –
[ 0 ]
[ 1 ]
[ 2 ]
.
M G . 9 0 . J 1 . 0 2 – V L T i s a r e g i s t e r e d D a n f o s s t r a d e m a r k
( 1 2 - 0 5 ) L e a s e E x p i r e s
O p t i o n :
d d : h h : m m : s s
F u n c t i o n :
R e a d o n l y .
D i s p l a y s t h e l e a s e - t i m e l e f t f o r t h e c u r r e n t
D H C P - a s s i g n e d I P a d d r e s s .
( 1 2 - 0 6 ) N a m e S e r v e r s
O p t i o n :
[ 0 ] P r i m a r y D N S
[ 1 ] S e c o n d a r y D N S * 0 0 0 . 0 0 0 . 0 0 0 . 0 0 0
F u n c t i o n :
I P a d d r e s s e s o f D o m a i n N a m e S e r v e r s .
C a n b e a u t o m a t i c a l l y a s s i g n e d w h e n u s i n g
D H C P .
( 1 2 - 0 7 ) D o m a i n N a m e
O p t i o n :
( M a x . 1 9 c h a r s . )
* b l a n k
F u n c t i o n :
D o m a i n n a m e o f t h e a t t a c h e d n e t w o r k .
C a n b e a u t o m a t i c a l l y a s s i g n e d w h e n u s i n g
D H C P .
( 1 2 - 0 8 ) H o s t N a m e
O p t i o n :
( M a x . 1 9 c h a r s . )
* b l a n k
F u n c t i o n :
L o g i c a l ( g i v e n ) n a m e o f o p t i o n
( 1 2 - 0 9 ) P h y s i c a l A d d r e s s
R a n g e :
0 0 : 1 B : 0 8 : 0 0 : 0 0 : 0 0 – 0 0 : 1 B : 0 8 : F F : F F : F F
F u n c t i o n :
R e a d o n l y
D i s p l a y s t h e P h y s i c a l ( M A C ) a d d r e s s o f t h e
o p t i o n
.
* 0 0 0 . 0 0 0 . 0 0 0 . 0 0 0
.
