urmet domus Exigo 1072/19A Manual

Panel with door unit and digitiser
Hide thumbs Also See for Exigo 1072/19A:
Table of Contents

Advertisement

Quick Links

HOW TO FORM THE PANEL CODE ................................................2
DIGITALIZER DEVICE Ref. 1072/19A ...............................................3
Performance .................................................................................3
Structure .......................................................................................3
Description of terminal boards .....................................................3
Technical specifications ...............................................................3
Default programming ....................................................................4
Connections .................................................................................4
Function ........................................................................................4
Adjustments ..................................................................................4
Description of terminals ................................................................5
Technical specifications ...............................................................5
TV CAMERA UNIT ............................................................................5
Technical specifications ...............................................................5
Camera unit assembly ..................................................................5
Camera lens direction adjustment ................................................6
CAMERA ADAPTER Ref. 1742/13A .................................................7
Adapter installation .......................................................................7
Flush-mounting boxes ..................................................................8
Door unit installation procedure ...................................................9
Flush-mounting boxes ................................................................11
Door unit installation procedure .................................................11
Manuale Tecnico - BIBUS II^ Ed. VOP
SECTION 3G
Exigo
WITH DOOR UNIT
AND
DIGITISER
Download from www.urmet.com Technical Manuals area.
SECTION CONTENTS
(REv.H)
PANEL
2
PROGRAMMING
See section 1A

sec.3g −−−−

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Exigo 1072/19A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for urmet domus Exigo 1072/19A

Summary of Contents for urmet domus Exigo 1072/19A

  • Page 1: Table Of Contents

    SECTION 3G (REv.H) Exigo PANEL WITH DOOR UNIT DIGITISER Download from www.urmet.com Technical Manuals area. SECTION CONTENTS PUSH BUTTON PANEL EXIGO DOOR PHONE SYSTEMS IN SINTHESI BOXES ELECTRICAL AND MECHANICAL SPECIFICATIONS .....2 Examples of modular constructions with various capacities ..13 HOW TO FORM THE PANEL CODE ..........2 VIDEO DOOR PHONE SYSTEMS IN SINTHESI BOXES Examples of modular constructions with various capacities ..14...

  • Page 2: Push Button Panel Exigo

    PUSH BUTTON PANEL EXIGO ELECTRICAL AND MECHANICAL SPECIFICATIONS HOW TO FORM THE PANEL CODE PUSH BUTTON PANEL EXIGO HOW TO FORM THE PANEL CODE Exigo is the new, elegant and customisable, brass-plated Urmet Please provide a code formed as follows for ordering a customised panel.

  • Page 3: Loudspeaking Unit With Built-In Digitalizer Device Ref. 1072/19A

    PUSH BUTTON PANEL EXIGO LOUDSPEAKING UNIT WITH BUILT-IN DIGITALIZER DEVICE Ref. 1072/19A LOUDSPEAKING UNIT WITH BUILT-IN STRUCTURE DIGITALIZER DEVICE Ref. 1072/19A The door unit with digitiser consists of the following parts: Speaker. Main terminal board. 3 Simplified programming dip-switch. PERFORMANCE Programming adapter connector Ref. 1072/60. 5 Simplified programming button and LED.

  • Page 4: Default Programming

    PUSH BUTTON PANEL EXIGO LOUDSPEAKING UNIT WITH BUILT-IN DIGITALIZER DEVICE Ref. 1072/19A DEFAULT PROGRAMMING BUSY FUNCTION This function is only required in systems with more than one calling § Refer to section 1A “Programming” in this manual for how to device.

  • Page 5: 16-Pushbutton Expansion Module Ref. 1038/17

    PUSH BUTTON PANEL EXIGO 16-PUSHBUTTON EXPANSION MODULE Ref. 1038/17 TV CAMERA UNIT Ref. 1810/40 16-PUSHBUTTON EXPANSION MODULE TV CAMERA UNIT Ref. 1810/40 Ref. 1038/17 To the digitizer Ref. 1072/19A OUTPUT INPUT OUTPUT INPUT Easy to insert and extract from the front of the panel, the camera unit is provided with: The extension module can be used to add 16 user buttons to the •...

  • Page 6: Camera Lens Direction Adjustment

    PUSH BUTTON PANEL EXIGO TV CAMERA UNIT DESCRIPTION OF TERMINAL BOARDS Camera on control in digital systems Camera power positive in digital systems Camera power positive in analogic systems Camera power negative V5/B Video signal earth V3/A Video signal CAMERA LENS DIRECTION ADjUSTMENT With this TV camera unit, it is possible to adjust the direction of the TV camera lens inside it using the specific adjustment screws A and B in order to overcome any installation flaws.

  • Page 7: Camera Adapter Ref. 1742/13A

    PUSH BUTTON PANEL EXIGO CAMERA ADAPTER Ref. 1742/13A FOR 5 WIRE SYSTEMS IMAGING ANGLES 22,5 -48,5 48,5 -22,5 +10° -10° HORIZONTAL +10° -20° VERTICAL Measurements in centimetres CAMERA ADAPTER Ref. 1742/13A The device is used in Bibus II^ Ed. VOP video door phone systems. It transforms the composite video signal from the camera into two different video signals (A and B).

  • Page 8: Panels For Sinthesi Flush-Mounting Boxes

    PUSH BUTTON PANEL EXIGO PANELS FOR SINTHESI FLUSH-MOUNTING BOXES PANELS FOR SINTHESI FLUSH-MOUNTING System wires lead into the boxes through the openings on the sides and bottom of the box. BOXES All openings are shut by removable closures. This range of panels is suitable for installation in systems from 1 to 10 users. Sinthesi flush-mounting boxes adapted by means of a spacer are used.

  • Page 9: Door Unit Installation Procedure

    PUSH BUTTON PANEL EXIGO PANELS FOR SINTHESI FLUSH-MOUNTING BOXES Screws A (3.5 x 16mm) are provided with the spacer. NAME TAG BACK-LIGHTING LED FASTENING The box and spacer must be installed flush with the wall without PROCEDURE protruding at a height of approximately 1.55 ÷ 1.60m from the floor. The flush-mounting depth of all boxes is equal to 60mm (45mm for the Use the template provided with the front panel to fasten the name tag box + 15mm for the spacer).

  • Page 10: Name Tag Assembly And Front Panel Fastening Procedure

    PUSH BUTTON PANEL EXIGO PANELS FOR DEDICATED FLUSH-MOUNTING BOXES NAME TAG ASSEMBLY AND FRONT PANEL PANELS FOR DEDICATED FLUSH-MOUNTING FASTENING PROCEDURE BOXES Exigo panels are provided with a brass name tag (not engraved) which This panel range is designed for use in systems from 3 to 20 users. may be replaced by an engraved brass name tag or an anthracite grey Dedicated flush-mounting boxes are used.

  • Page 11: Flush-Mounting Boxes

    PUSH BUTTON PANEL EXIGO PANELS FOR DEDICATED FLUSH-MOUNTING BOXES FLUSH-MOUNTING BOXES FLUSH-MOUNTING BOX INSTALLATION PROCEDURE Apply adhesive labels to protect the front panel fastening holes during A different box than shown in the following table must be used the embedding operation. according to the panel model to be installed: Front panel code Flush-mounting...

  • Page 12: Name Tag Back-Lighting Led Fastening Procedure

    PUSH BUTTON PANEL EXIGO PANELS FOR DEDICATED FLUSH-MOUNTING BOXES 2 ROWS OF BUTTONS NAME TAG ASSEMBLY AND FRONT PANEL FASTENING PROCEDURE Exigo panels are provided with a brass name tag (not engraved) which may be replaced by an engraved brass name tag or an anthracite grey PVC name tag. Coloured film (each box contains 5 pieces in two colours) may be used to customise the colour of the backlighting: •...

  • Page 13: Door Phone Systems In Sinthesi Boxes Examples Of Modular Constructions With Various Capacities

    PUSH BUTTON PANEL EXIGO DOOR PHONE SYSTEMS IN SINTHESI BOXES EXAMPLES OF MODULAR CONSTRUCTIONS WITH vARIOUS CAPACITIES BUTTONS NUMBER 1 2 3 4 5 6 7 8 9 10 1143/101 1143/102 1143/103 1143/104 1143/105 FRONT 1143/106 1143/107 1143/108 1143/109 1143/110 DOOR UNIT 1072/19A EXPANSION...

  • Page 14: Video Door Phone Systems In Sinthesi Boxes Examples Of Modular Constructions With Various Capacities

    PUSH BUTTON PANEL EXIGO vIDEO DOOR PHONE SYSTEMS IN SINTHESI BOXES EXAMPLES OF MODULAR CONSTRUCTIONS WITH vARIOUS CAPACITIES BUTTONS NUMBER 1 2 3 4 5 6 7 8 9 10 1743/101 1743/102 1743/103 1743/104 1743/105 FRONT 1743/106 1743/107 1743/108 1743/109 1743/110 DOOR UNIT 1072/19A...

  • Page 15: Door Phone Systems In Dedicated Boxes Examples Of Modular Constructions With Various Capacities

    PUSH BUTTON PANEL EXIGO DOOR PHONE SYSTEMS IN DEDICATED BOXES EXAMPLES OF MODULAR CONSTRUCTIONS WITH vARIOUS CAPACITIES BUTTONS NUMBER 1 row 2 rows 5 6 4 6 8 10 12 14 16 18 20 1121/103 1121/104 1121/105 1121/106 1121/204 1121/206 FRONT 1121/208 1121/210...

  • Page 16: Video Door Phone Systems In Dedicated Boxes Examples Of Modular Constructions With Various Capacities

    PUSH BUTTON PANEL EXIGO vIDEO DOOR PHONE SYSTEMS IN DEDICATED BOXES EXAMPLES OF MODULAR CONSTRUCTIONS WITH vARIOUS CAPACITIES BUTTONS NUMBER 1 row 2 rows 5 6 4 6 8 10 12 14 16 18 20 1721/103 1721/104 1721/105 1721/106 1721/204 1721/206 FRONT 1721/208...
