CDP
The front panel display may vary according to the inverter model,
Figure 4:PIKO 3.0/3.6/4.2/5.5 screen (with type I communications card)
Figure 5:PIKO 7.0/8.3/10.1/10/12/15/17/20 screen (with type II communications card )
Programming the inverter on the web server is recommended, given that it streamlines the pro-
gramming and enables a faster and easier configuration.
The parameters to be configured are:
 Peripheral number
 KOSTAL communication protocol
 Analogue input function.
The communications speed is 19200 bps, a fixed parameter.
When a KOSTAL inverter is selected in the CDP, the device adjusts the communication speed
to the inverters' speed.
Application notes
and .
Figure 4 Figure 5
