FabiaTech FX5642 Series Users Quick Reference

Version 1.0

1. Brief

The FX5642xxx is a powerful, compact size embedded system with Intel® Skylake™ processor board
inside. This user's quick reference provides the I/O outlets description and their pin assignment.

2. Dimensions (in mm) and Front/Rear Panel Information

FX5642S0x (no expansion slot)
EAR-PHONE LINE IN DISPLAY3 POWER BUTTON
DIGITAL I/O MIC DISPLAY2 USB RESET
D I/O
-
2 3
1 0 IN
+ 1 0 OUT
12~24V
ANTENNA ANTENNA
www.fabiatech.com
FX5642x Series User's Quick Reference
FX5642S2x (2 expansion slots)
EAR-PHONE LINE IN DISPLAY3 POWER BUTTON
DIGITAL I/O MIC DISPLAY2 USB
LAN2
LAN1
D I/O
-
3
2
1 0 IN
+
12~24V 1 0 OUT
1
2
HDD
ANTENNA
(Front Panel)
GROUND DC IN USB
DC IN
SYS 12~24V CARD 12V
- -
+ + 2
1
VGA LAN2 LAN1

3. Packing List

A. Standard Items
1 FX5642xxx embedded system.
1 4-pin, pitch 5.08mm terminal block for DC power input.
1 6-pin, pitch 3.5mm terminal block for digital I/Os.
2 SATA cables (signal and power).
1 pack of 12 screw (6+4+2) for Mini-card/2.5" HDD/Riser card installation.
1 compact disc includes software utilities and manuals.
B. Optional Items for FX5642xxx system
# Half size mini-card adapter kit (AK1006, 1 piece of metal with 2 screws, P/N: 0606010028G)
# Wall mounting kit (FX5636K1, P/N: 0606010027G, 2 pieces of metal with 4 fixed screws)
# 2-slot PCI riser card (FB4764, P/N: 0103010011G,
# 1-slot PCIe x16 riser card (FB4767, P/N: 0120010006G,
# 2-slot PCIe riser card (FB4769, P/N: 0103010010G,

4. Features

* Processor Board
Intel® Skylake™ processor with 8GB/4GB DDR4 RAM. (16GB DDR4 maximum)
FX5642SxC
FX5642Sx5 : i5-6500TE (2.3GHz to 3.3GHz, 4C/4T, 6MB Cache, 1866+MHz FSB, 35 Watts)
* I/O Outlets
2 GbE ports with LED indicators.
LAN2
RESET LAN1
7 USB ports (4x V3.0), 2 RS-232 and 4 RS-232/422/485 serial ports.
1 VGA, 1 HD display port, 1 DP display port, 1 Earphone, 1 Line-in, and 1 Microphone connectors.
1 6-pin terminal block for 2 digital inputs and 2 digital outputs.
1 power button LED, 1 reset button, 2 LAN-link LEDs, and 1 HDD/m-SATA access LED.
1 1 free PCIe expansion slot for riser cards.
2
* Storage Bay
1 m-SATA socket and 2 SATA connectors for 2.5" HDD.
2 mini PCIe sockets and 2 SIM sockets.
* Power requirement
FX5642SxC: DC 12~24V, 60VA maximum, 38VA typical with 24V input.
FX5642Sx5: DC 12~24V, 88VA maximum, 64VA typical with 24V input. (All w/o riser cards).
* Dimensions
ANTENNA HDD
FX5642S0x: 252.0mm (D) x 210.0mm (W) x 77.2mm (H) w/o rubber stands and wall mounting kit.
FX5642S2x: 252.0mm (D) x 210.0mm (W) x 120.2mm (H) w/o rubber stands and wall mounting kit.
GROUND
DC IN
SYS 12~24V
COM6 COM4 COM2 -
+
10101
1
6 4 2
5 3 1
COM5 COM3 COM1
VGA
(Rear Panel)
FX5642S2x
FX5642S2x
: Celeron G3900TE (2.3GHz, 2C/2T, 2MB Cache, 1866+MHz FSB, 35 Watts)
(FX5642S2x
Page 1/3
DC IN USB COM6 COM4 COM2
10101
CARD 12V
-
+ 2 1
6 4 2
1
5 3 1
LAN2 LAN1 SLOT COM5 COM3 COM1
only)
FX5642S2x only)
only)
only)
