FabiaTech Fanless Series Manual

Hide thumbs Also See for Fanless Series:
Table of Contents

Advertisement

Quick Links

Download this manual
FabiaTech Corporation
IPC Solution
Website:
http://www.fabiatech.com
Email:
support@fabiatech.com
Small Cube System
Fanless Series
FX5408
User's Manual
i
JAN 2019
Version: 1.3
Part Number: FX5408

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fanless Series and is the answer not in the manual?

Questions and answers

Related Manuals for FabiaTech Fanless Series

Summary of Contents for FabiaTech Fanless Series

  • Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com Small Cube System Fanless Series FX5408 User’s Manual JAN 2019 Version: 1.3 Part Number: FX5408...
  • Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.

  • Page 3: Table Of Contents

    Table of Contents FX5408 User’s Manual ......................i Chapter 1 Introducing the FX5408 System ................1 Overview..........................1 Series Comparison Table .......................2 Layout............................3 Specifications..........................4 Packing List ..........................5 Chapter 2 Hardware Installation ....................7 Before Installation ........................7 To install hardware- remove the bottom Cover ..........8 　...
  • Page 4 Boot ............................46 CSM Parameters ....................48 　 Security...........................50 Save & Exit ..........................53 Chapter 4 Software Installation ....................55 Install AMD Catalyst ™ Drivers....................55 WIN XP/7 32/64 Driver....................55 Audio Driver...........................56 WIN XP/7 X86/X64 Driver ...................56 LAN Driver (RTL 8111F) ......................56 WIN XP/7 Driver X86/X64 Driver ................56 BIOS Flash Utility........................57 Watchdog Timer........................58 Watchdog Timer Setting ..................59...

  • Page 6: Chapter 1 Introducing The Fx5408 System

    FabiaTech Corporation Chapter 1 Introducing the FX5408 System Overview The FX5408 is an embedded system with AMD® G-Serial T40E Processor low-power CPU module inside. This user’s manual provides information on the physical features, installation, and BIOS setup of the FX5408.

  • Page 7: Series Comparison Table

    FabiaTech Corporation Series Comparison Table Model FX5408 System Processor AMD® G-Serial T40E 1.0 GHZ Memory DDR3L-1066 204 Pin-DIMM*2 4GB / 8GB (Max.) Audio Line-In,MIC-In and Ear-Phone Display VGA (DB-15)/ DP Multi I/O Two RS232 and Two RS232/RS422/RS485 USB 2.0 RJ45 LAN port...

  • Page 8: Layout

    FabiaTech Corporation Layout Front Panel POWER BUTTON DISPLAY MIC LINE IN CFAST HDD RESET EAR-PHONE CFAST Rear Panel DIGITAL IO COM4 COM2 DC IN D I/O DC12~24V 12~24V 10101 ANTENNA COM3 COM1 LAN2 LAN1 ANTENNA...

  • Page 9: Specifications

    FabiaTech Corporation Specifications Processor Board – AMD® G-Serial T40E 1.0 GHZ (512KB L2 Cache For Per Core) Dual Core Low Power Processor with 4GB DDR3L/1066 RAM I/O Outlets – Two 10/100/1000 base-TX Ethernet LAN port with RJ45 VGA connector with DB15...

  • Page 10: Packing List

    FabiaTech Corporation Packing List Upon receiving the package, verify the following things. Should any of the mentioned happens, contact us for immediate service. • Unpack and inspect the FX5408 package for possible damage that may occur during the delivery process.
  • Page 11 FabiaTech Corporation...

  • Page 12: Chapter 2 Hardware Installation

    FabiaTech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors & jumper settings, and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the following descriptions. 1. Before removing the cover, shut down the operation System and disconnect power cord and (or) unplug DC-In cable.

  • Page 13: To Install Hardware- Remove The Bottom Cover

    FabiaTech Corporation To install hardware- remove the bottom Cover If you are installing following hardware items, you can remove the bottom cover. The following figure will guide you how to install SATA 2.5" HDD, CFAST Compact Flash modules, mini PCIe WLAN or GPRS module, DDR3L RAM module to the FX5408 and how to install the FX5408 fixers.
  • Page 14 FabiaTech Corporation c. Installing Hard Disk Fasten screws up the Hard disk device to HDD metal frame and connect the SATA HDD cable and power cable. See following figure. c1. Fasten screw the SATA HDD M 3*P0.5 c2. Installing SATA Cable...
  • Page 15 FabiaTech Corporation d. Installing PCIe Mini Card or m-SATA Module FX5408 supports PCIe mini card socket; you may extend additional PCIe mini card module and SIM card or m-SATA module to system. Connect to the antenna cable from rear side antenna holes to GPRS or Wireless LAN module and install the SIM card for GPRS.
  • Page 16 FabiaTech Corporation e. Installing Memory: So-DIMM Socket for DDR3L RAM Modules If you may extend additional memory to system, see as following figure. The 204 pin So-DIMM socket supports 2GB to 8GB of DDR3L RAM modules. Installing memory module to So-DIMM socket of down side, when only one memory module. We recommend that installing dual channel RAM module made by the same part number and manufacturer.
  • Page 17 FabiaTech Corporation f. Installing the universal fixers Please refer to the down side figure for installing the FX5408 with universal fixers. f1. Standard Wall Mounting (See Dimension) M3*P0.5 f2. FX5407k2– Wall Mounting (See Dimension) M3*P0.5 f3. FX5403K1 – 1U Rack Mount Kit...
  • Page 18 FabiaTech Corporation f4. FX5504K1– Panel Back Mounting (VESA Mount 100*100/75*75) Kit M3*P0.5 f5. FX5407K3 – Panel mounting Kit M3*P0.5 M4*P0.7...

  • Page 19: Led Indicators

    FabiaTech Corporation LED indicators The Power button with LED and HDD LED has two distinctive statuses: Off for inactive and blinking light for activity operation. POWER BUTTON DISPLAY MIC LINE IN CFAST HDD RESET EAR-PHONE CFAST I/O Peripheral Connectors View from the rear and front side, if you are connecting the monitor, LAN, COM, Audio, GPIO, and USB to the FX5408.
  • Page 20 FabiaTech Corporation Connecting the Display port Display Port Connecting the COM ports The DB9-COM1 and COM2 are designed for multiple proposes. Its can select RS232/RS422/RS485 by BIOS CMOS setting. The following tables show the signal connections of these connectors. DB-9...
  • Page 21 FabiaTech Corporation Connecting the USB Ports The system supports a three port USB connector. Any USB device can be attached to USB ports as plug-and-play function is supported. The front side port USB #1/2 and rear side USB # 3 ~ USB#6 support USB 2.0.

  • Page 22: Connecting The Dc Power And Power Button

    FabiaTech Corporation Connecting the DC Power and Power Button Power is supplied through an external power DC In. See following figure and a side pictures. 1. DC Power Connector: Use external 2-pin apartable terminal block. DC12~24V DC +12V~+24V, 55VA minimum 2.

  • Page 23: Jumper Setting

    FabiaTech Corporation Jumper Setting JP1: Clear CMOS Setting You can use JP1 to clear CMOS data. The CMOS stores information like system date, time, boot up device, password, IRQ… which are set up with the BIOS. To clear the CMOS, set JP1 to 2-3 closed and wait 3~5 sec then return to open before system powers off.

  • Page 24: Chapter 3 Bios Setup

    FabiaTech Corporation Chapter 3 BIOS Setup This chapter describes the BIOS setup. Overview BIOS are a program located on a Flash memory chip on a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, the ISA bus and connected devices such as the video display, diskette drive, and the keyboard.

  • Page 25: Bios Functions

    FabiaTech Corporation BIOS Functions On the menu, you can perform the following functions 1. Main 2. Advanced ACPI Settings CPU Configuration IDE Configuration USB Configuration SMART Settings ITE8786 Super IO Configuration ITE8786 H/W Monitor WAKE Configuration 3. Chipset North Bridge South Bridge 4.

  • Page 26: Keyboard Convention

    FabiaTech Corporation Keyboard Convention On the BIOS, the following keys can be used to operate and manage the menu: Function [↑][↓] The Up and Down keys allow you to select item. [←][→] The Left and Right keys allow you to select screen.

  • Page 27: Main Setup

    FabiaTech Corporation Main Setup This section describes BIOS version information and basic system hardware configuration. If the CPU board is already installed in a working system, you will not need to select this option anymore. System Date & Time Setup Highlight the <Date>...

  • Page 28: Advanced Setup

    FabiaTech Corporation Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as USB Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...

  • Page 29: Acpi Settings

    FabiaTech Corporation ACPI settings This filed specifies allow you set this value to utilize the ACPI (Advanced Configuration and Power Interface) specification. Enabled ACPI Auto Configuration This item allows users to enable or disable BIOS ACPI Auto Configuration. Available Options: Disabled, Enabled...
  • Page 30 FabiaTech Corporation ACPI Sleep State This item allows users to select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Available Options: Suspend Disabled, and S1 Only (CPU Stop Clock) Default setting: S1 Only (CPU Stop Clock) Lock Legacy Resources This item allows users to enable or disable Lock of Legacy Resources.

  • Page 31: Cpu Configuration

    FabiaTech Corporation CPU Configuration The Item Display CPU Information, like CPU speed and L1/L2 cache and support function, you can use this screen to select options for the CPU information. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 32 FabiaTech Corporation PPC Adjustment This field provides to adjust _PPC objects. Available Options: PSTATE0, and PSTATE2 Default setting: PSTATE0 NX Mode This field allows the users to enable or disable the No-executed page Protection functions. Available Options: Disabled, and Enabled...

  • Page 33: Ide Configuration

    FabiaTech Corporation IDE Configuration You can use this screen to select options for the SB SATA Configuration.
  • Page 34 FabiaTech Corporation SB SATA Configuration OnChip SATA Channel This item allows users to enable or disable SATA Controller. Available Options: Disabled, and Enabled Default setting: Enabled OnChip SATA Type Select a configuration for SATA controller. Install Windows XP in AHCI mode need to use the F6 Method pre-installed AHCI driver, if you select Legacy IDE mode, you do not need to pre-install.

  • Page 35: Usb Configuration

    FabiaTech Corporation USB Configuration You can use this screen to select options for the USB Configuration. Legacy USB Support Legacy USB Support refers to the USB mouse and USB keyboard support. Normally if this option is not enabled; any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.
  • Page 36 FabiaTech Corporation USB Mass Storage Driver Support Mass storage device emulation type. If the emulation FDD, recommended formatted as FAT32 format. Available Options: Disabled, and Enabled Default setting: Enabled USB transfer time-out The time-out value for control, bulk, and interrupt transfers.
  • Page 37 FabiaTech Corporation Device power-up delay > Select “Manual“ Device Power-Up delay in second Delay range is 1...40 seconds, in one second increments Available Options: 1, 5, 10, 20, 30, and 40 Sec Default setting: 5 Sec Generic Storage Device 1.01 Mass storage device emulation type.

  • Page 38: It8786 Super Io Configuration

    FabiaTech Corporation IT8786 Super IO Configuration This section describes the function of Super I/O settings. Serial Port 0/ Port 1 Configuration These fields select the I/O port address for Serial port 0 and port 1.
  • Page 39 FabiaTech Corporation Serial Port 0/1 This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled. Default setting: Enabled Device Settings Serial Port0: IO=3F8; IRQ=IRQ4; Serial Port1: IO=2F8; IRQ=IRQ3 Transfer Mode Setting This item allows users can select RS-232, RS-422 and RS-485 of select COM1/COM2.
  • Page 40 FabiaTech Corporation Serial Port 2/3 Configuration Serial Port 2/3 This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled. Default setting: Enabled Device Settings Serial Port2: IO=3E8; IRQ=IRQ11; Serial Port3: IO=2E8; IRQ=IRQ10;...

  • Page 41: Hardware Health Configuration

    FabiaTech Corporation Hardware Health Configuration On the Hardware Monitor Setup screen, you can monitor the system temperature1, System voltage, and VBAT voltage…...

  • Page 42: Wake Configuration

    FabiaTech Corporation Wake Configuration Onboard PCIE LAN PXE ROM This field specifies the PXE boot ROM of the onboard LAN chip. Available Options: Disabled, and Enabled Default setting: Disabled Wake ON Lan This item is can select Enabled to integrated LAN to wake up the system.

  • Page 43: Realtek Pcie Gbe Family Controller (Mac)

    FabiaTech Corporation Realtek PCIe GBE Family Controller (MAC) On the LAN Information screen, you can see the LAN Chipset information, when setting the Launch PXE OpROM Policy to UEFI Only of CSM Boot.

  • Page 44: Chipset

    FabiaTech Corporation Chipset This section describes the configuration of the board’s chipset features. • North Bridge • South Bridge...

  • Page 45: North Bridge

    FabiaTech Corporation North Bridge You can use this screen to select options for the Host Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 46 FabiaTech Corporation Memory Configuration Integrated Graphics This field specifies allows you to select the Video Device which will be activated during POST. Available Options: Auto, Disabled, and Force. Default setting: Auto UMA Frame buffer Size When Integrated Graphics selected to “Focus”, User can select graphics memory size used by the internal graphics device.
  • Page 47 FabiaTech Corporation Socket 0 Information On the Socket 0 Information screen, you can see the system memory information.

  • Page 48: South Bridge

    FabiaTech Corporation South Bridge You can use this screen to select options for the South Bridge Configuration. South Bridge is a chipset on the motherboard that controls the USB, and audio function. Restore On AC Power Lose This field specifies the option controls how the PC will behave once power is restored following a power outage (or other unexpected or ungraceful shutdown).
  • Page 49 FabiaTech Corporation USB Configuration OHCI HC (Bus 0 Dev 18/19/22/20 FN 0/5) The USB OHCI HOST Control each of the USB ports (0~5). Enable: Enable USB 0/1, 2/3, 4/5 port; Disable: Use USB port 0/1, 2/3, 4/5 settings Available Options: Disabled, and Enabled...
  • Page 50 FabiaTech Corporation Azalia HD Audio Audio Controller This item allows users to enable or disable Azalia Controller. Available Options: Auto, Disabled, and Enabled Default setting: Enabled...

  • Page 51: Boot

    FabiaTech Corporation Boot Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Device Priority, to go to the sub menu for that item. You can display a Boot BIOS Setup option by highlighting it using the <Arrow>...
  • Page 52 FabiaTech Corporation Quiet Boot This item allows users to enable or disable Quiet boot option. If Enable, an OEM LOGO is shown instead of POST messages. Available Options: Disabled, and Enabled Default setting: Disabled Fast Boot This field is used to activate the fast boot function of the system. When set to Enabled, boot with initialization of a minimal set of devices required to launch active boot option.

  • Page 53: Csm Parameters

    FabiaTech Corporation Note: When you select a boot Option category from the boot menu, a list of devices in that category appears. For example, if the system has hard disk drives and USB storage connected, then the list will show all hard disk drives attached.
  • Page 54 FabiaTech Corporation Launch PXE OpROM Policy This option Controls the execution of UEFI and Legacy PXE OpROM. Available Options: Do not Launch, Legacy only, UEFI only, Leach First and UEFI First. Default setting: Do not Launch Launch Storage OpROM Policy This option Controls the execution of UEFI and Legacy Storage OpROM.

  • Page 55: Security

    FabiaTech Corporation Security Security Setup provides both Administrator and User password. If you use both passwords, the Administrator password must be set first. The system can be configured so that all users must enter a password every time the system boots or when Setup is executed, using either the Administrator password or User password.
  • Page 56 FabiaTech Corporation Clear Old Password Select Administrator/user password item, press <Enter> and type current password, at the next dialog press <Enter> to Clear Old Password.
  • Page 57 FabiaTech Corporation HDD Security Configuration Customizable HDD Password Secure Boot settings, when HDD/SSD device is support.

  • Page 58: Save & Exit

    FabiaTech Corporation Save & Exit Save Changes and Exit When you have completed the system configuration changes, select this option to save the changes and Exit, so the new system configuration parameters can take effect. Discard Changes and Exit Select this option to quit without making any modifications to the system configuration.
  • Page 59 FabiaTech Corporation Discard Changes and Reset Select this option to reboot the system without saving the changes done in the setup configuration. Save Changes When you have completed the system configuration changes, select this option to save your system configuration and continue. For some of the options it required to reset the system to take effect.

  • Page 60: Chapter 4 Software Installation

    FabiaTech Corporation Chapter 4 Software Installation The enclosed CD diskette includes FX5408 VGA, System, Audio, and LAN driver. To install and configure you FX5408 system, you need to perform the following steps. Install AMD Catalyst ™ Drivers WIN XP/7 32/64 Driver To install the AMD T40E driver, insert the DVD ROM into the USB DVD ROM device, and enter DRIVER>VGA>AMD_T40E>WINXP, or >WIN7.

  • Page 61: Audio Driver

    FabiaTech Corporation Step 9: The AMD - Catalyst Install Manager will analyze the system, and install the required files. Step10: The AMD - Catalyst Install Manager will confirm when the installation is complete. Click Finish. Step11: When prompted, Click Yes to restart the system and complete the installation process.

  • Page 62: Bios Flash Utility

    FabiaTech Corporation BIOS Flash Utility In the <UTILITY> directory, there is the AFU301.EXE file. Step 1: Use the AFU301.EXE xxxxxVxx.rom program to update the BIOS setting. Step 2: And then refer to the chapter “BIOS Setup”, as the steps to modify BIOS.

  • Page 63: Watchdog Timer

    FabiaTech Corporation Watchdog Timer This section describes how to use the Watchdog Timer, including disabled, enabled, and trigger functions. The FX5408 is equipped with a programmable time-out period watchdog timer. You can use your own program to Enabled the watchdog timer. Once you have enabled the watchdog timer, the program should trigger the I/O every time before the timer times out.

  • Page 64: Watchdog Timer Setting

    FabiaTech Corporation Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. The watchdog timer is automatically disabled after reset. Once you have enabled the watchdog timer, your program must trigger the watchdog timer every time before it times out.

  • Page 65: Watchdog Timer Enabled

    FabiaTech Corporation Watchdog Timer Enabled To enable the watchdog timer, you have to output a byte of timer factor to the watchdog register whose address is 2eh and data port is 2fH. The following is a Demo program, which demonstrates how to enable the watchdog timer and set the time-out period at 28 seconds.

  • Page 66: Digital I/O (Gpio) Programming

    FabiaTech Corporation Digital I/O (GPIO) programming The following is Demo program, which demonstrates how to read and write the data of GPIO. ;---------------------------------------------------------------------------------------------------------------- ; Configuration the Digital IO port is A06h-(GPO) Bit0, Bit1/ (GPI) Bit 4, Bit 5, ; A06h-Bit0/Bit1 (GPO-0 / GPO-1, Write data) When set to a “1”, respective GPO port is programmed as ‘High’.
  • Page 67 FabiaTech Corporation...

  • Page 68: Chapter 5 Technical Reference

    FabiaTech Corporation Chapter 5 Technical Reference This section outlines the errors that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Technical Reference Dimension Technical Reference Physical and Environmental Temperature: Operating -20°C ~ 60°C Relative humidity 5 % to 95 % non-condensing Surface Temperature of Chassis：...

  • Page 69: Serial Ports

    FabiaTech Corporation Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits.
  • Page 70 FabiaTech Corporation Bit 1: Enable Transmitter Holding Empty Interrupt (ETBEI) Bit 2: Enable Receiver Line Status Interrupt (ELSI) Bit 3: Enable MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0...
  • Page 71 FabiaTech Corporation Bit 5: Stick Parity Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB) MODEM Control Register (MCR) Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2)
  • Page 72 FabiaTech Corporation Bit 4: Clear to Send (CTS) Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1...

  • Page 73: Appendix

    FabiaTech Corporation Appendix Dimension a. FX5408 R4.5 R2.5 213(REF) 226(REF)
  • Page 74 FabiaTech Corporation b. FX5407k2 R4.5 R2.25 217(REF) 231(REF)
  • Page 75 FabiaTech Corporation c. FX5407k3 39(REF) 50(REF) 12.5 67(REF) 12.5...
  • Page 76 FabiaTech Corporation d. FX5403k1 31.8 44.2...
  • Page 77 FabiaTech Corporation e. FX5504k1 50(REF) 63.2(REF) 12.5 R2.75...
