- Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com Small Cube System Fanless Series FX5622 User’s Manual JUNE 2008 Version: 1.0 Part Number: FX5622...
- Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.
-
Page 3: Table Of Contents
Table of Contents FX5622 User’s Manual ................... i Chapter 1 Introducing the FX5622 System........... 1 Overview..........................1 Series Comparison Table .......................2 Layout............................3 Specifications..........................4 Packing List ..........................5 Chapter 2 Hardware Installation ..............7 Before Installation ........................7 Removing Covers –Installing Hardware............8 LED Indicators (On the Front Panel)...............12 ... - Page 4 Hard Disk Drives ....................36 Security setup........................37 Chipset Setup........................39 North Bridge Configuration ................39 South Bridge Configuration ................40 Power Manager ....................41 Chapter 4 Software Installation ..............43 System Driver .........................43 WIN 2000/XP Driver.....................43 VGA Driver for 2000/XP......................44 LAN Driver ..........................45 WIN 2000/XP Driver.....................45 BIOS Flash Utility........................45 Watchdog Timer........................46...
-
Page 6: Chapter 1 Introducing The Fx5622 System
FabIATech Corporation Chapter 1 Introducing the FX5622 System Overview The FX5622 is a compact size embedded system with Intel low-power CPU board inside. This user’s manual provides information on the physical features, installation, and BIOS setup of the FX5622. Built to unleash the total potential of the Intel Celeron-M Processor, Able to support 1GHz CPU, this system supports four 10/100M Base–TX and four 10/100/1000 Base–TX... -
Page 7: Series Comparison Table
FabIATech Corporation Series Comparison Table Model FX5622 Processor Intel Celeron-M 1GHz Chipset Intel 82910GMLE 2-DIMM (Max.) 1GB/2GB Watchdog Timer Multi I/O One RS232 Enhanced IDE or CF USB 2.0 RJ45 ports (1Gbps) Four RJ45 Ports (100Mbps) Four * LAN Bypass Function... -
Page 8: Layout
FabIATech Corporation Layout POWER ACTIVE Power Active Link GIGA 10/100M Status GIGA LAN STATUS LINK RESET ANTENNA ANTENNA 10/100M GIGA Antenna Antenna GIGA LAN DC IN SWITCH... -
Page 9: Specifications
FabIATech Corporation Specifications Processor Board – Intel Celeron-M 1GHz CPU with 1GB DDR2 RAM. I/O Outlets – Four 10/100 base-TX and Four 10/100/1000 Base–TX Ethernet ports. Two USB ports (V2.0) and One RS232 Port. One Mini PCI Socket for mini-PCI module. -
Page 10: Packing List
FabIATech Corporation Packing List Upon receiving the package, verify the following things. Should any of the mentioned happens, contact us for immediate service. • Unpack and inspect the FX5622 package for possible damage that may occur during the delivery process. - Page 11 FabIATech Corporation...
-
Page 12: Chapter 2 Hardware Installation
FabIATech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors & jumper settings, and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the following descriptions. 1. Before removing the cover, shut down the operation System and disconnect power switch to off and unplug AC-to DC Adapter cable. -
Page 13: Removing Covers -Installing Hardware
FabIATech Corporation Removing Covers –Installing Hardware If you are installing hardware option, you can remove the bottom cover. The following figure will guide you how to install SATA or PATA 2.5" HDD inside, Compact Flash modules, mini PCI WLAN module and DDR-RAM module the FX5622 and how to install the FX5622 fixers. - Page 14 FabIATech Corporation a2. Installing PATA or SATA Cable CN11 Note: Use caution when handling the hard disk to prevent damage to IDE connector as you insert hard disk. 1. Be careful with the pin orientation when installing connectors and the cables. A wrong connection can easily destroy your hard disk.
- Page 15 FabIATech Corporation b. Installing Compact Flash CN12 Note: The Compact Flash socket (on the FX5622) supports 3.3V Compact Flash and Micro Drives. c. Installing Memory: DIMM Socket For DDR2 Modules You may extend additional memory to FX5622, See as following figure and rear pictures.
- Page 16 FabIATech Corporation d. Installing Mini PCI Card: Mini PCI Socket for WLAN Modules You may extend additional mini PCI WLAN module to FX5622 by removing the bottom cover. Connect the antenna cable from backside antenna hole to Mini PCI WLAN (the auxiliary board). (Please see the spots circled.) e.
-
Page 17: Led Indicators (On The Front Panel)
FabIATech Corporation e2. FX5504K1 universal fixers. LED Indicators (On the Front Panel) The Power/Watchdog LED, HDD LED and Status LED’s have two distinctive statuses: Off for inactive operation and blinking light for activity. And the 16 LED’s for LAN ports. The down side LED (Orange) indicates data is being accessed and the up side LED’s (Green) indicates on-line status. -
Page 18: Connecting The Usb Ports And Com Port (On The Front Panel)
FabIATech Corporation Connecting the USB Ports and COM Port (On the Front Panel) To connector the peripheral USB devices and RS232 to the FX5622, refer to the following procedure. a. Connecting COM Port The DB9 (COM1) is standard serials port connector. The following tables show the signal connections of these connectors. - Page 19 FabIATech Corporation a. Connecting the LAN Ports The LAN ports are RJ45 connectors with 2 LEDs. The right side LED (orange) indicates data is accessing and the left side LED (green) indicates on-line status. (When lighted indicates on-line and off indicates off-line). The LANI ~ LANIV is the 10/100/1000 base-TX port and others are 10/100 base-TX ports.
-
Page 20: Jumper Setting
FabIATech Corporation c. Reset Push button The Reset push button is switcher for system reset; Push and release the button will cause hard ware reset of FX5622 and restart system booting. Reset Push Button: Restart Jumper Setting The JP2 is used to select master/slave device of this Compact Flash socket. And use JP1 to clear CMOS data, to clear the CMOS, set JP1 to 2-3 and then return to 1- 2 before system powers off. -
Page 21: Crt Display
FabIATech Corporation CRT Display The following table and figure illustrate the pin definition of CN12 and D-sub 15-pin on the CRT adapter cable: CN12 DB15 CN12 Signal DB-15 PIN Signal DB15 VGA Sensor GREEN Ground 5,10 BLUE Ground 6,8,Case VSYNC... -
Page 22: Chapter 3 Bios Setup
FabIATech Corporation Chapter 3 BIOS Setup This chapter describes the BIOS setup. Overview BIOS are a program located on a Flash memory chip on a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, the ISA bus and connected devices such as the video display, diskette drive, and the keyboard. -
Page 23: Bios Functions
FabIATech Corporation BIOS Functions On the menu, you can perform the following functions 1. Main 2. Advanced CPU Configuration IDE Configuration SuperIO Configuration Hardware Health Configuration Remote Access Configuration USB Configuration 3. PCIPnP 4. Boot Boot Settings Configuration Boot Device Priority Hard Disk Drives 5. -
Page 24: Keyboard Convention
FabIATech Corporation South Bridge Configuration 7. Power 8. Exit Save Changes and Exit: Exit system setup after saving the changes.F10 key can be used for this operation. Discard Changes and Exit: Exit system setup without saving any changes. ESC key can be used for this operation. -
Page 25: Main Setup
FabIATech Corporation Main Setup This section describes basic system hardware configuration, system clock setup and BIOS version information. If the CPU board is already installed in a working system, you will not need to select this option anymore. System Memory This option is display-only which is determined by POST (Power On Self Test) of the BIOS. -
Page 26: Advanced Setup
FabIATech Corporation Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... -
Page 27: Ide Configuration
FabIATech Corporation IDE Configuration You can use this screen to select options for the ATA/IDE Configuration Settings. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. A description of the selected item appears on the right side of the screen. - Page 28 FabIATech Corporation Default setting: SATA Pri, PATA_Sec Configure SATA as This field is when set to Enhanced mode; you can select the IDE or AHCI. Available Options: IDE, and AHCI Default setting: IDE IDE Primary/Secondary Master/Slave IDE hard drive controllers can support up to two separate hard drives. These drives have a master/slave relationship, which is determined by the cabling configuration used to attach them to the controller.
-
Page 29: Superio Configuration
FabIATech Corporation Hard Disk Write Protect Set this option to protect the hard disk drive from being overwritten. The Optimal and Fail-Safe default setting is Disabled. Available Options: Disabled, Enabled Default setting: Disabled IDE Detect Time Out (Sec.) Set this option to stop the AMIBIOS from searching for IDE devices within the specified number of seconds. -
Page 30: Hardware Health Configuration
FabIATech Corporation KBC Clock Rate Selection This field is select Keyboard clock rate selecting 6MHz/8MHz/12MHz/16MHz Controller. Available Options: 6MHz, 8MHz , 12MHz and 16MHz Default setting: 8MHz Serial Port 1 Address These fields select the I/O port address for each Serial port. -
Page 31: Remote Access Configuration
FabIATech Corporation Remote Access Configuration This option turns on remote access support in the BIOS and is the default setting. The remote access feature requires the use of the serial port1 connector located at the front panel of the FX5622. - Page 32 FabIATech Corporation Available Options: 3F8, 4 Default setting: 3F8, 4 Serial Port Mode This field is select Serial port1 can use any mode. Just keep in mind that the bits per second, data bits, parity, and stop bits must match terminal setting.
-
Page 33: Usb Configuration
FabIATech Corporation USB Configuration You can use this screen to select options for the USB Configuration. Legacy USB Support Legacy USB Support refers to the USB mouse and USB keyboard support. Normally if this option is not Enabled; any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded. - Page 34 FabIATech Corporation BIOS ECHI Hand-Off This is a workaround for OS without ECHI Hand-Off support. The ECHI ownership change should claim by ECHI driver. Available Options: Enabled and Disabled Default setting: Disabled Hotplug USB FDD Support This field is a dummy FDD device is created that will be associated with the hot plugged FDD latter Auto Option creates this dummy device only if there is no USB FDD present.
-
Page 35: Pcipnp Setup
FabIATech Corporation PCIPnP Setup Select the PCI/PnP tab from the setup screen to enter the Plug and Play BIOS Setup screen. You can display a Plug and Play BIOS Setup option by highlighting it using the <Arrow> keys. All Plug and Play BIOS Setup options are described in this section. The Plug and Play BIOS Setup screen is shown below. - Page 36 FabIATech Corporation PCI IDE BusMaster This option is to specify that the IDE controller on the PCI local bus have bus-mastering capability. Available Options: Enabled, Disabled Default setting: Disabled IRQ 3 –15 When I/O resources are controlled manually, you can assign each system interrupt...
-
Page 37: Boot Setup
FabIATech Corporation Boot Setup Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Device Priority, to go to the sub menu for that item. You can display a Boot BIOS Setup option by highlighting it using the <Arrow>... -
Page 38: Boot Setting Configuration
FabIATech Corporation Boot Setting Configuration Quick Boot This field is used to activate the quick boot function of the system. When set to Enabled, 1. BIOS will not wait for up to 40 seconds if a Ready signal is not received from the IDE drive, and will not configure its drive. - Page 39 FabIATech Corporation Available options: On, Off Default setting: On PS/2 Mouse Support The setting of Auto or Enabled allows the system to detect a PS/2 mouse on boot up. If detected, IRQ12 will be used for the PS/2 mouse. IRQ 12 will be reserved for expansion cards if a PS/2 mouse is not detected.
-
Page 40: Boot Device
FabIATech Corporation Boot Device Use this screen to specify the order in which the system checks for the device to boot from. To access this screen, select Boot Device Priority on the Boot Setup screen and press <Enter>. First /Second /Third Hard Disk Boot Device Set the boot device options to determine the sequence in which the computer checks which device to boot from. -
Page 41: Hard Disk Drives
FabIATech Corporation Hard Disk Drives Use this screen to view the hard disk drives in the system. To access this screen, select Hard disk drives on the Boot Setup screen and press <Enter>. -
Page 42: Security Setup
FabIATech Corporation Security setup There are two security passwords: Supervisor and User. Supervisor is a privileged person that can change the User password from the BIOS. According to the default setting, both access passwords are not set up and are only valid after you set the password from the BIOS. - Page 43 FabIATech Corporation 5. Select System or Setup. Aways: a visitor who attempts to enter BIOS or operating system will be prompted for password. Setup: a visitor who attempts to the operating system will be prompted for user password. You can enter either User password or Supervisor password.
-
Page 44: Chipset Setup
FabIATech Corporation Chipset Setup This section describes the configuration of the board’s chipset features. • NorthBridge Configuration • SouthBridge Configuration North Bridge Configuration You can use this screen to select options for the North Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. -
Page 45: South Bridge Configuration
FabIATech Corporation Configuration DRAM Timing by SPD DRAM Timing If the installed SDRAM supports SPD function, select Enabled. If not, you can select based on other access time of the SDRAM. Available Options: Enabled and Disable Default setting: Enabled Internal Graphics Mode Select This field is share memory architecture (SMA) for frame buffer memory. -
Page 46: Power Manager
FabIATech Corporation LAN Boot ROM1/ROM2 Controller This field specifies the PXE boot ROM of the onboard LAN chip. Available Options: Disabled, Enabled Default setting: Disabled Power Manager Power Management/APM Select Enabled to activate the chipset Power Management and APM (Advanced Power Management) features. - Page 47 FabIATech Corporation...
-
Page 48: Chapter 4 Software Installation
FabIATech Corporation Chapter 4 Software Installation The enclosed diskette includes FX5622 VGA, Audio, USB, System and LAN driver. To install and configure you FX5622 system, you need to perform the following steps. System Driver WIN 2000/XP Driver Installs 915GME or 910GMLE Chipset, IRQ Routing, USB, AGP Driver and ISA IDE Bus Master Drive. -
Page 49: Vga Driver For 2000/Xp
FabIATech Corporation VGA Driver for 2000/XP Step 1: To install the VGA driver, insert the CD ROM into the CD ROM device, and enter DRIVER>VGA>915GME>2KXP. Step 2: Execute SETUP.EXE file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu. -
Page 50: Lan Driver
FabIATech Corporation LAN Driver WIN 2000/XP Driver To install the LAN utility OR driver, insert the CD ROM into the CD ROM device, and enter DRIVER>LAN>82573L>2KXP. If your system is not equipped with a CD ROM device, copy the LAN driver from the CD ROM to CF. -
Page 51: Watchdog Timer
FabIATech Corporation Watchdog Timer This section describes how to use the Watchdog Timer, including disabled, Enabled, and trigger functions. The FX5622 is equipped with a programmable time-out period watchdog timer. You can use your own program to Enabled the watchdog timer. Once you have Enable the watchdog timer, the program should trigger the I/O every time before the timer times out. -
Page 52: Watchdog Timer Setting
FabIATech Corporation Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. LED1 on this CPU board is the watchdog timer indicator, which is located at the upper-left corner above the USB connector. -
Page 53: Watchdog Timer Enabled
FabIATech Corporation Watchdog Timer Enabled To Enabled the watchdog timer, you have to output a byte of timer factor to the watchdog register whose address is 2Eh and data port is 2fH. The following is an Assemble program, which demonstrates how to Enabled the watchdog timer and set the time-out period at 28 seconds. -
Page 54: Watchdog Timer Disabled
FabIATech Corporation Watchdog Timer Disabled To disable the watchdog timer, simply write a 00H to the watchdog register. ;------------------------------------------------------------------------------------------ ; Enter the extended function mode, interruptible double-write ;------------------------------------------------------------------------------------------ dx,2eh ; Enter to extended function mode al,87h dx,al dx,al ;------------------------------------------------------------------------------------------------------------------------ ; Logical device 8, configuration register CRF5 Bit 3(Sec./Min.), CRF6 Bit 0~7 (Count.) ;-------------------------------------------------------------------------------------------------------------------------... -
Page 55: Lan By-Pass Programming
FabIATech Corporation LAN By-pass Programming The FX5622 can defined the normal or by pass function of LAN3 & LAN4. When I/O Port 2Eh/2Fh, device 8, index F1 Bit 0 is set to1 is normal mode, the LAN3 & LAN4 is active. -
Page 56: Status Led Programming
FabIATech Corporation Status LED Programming The FX5622 can define the Status LED to Light/Blinking. When I/O Port 2Eh/2Fh, device 9, index F3 Bit 6 & bit7 is set to 0 the Status LED is active, if bit 6 set to 1 the status LED is not active. - Page 57 FabIATech Corporation...
-
Page 58: Chapter 5 Technical Reference
FabIATech Corporation Chapter 5 Technical Reference This section outlines the errors that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Trouble Shooting for Error Messages Technical Reference Trouble Shooting for Post Beep and Error Messages The following information informs the Post Beep &... - Page 59 FabIATech Corporation CMOS CHECKSUM ERROR This error informs that the CMOS has corrupted. When the battery runs weak, this situation might happen. Please check the battery and change a new one when necessary. DISK BOOT FAILURE When you can‘t find the boot device, insert a system disk into Drive A and press <...
- Page 60 FabIATech Corporation MEMORY SIZE HAS CHANGED Memory has been added or removed since last boot. In EISA mode, use Configuration Utility to re-configure the memory configuration. In ISA mode enter BIOS Setup and enter the new memory size in the memory fields.
-
Page 61: Technical Reference
FabIATech Corporation Technical Reference Physical and Environmental Temperature: Operating 0°C ~ 50°C Relative humidity 5 % to 95 % non-condensing DC-AC adapter Input AC Voltage Range: 100V~240V/1.5A, 50Hz ~60Hz Output DC Voltage: 19V/3.42A Maximal Surface Temperature of Chassis： 5°C to 45°C (W/HDD)/0°C to 50°C (W/CF card only) - Page 62 FabIATech Corporation Address Description Status register C Status register D Diagnostic status byte Shutdown status byte Diskette drive type byte, drive A and B Fixed disk type byte, drive C Fixed disk type byte, drive D Reserved Equipment byte Low base memory byte...
-
Page 63: Cmos Ram Map
FabIATech Corporation CMOS RAM Map Register Description 00h -10h Standard AT-compatible RTC and Status and Status Register data definitions 11h – 13h Varies Equipment Bits Number of Floppy Drives 1 Drive 2 Drives Bits Monitor Type Not CGA or MDA 01 40x25 CGA... -
Page 64: I/O Port Address Map
FabIATech Corporation I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses, which also becomes the identity of the device. There is a total of 1K-port address space available. The following table lists the I/O port addresses used on the Industrial CPU Card. -
Page 65: Interrupt Request Lines (Irq)
FabIATech Corporation Interrupt Request Lines (IRQ) There are a total of 15 IRQ lines available on the Industrial CPU Card. Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on the Industrial CPU Card. -
Page 66: Dma Channel Map
FabIATech Corporation DMA Channel Map The equivalent of two 8237A DMA controllers is implemented in the FX5622 board. Each controller is a four-channel DMA device that will generate the memory addresses and control signals necessary to transfer information directly between a peripheral device and memory. -
Page 67: Serial Ports
FabIATech Corporation Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits. - Page 68 FabIATech Corporation Bit 1: Enabled Transmitter Holding Empty Interrupt (ETBEI) Bit 2: Enabled Receiver Line Status Interrupt (ELSI) Bit 3: Enabled MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0...
- Page 69 FabIATech Corporation Bit 5: Stick Parity Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB) MODEM Control Register (MCR) Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2)
- Page 70 FabIATech Corporation Bit 4: Clear to Send (CTS) Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1...
-
Page 71: Dimension
FabIATech Corporation Dimension a. FX5622... - Page 72 FabIATech Corporation b. FX5501K1...
- Page 73 FabIATech Corporation c. FX5504K1 universal fixers...
