Parameter
ID
P 00 DHW max
P 01 Min C.H.
P 02 Central heating max
P 03 Relay 1 (optional)
P 04 Relay 2 (optional)
P 05 Relay 3 (optional)
P 07 External probe correction
Gen. thermal DHW setpoint
P 11
offset
DHW electric resistance
P 12
tripping offset
P 23 Heat setpoint correction
P 24 Cool setpoint correction
Description
Defines the maximum heat output percentage of
the heat generator during the D.H.W. phase
compared to the maximum heat output available
Defines the minimum heat output percentage of
the heat generator during the C.H. phase compa-
red to the maximum heat output available
Defines the minimum heat output percentage of
the heat generator during the C.H. phase compa-
red to the maximum heat output available
The hydronic module is set up to operate with a
configurable relay board (optional)
0 = Off
1 = DHW recirculation
2 =General alarm
3 = Central heating / cooling mode active
4 = Puffer mode active
5 = Dehumidifier zone 3
The hydronic module is set up to operate with a
configurable relay board (optional)
0 = Off
1 = DHW recirculation
2 =General alarm
3 = Central heating / cooling mode active
4 = Puffer mode active
5 = Zone 3 mixing valve closing
The hydronic module is set up to operate with a
configurable relay board (optional)
0 = Off
1 = DHW recirculation
2 =General alarm
3 = Central heating / cooling mode active
4 = Puffer mode active
5 = Zone 3 mixing valve opening
If the reading of the external probe is not accurate,
it is possible to correct it in order to compensate
any environmental factors
The DHW flow setpoint of the thermal generator is
calculated by adding P011 to the DHW setpoint
Call Immergas technical service assistance
Allows to correct the heating mode demand
setpoint in presence of dispersions or system
decoupling circuits
Allows to correct the cooling mode demand
setpoint in presence of dispersions or system
decoupling circuits
Customised
Range Default
0 - 100 % 100 %
0 – P 02 % 0
0 - 100 % 85 %
0 ÷ 5 0
0 ÷ 5 0
0 ÷ 5 0
-9 ÷ 9 K 0
2 ÷ 30 °C 20
5 ÷ 50 °C 10
0 ÷ 10°C 0
0 ÷ 10°C 0
value
