1.3 MAIN DIMENSIONS
1.4 MINIMUM INSTALLATION DISTANCES
Key (Fig. 2):
V - Electric connection
G - Gas supply
AC - Domestic hot water outlet
AF - Domestic hot water inlet
SC - Condensate
diameter Ø 13 mm)
R - System return
M - System flow
LP - Chiller line - liquid phase
GP - Chiller line - gaseous phase
Height
(mm)
787
CONNECTIONS
LINE
CHILLER LINE
LP GP
SAE 1/4" SAE 5/8" 3/4"
2
Key (Fig. 3):
3
drain (minimum internal
Width Depth
(mm) (mm)
440 400
DOMESTIC
GAS HOT SYSTEM
WATER
G AC - AF R - M
1/2" 3/4"
A - 450 mm
B - 350 mm
C - 30 mm
D - 30 mm
E - 350 mm
