- Page 1 3141 en - 02.1999 / a X20 – 30 – 36 AC GEARLESS Installation and maintenance...
- Page 2 Installation, servicing and maintenance must only be of ordering. carried out by a qualified member of staff. LEROY-SOMER cannot be held responsible for any problems arising from failure to comply with the 4 - COMMISSIONING instructions in this manual.
-
Page 3: Installation
LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS 4.2 - Installation Incorrect lifting methods may be dangerous for Motors should be installed in a location where cooling air personnel and may cause serious damage to the (which must be low in humidity, free of dust, steam and machine. -
Page 4: Brake Adjustment
LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS 4.5 - Brake adjustment Release the mechanical system which immobilized the car before the adjustments. Before carrying out the adjustments, disconnect the brake supply. -
Page 5: Ordering Spare Parts
LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS 5.2.1 - Every month 5.2.3 - Every year - Check for loose bolts, nuts or electrical connections. - Motor bearing (NDE) maintenance : open drain plug (363). -
Page 6: Part List
LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS SHEAVE LUBRICATING-POINT Secondary sheave Rep. Designation Square head plug PART LIST Rep. Designation Rep. Designation Sheave and drum Torque adjustment counter nut Brake arm... - Page 7 LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS DRAWINGS Fig. 5...
- Page 8 LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS Fig. 6...
- Page 9 LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS...
- Page 10 LEROY-SOMER INSTALLATION AND MAINTENANCE 3141 en - 02.1999/ a X20 – 30 – 36 – AC GEARLESS...
- Page 12 LEROY-SOMER 16015 ANGOULÊME CEDEX - FRANCE RCS ANGOULÊME N° B 671 820 223 S.A. au capital de 62 779 000 www.leroy-somer.com...
