- Page 1 Réf. 3377 GB - 4.33 / a - 09.00 X2 X3 - AC Gearless Installation and maintenance...
- Page 2 X2 - X3 - AC Gearless Receipt - Storage Commissioning 3. - ENVIRONMENT In order to obtain complete satisfaction with your new LEROY–SOMER gearless machine, it is important to Rated characteristics for these motors are given for a comply with the following instructions.
- Page 3 X2 - X3 - AC Gearless Commissioning 4.2.2 - Mechanical installation - The gearless machine must be installed on a bed-plate not subject to vibrations, and must be secured by four M20 bolts,nuts, and washers. The bolts must be secured only when ropes, car, counter-weight, traction sheave and secondary sheave are perfectly aligned.
- Page 4 X2 -X3 - AC Gearless Commissioning ∆ ∆ 4.3.1 - Brake adjustment 4.3.2 - Definitions and limits x : Plunger stroke travel. 4.3.4 - Plunger stroke adjustment : Torque adjust screw lengh when brake lining are - Unlock counter nut 56.
- Page 5 Bolts and nuts tightening Noise & vibration inspection Brake spring and stroke inspections Greasing secondary sheave X2 - X3 - AC Gearless Ordering spare parts 6. - ORDERING SPARE PARTS - quantity ordered To ensure efficient after-sales service, each order for...
- Page 6 X2 - X3 - AC Gearless Brake system Part list* Rep. Designation Rep. Designation Brake arm Torque adjustment counter nut Torque adjustment screw Stroke adjustment screw Torque adjustment spring Stroke adjustment counter nut Torque adjustment nut Plunger axle Brake manual release lever...
- Page 7 X2 - X3 - AC Gearless Part list* Rep. Designation Sheave and drum Brake arm Torque adjustment spring Brake manual release lever Lining Brake terminal box Motor terminal box...
