- Page 1 " " " % &! #! " ' Copyright 2003-2008 © Transpak Equipment Corp. All rights reserved. last updated; August 19, 2008...
- Page 2 Automatic Strapping Machine TP-6000 Q&A CONTENTS The machine does not work ...................... 2 Strap does not reach the sealing point (strap returns to the accumulation box while strapping)2 III. There is excessive or insufficient strap in the accumulator box to make the machine fail to feed............................
- Page 3 Automatic Strapping Machine TP-6000 Q&A The machine does not work (a) Check if the power cord is plugged in the socket and check if the socket is with power. (b) Check if the power wire or Main Power Switch (T6-6-40010/T6-6-30011) is broken.
- Page 4 Automatic Strapping Machine TP-6000 Q&A (f) The clearance between T6-1-10171 Gear Box Pulley and T6-6-10180 Magnet Brake is too large. The clearance should be 0.15-0.25 mm{Refer to the following drawing} T6-1-10171 (g) The Magnet Brake (T6-6-10180) is defective, or its connecting wire is loose. The fuse for Magnet Brake (BRK) is burnt.
- Page 5 Automatic Strapping Machine TP-6000 Q&A (k) K-Type Guide Rail Hinge Shaft (T6-2-20220) is falling off or the Arch Guide Rail Spring (T6-2-21250) is stretched, loose or broken. Strap would be out from the arch in these situations. The flaps of LH Bandway Ass' y (T6-2-12000) or RH Bandway Ass' y (T6-2-11000) can not close and causes the strap to go out from the bandway.
- Page 6 Automatic Strapping Machine TP-6000 Q&A III. There is excessive or insufficient strap in the accumulator box to make the machine fail to feed (a) Please check the adjustment for “Amount of strap in Accumulator Box” based on manual Part I P10.
- Page 7 Automatic Strapping Machine TP-6000 Q&A (e) The screw HBS0620S of Slide Table (T6-1-20130) is loose. (f) The position of RH Bandway Ass' y (T6-2-11000) is too forward or too backward. This results in the sealing joint area being too small and being apart. Adjust the assembling of the bandway to increase the sealing joint area.
- Page 8 Automatic Strapping Machine TP-6000 Q&A (c) V-Belt, M-22 (T6-1-70111/T6-1-70112) of M2 motor is worn or the bearing (BR6202ZZ) on Feed Roller (T6-1-71140) gets stuck. Both would make Feed Roller (T6-1-71140) difficult for running and then the machine has incomplete reversing problem.
