- Page 1 " " " % &! #! " ' Copyright 2003-2008 © Transpak Equipment Corp. All rights reserved. last updated; August 19, 2008...
- Page 2 Semi-Auto Strapping Machine TP-201/202/203/202L Q&A CONTENTS After the strap has been inserted into the strap inlet (LS1 Switch is touched), the machine does not start running.......................2 Strapping cycle is completed but without tensioning ..............2 III. After tensioning, the machine will not cut the strap. (The non-stop reversing may damage the package.) ..........................2...
- Page 3 Semi-Auto Strapping Machine TP-201/202/203/202L Q&A After the strap has been inserted into the strap inlet (LS1 Switch is touched), the machine does not start running (a) Check if TF-006 Micro Switch (LS-1) is defective or the connecting wire is loose.
- Page 4 Semi-Auto Strapping Machine TP-201/202/203/202L Q&A IV. While tensioning, there is a screeching sound and machine does not complete the strapping cycle(pressure is too low) (a) Tighten the 4 nuts (no. ) by 0.5 to 1 turn. {refer to the drawing (a)} (b) There should be about 0.5mm clearance for...
- Page 5 Semi-Auto Strapping Machine TP-201/202/203/202L Q&A (g) Clearance “A”{refers to the drawing(a)} between feed rollers is too small so that the strap is reversed outside of the rollers TB-117. As a result, the strap can not be fed out. (h) Check if TF-006 Micro Switch (LS-3) is defective or connecting wire is loose.
- Page 6 Semi-Auto Strapping Machine TP-201/202/203/202L Q&A XII. Insufficient tension (a) Turn TB-251 Tube B clockwise to required tension. (b) Clean the contacting surface of TB-176 Friction Disc & TB-170 Pulley from oil and dirt. (c) Replace TB-176 Friction Disc. (d) Replace TB-170 Pulley and TB-175 Plate.
- Page 7 Semi-Auto Strapping Machine TP-201/202/203/202L Q&A (i) The heater is deformed so that it cannot slide in between the upper and lower straps. XV. Incomplete cutting (a) Move TA-239 Cutter Holder to the right to touch the TA-069 Press Bar slightly.
- Page 8 (a) Load the p.p. strap following the direction of arrow. (b) Replace the TE-023 Rubber Stop (TP-201). (c) Replace or Adjust the TC-018 Brake Lining (TP-202). (d) Replace new TE-025(TP-201/TP-203) or TC-025(TP-202/TP-202L) Spring for the brake if either one of them is worn. XX. The TG-007 P.C.Board is burnt (a) Check if the power supply is appropriate for the machine.
