  • Page 1 MITX-6922 Mini-ITX Motherboard User’s Manual V3.0...
  • Page 2 Before ordering products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD. The ownership of other trademarks involved in this manual is owned by its respective owners.
  • Page 3 Safety Instructions 1．Please read the product manual carefully before using this product. 2 ． Put all the unused or uninstalled boards or electronic components in a static dissipative surface or static shielding bag. 3．Always ground yourself to remove any static discharge before touching the board, to place your hands on grounding metal object for a while or wear an anti-static wrist strap at all times.

  • Page 4: Table Of Contents

    Content Chapter One Product Introduction......................1 1.1 Introduction..........................1 1.2 Product Specification........................ 1 Chapter Two Installation Specification....................4 2.1 Interfaces Location & Dimension.................... 4 2.2 Installation Steps........................4 2.3 Memory Installation........................5 2.4 Jumpers Setting.........................5 2.4.1 CMOS Clear/Hold Jumper Setting（JCC）.............. 5 2.4.2 Auto Boot upon Restore AC Power（JAT）..............
  • Page 5 BIOS Set up............................25 3.1 Main Menu..........................26 3.2 Advanced Menu........................27 3.2.1 APM Configuration......................27 3.2.2 ACPI Settings....................... 28 3.2.3 CPU Configuration......................29 3.2.4 SATA Configuration.....................30 3.2.5 AMT Configuration....................... 31 3.2.6 USB Configuration...................... 32 3.2.7 IT8783F Supper IO Configuration................33 3.2.8 IT8783F H/W Monitor....................34 3.2.9 Serial Port Console Redirection................
  • Page 6 Chapter Product Introdu ction...

  • Page 7: Chapter One Product Introduction

    Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Chapter One Product Introduction 1.1 Product Introduction MITX-6922 is a Mini-ITX motherboard， with Intel QM67/QM77chipset， support Intel Socket G2 Mobile Sandy/Ivy Bridge i7/i5/i3 processor，2x dual channel SO-DIMM memory slot，and DDRⅢ/DDRIIIL 1066/1333/1600，memory up to16GB. 4xSATA ports，2xGigabit network port (in which LAN1 support AMT function)，provide VGA、DVI，LVDS，HDMI display port，and...
  • Page 8 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset up to 8GB. Storage ●4 x standard 7 Pin SATA port，in which SATA1，SATA2 support SATA 3.0。QM67 platform support AMT7.0，QM77 platform support AMT8.0. LAN Function ●Network controller：Adopt Intel 82579LM/82574L network chip ●2 x standard RJ45 port ●...
  • Page 9 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Expansion Port ●2xMINI PCIe，MINI PCIe 1 support WiFi、3G module，MINI PCIe 2 support WiFi、3G module and SSD card function ●On board SIM card slot，can support 3G network，need to work with MINI PCIe 3G module Power Supply ●Standard ATX power supply...
  • Page 10 Chapter Install ation Specifi cation...

  • Page 11: Chapter Two Installation Specification

    Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Chapter Two Installation Specification 2.1 Interfaces Location & Dimension Following picture illustrates the interfaces location and dimension of MITX-6922. Please take care of some components during the installation. Improper installation may leads to system failure.

  • Page 12: Memory Installation

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 2．Install Memory; 3．Install other expansion cards； 4．Connect all signal lines, cables, control panel circuit and power supply unit； 5．Start the computer and complete BIOS Settings Key components of this motherboard are Integrated circuit and these components could be easily damaged by electrostatic influence.
  • Page 13 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset （2）Use jumper cap to connect JCC pins 1 and 2 for 5-6 seconds, then restore to 2-3； （3）Press "F9" -- "enter" to reload the optimal default value； （4）Press F10 to save and exit the settings JCC：...

  • Page 14: Me Function Setting（Jcm

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 2.4.2 Hardware Switch for System Auto Boot upon Power on（JAT） 2.4.3 ME Function Setting（JCM）...
  • Page 15 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset JCM： Setting Clear ME setting Normal working state, default setting 2.4.4 COM2 Jumper Setting（J5，J6，J8） J5，J6，J8 jumper is to set COM2 transmission mode，COM2 support RS 232/RS 422/RS 485 transmission mode，you can choose settings according to your own needs，the default transmission mode is RS 232.

  • Page 16: Sata Port（Sata1-Sata4，Hdd_Power

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 2.5.1 SATA Port（SATA1-SATA4，HDD_POWER） On board 4xSATA port，provide 1x5Pin HDD power supply voltage interface. SATA1-SATA4 HDD_POWER SATA： Signal Name JSATAPWR： Signal Name +3.3V +12V...

  • Page 17: Serial Port（Com1，Com2，Com3456

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 2.5.2 Serial Port（COM1，COM2，COM3456） Board with 6xserial port，COM1 is standard DB9 pin connector、COM2 is standard 2×5 Pin pin，the DB9 interface needs to be led out through the conversion cable；COM3-6 are 2× 20Pin pin，the equipment needs to be connected by conversion cable. Users can turn on or off the serial port in the BIOS setting option, and can select its interrupt IRQ and I / O address.
  • Page 18 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset SOUT When COM2 is set to RS232/RS422/RS485，the pins are defined as follows： RS232 RS422 RS485 （default） DATA- DATA+ COM_3456： Signal Name Signal Name DCD3 DSR3 RXD3 RTS3 TXD3 CTS3 DTR3 DCD4 DSR4...

  • Page 19: Display Port（Vga， Dvi，Lvds

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset RXD5 RTS5 TXD5 CTS5 DTR5 DCD6 DSR3 RXD6 RTS6 TXD6 CTS6 DTR6 2.5.3 Display Port（VGA， DVI，LVDS） HDMI LVDS VGA、DVI VGA： Signal Name Signal Name Signal Name GREEN BLUE HSYNC VSYNC DDCCLK...
  • Page 20 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset DVI（18Bit DVI cable is recommended） ： Signal Name Signal Name TDC2# TDC2 SC-DDC SD-DDC TDC1# TDC1 HP-DETECT TDC0# TDC0 TLC# LVDS： VDD_PANEL VDD_PANEL VDD_PANEL LVDSA_DATA0# LVDSA_DATA0 LVDSA_DATA1# LVDSA_DATA1 LVDSA_DATA2# LVDSA_DATA2 LVDSA_CLK# LVDSA_CLK...
  • Page 21 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset HDMI： Signal Name Signal Name DDC CLK DDC DATA HP DET...

  • Page 22: Usb Port（Usb_12，Usb_34，Usb56_Lan1，Usb78_Lan2

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 2.5.4 LVDS Power Supply Voltage（LVDS_BKLT） LVDS_BKLI LVDS_BKLT： Signal Name BKLT_CTRT BKLT_EN +12V 2.5.5 USB Port（USB_12，USB_34，USB56_LAN1，USB78_LAN2） External USB port and network interface，2x independent socket. Separately provide 2x standard USB 2.0 port and 1 x standard RJ45 port. USB_12、 USB_34 are built-in USB port， two...

  • Page 23: Keyboard And Mouse Interface（Kbms

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset USB56_LAN1 USB78_LAN2 USB1-4 Standard USB port： Signal Name USB DATA- USB DATA+ USB_12，USB_34： Signal Name Signal Name USB DATA- USB DATA+ USB DATA+ USB DATA- 2.5.6 Keyboard & Mouse Interface（KBMS） Provide 1x keyboard and mouse interface.
  • Page 24 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset KBMS KBMS: Signal Name Signal Name KB_DATA VCC_KM KB_CLK MS_DATA VCC_KM MS_CLK 2.5.7 Programmable I/O Interface（JGPIO1、JGPIO2） Provide two 2×10Pin programmable I/O interface.
  • Page 25 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset JGPIO1-2 JGPIO1： Signal Name Signal Name IO_00 IO_01 IO_04 IO_02 IO_05 IO_03 IO_06 IO_07 JGPIO2 Signal Name Signal Name IO_08 IO_09 IO_12 IO_10 IO_13 IO_11 IO_14 IO_15...

  • Page 26: Power Interface（Atx

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 2.5.8 Power Interface（ATX） ATX： Signal Name Signal Name +3.3V +3.3V +3.3V -12V PS-ON PW-OK +5V SB +12V 2.5.9 Fan Interface（CPUFAN，SYSFAN） Board with 1x 4Pin CPU fan interface and 1x3Pin system fan interface. Please pay...

  • Page 27: Audio Port（Audio，Jau，Jamp

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset （1）FAN current ≤350 mA（4.2W，12V）. （2）Make sure that the fan wiring is in line with the socket wiring. CPUFAN SYSFAN CUFAN: Signal Name +12V Speed detect Speed control SYSFAN： Signal Name +12V Speed detect 2.5.10 Audio Port（Audio，JAU，JAMP）...

  • Page 28: Front Panel Interface（Jfp

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset AUDIO JAMP JAU： Signal Name Signal Name Mic-in_L Mic-in_R Line-out_L Line-out_R Line-in_L Line-in_R JAMP： Signal Name OUT-L- OUT-L+ OUT-R- OUT-R+ 2.5.11 Front Panel Interface（JFP） Front panel pin，for connecting to the function buttons and indicators set on the front panel...
  • Page 29 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset JFP： Signal Name Signal Name PWR_LED+ PWR_LED- HDD_LED- HDD_LED+ BUZZDATA- BUZZDATA+ RSTBTN POWERSW+ Please follow the table below to connect, pay attention to the anode (+) and cathode (-), otherwise some function cannot be realized.

  • Page 30: Memory Slot（Dimm

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 1）System power LED pins（Pin 1、Pin 2 PWRLED） Connect system power LED cable with these pins. （ pin 1 is LED anode） When system is power on, power LED is on；when system is power off, power LED is off.
  • Page 31 Chapter Three BIOS Set up...

  • Page 32: Chapter Three Bios Set Up

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Chapter Three BIOS SET UP AMI BIOS Refresh BIOS provides the underlying driver of hardware resources and is the bridge between hardware and operating system. Hardware and software are upgrading all the time, so when your system goes wrong, for example, your system can not support the newest CPU, you need to upgrade BIOS to keep up with the latest technology.

  • Page 33: Bios Set Up

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset BIOS Set up： When the computer is powered on, after self-diagnosis, the following information will be displayed on the screen: Del->SETUP. At this time, click the Del key, and BIOS will automatically turn to the setup setting screen after detection of IDE and other devices.

  • Page 34: Advanced Menu

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset System Time System Time Format，Hour/Minute/Second. 3.2 Advanced Menu BIOS SETUP UTILITY Enabled or Disabled Boot Option BIOS Information for Legacy Network Devices. Launch LAN1 PXE OpROM [Disabled] Launch LAN2 PXE OpROM [Disabled] →←：Select Screen...

  • Page 35: Acpi Settings

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Enable or disable System wake on RTC Power On Function [Enabled] alarm event. When enabled. RTC Power On Hour System will wake RTC Power On Minute hr::min::sec specified RTC Power On Second →←：Select Screen...

  • Page 36: Cpu Configuration

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset →←：Select Screen ↑↓：Select Item Enter：Select +/-：Change Opt. F1：General Help F9：Optimized Defaults F10：Save & Exit ESC：Exit Version 2.10.1208. Copyright（C）2010 American Megatrends，Inc. ACPI Sleep State To select different system sleep time to reach saving power mode and levels of power consumption will be different.
  • Page 37 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset L2 Cache 256 KB ×4 →←：Select Screen L3 Cache 6144 KB ×4 ↑↓：Select Item Enter：Select Hyper-Threading [Enabled] +/-：Change Opt. Active Processor Cores [All] F1：General Help Limit CPUID Maximum [Disabled] F9：Optimized Defaults Execute Disabled Bit [Enabled] F10：Save&Exit...

  • Page 38: Sata Configuration

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Intel Virtualization Technology Intel Virtualization is a system hypothesis technology used in Intel's CPU. It enables a PC to run multiple OSs. VT technology will play a very important role in various types of processors (including dual-core processors).

  • Page 39: Amt Configuration

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 3.2.5 AMT Configuration BIOS SETUP UTILITY Intel AMT [Enabled] Enable / Disable Intel(R) Active Enable ME [Enabled] Management Technology BIOS BIOS Hotkey Pressed [Disabled] Extension. Un-Configure ME [Disabled] Note: iAMT always End of Post Enable [Enabled] enabled.

  • Page 40: Usb Configuration

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset End of Post Enable The status bit transmitted to ME, which is required for AMT remote installation system 3.2.6 USB Configuration BIOS SETUP UTILITY Enable or Disable the USB EHCI USB Configuration (USB 2.0) functions.

  • Page 41: It8783F H/W Monitor

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Set Parameters of Serial Port 1 IT8783F Super IO Configuration （COMA） IT8783F Super IO Chip IT8783F Serial Port 1 Configuration Serial Port 2 Configuration →←：Select Screen Serial Port 3 Configuration ↑↓：Select Item Serial Port 4 Configuration Enter：Select...

  • Page 42: Serial Port Console Redirection

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset →←：Select Screen CPU Fan Speed : 5357 RPM ↑↓：Select Item SYS Fan Speed : N/A Enter：Select +/-：Change Opt. CPUVCORE : +1.061V F1：General Help +3.3VIN : +3.198V F9：Optimized Defaults +5VIN : +4.806V F10：Save&Exit ESC：Exit...

  • Page 43: Chipset Menu

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Console Redirection The first two items are used to set whether to enable the serial port redirection output function，Set value：[Enabled][Disabled]. 3.3 Chipset Menu BIOS SETUP UTILITY North Bridge North Bridge Parameters South Bridge →←：Select Screen...

  • Page 44: South Bridge

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Enable PEG External video card PCIEx16 switch Primary Display Select the internal or external video card as the main display DVMT Pre-Allocated Special video memory for built-in video card DVMT Total Gfx Mem The built-in video card shares the video memory.

  • Page 45: Boot Menu

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Enable or disable Audio Controller. South Bridge Audio Controller [Enabled] LAN 1 Controller [Enabled] →←：Select Screen LAN 2 Controller [Enabled] ↑↓：Select Item Wake on LAN [Enabled] Enter：Select +/-：Change Opt. Restore AC Power Loss [Power On] F1：General Help...
  • Page 46 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Bootup Numlock State [On] →←：Select Screen Show Full Logo [Disabled] ↑↓：Select Item Enter：Select Boot Option Priorities +/-：Change Opt. Boot Option #1 [SATA PM:WDC WD10… ] F1：General Help F9：Optimized Defaults Hard Drive BBS Priorities F10：Save&Exit...

  • Page 47: Security Menu

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset 3.5 Security Menu BIOS SETUP UTILITY The password length must be Set Administrator Password in the following range: →←：Select Screen Minimum length ↑↓：Select Item Maximum length Enter：Select +/-：Change Opt. Administrator Password F1：General Help User Password F9：Optimized Defaults...
  • Page 48 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset →←：Select Screen ↑↓：Select Item Enter：Select +/-：Change Opt. F1：General Help F9：Optimized Defaults F10：Save&Exit ESC：Exit Version 2.10.1208. Copyright（C）2010 American Megatrends，Inc. Load Defaults To select whether to restore the BIOS default settings Save Change and Exit To save changes to BIOS settings and restart the computer.
  • Page 49 Appendix...

  • Page 50: Appendix

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Appendix Appendix 1：Watchdog Programming Guide Watchdog reference code（ASM） -------------------------------------------------------------------------------------------------------------- Set the port to realize watchdog function. Different functions of Watchdog Timer can be realized by writing data to corresponding ports and operating ports.
  • Page 51 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset temp |= 0x02; outportb(datap,temp); //lock...

  • Page 52: Appendix 2：Glossary

    MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset Appendix 2：Glossary ACPI Advanced Configuration and Power Management. ACPI specifications allow operating system to control most power of the computer and its add-ons. BIOS Basic input/output system. It is a kind of software including all in/out control code interface in PC.
  • Page 53 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset DRAM Dynamic Random Access Memory. It’s a general type of memory for regular computer which usually store 1 bit with a transistor and a capacitance. With the development of the technology, more and more types of DRAM with different specifications exist in computer applications. For example: SDRAM/DDR SDRAM/RDRAM.
  • Page 54 MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset interface with only 6PIN; it also can connect other devices, like modem. It is the Universal Serial Bus for short. A hardware interface adapts to low speed peripherals, and is always used to connect keyboard, mouse etc. One PC can connect maximum 127 USB...
