  • Page 1 MITX-6110 User’s Manual V1.0...
  • Page 2 Before buying products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD. The ownership of other trademarks involved in this manual is owned by its respective owners.

  • Page 3: Safety Instructions

    Safety Instructions 1.Before using this product, please read this user’s manual carefully; 2.Any plate cards not ready to be installed shall be kept in the anti-static protective bags; 3.Before taking out the plate cards from the anti-static protective bags, first place hands on the grounding metal object for a while so as to release the static electricity from your body and hands;...

  • Page 4: Table Of Contents

    Content Chapter 1 Product Introduction......................1 1.1 Product Specification........................ 1 Chapter 2 Installation Instructions...................... 3 2.1 Interface Location and Dimension Diagram................3 2.2 Installation Steps........................3 2.3 Memory Installation........................4 2.4 Jumper Setting...........................4 2.4.1 CMOS Content Clearance /Keep Settings（JCC1、JCC2）........4 2.4.2 Hardware Switch for System Auto Boot upon Power On（JAT）......6 2.4.3 Debug Interface（DB_UART）...................
  • Page 5 Chapter 3 BIOS Setup........................25 AMI BIOS Reflesh........................25 AMI BIOS Description......................25 BIOS Parameter Setting....................... 25 3.1 Main Menu..........................26 3.2 Advanced..........................27 3.2.1 ACPI Settings....................... 28 3.2.2 CPU Configuration.......................29 3.2.3 SATA Drives......................... 31 3.2.4 USB Configuration....................... 32 3.2.5 F81804 Supper IO Configuration................33 3.2.6 Hardware Monitor......................
  • Page 6 Chapter Product Introdu ction...

  • Page 7: Chapter 1 Product Introduction

    MITX-6110 User's Manual Chapter 1 Product introduction 1.1 Product Specification Size ●170mm×170mm（L×W） Processor ●Pentium Silver J5005； Pentium Silver N5000； Celeron J4105； Celeron J4005； Celeron N4100； Celeron N4000； Display ●VGA：1xVGA port ●HDMI：1xHDMI* 2.0a port，Supporting resolution : 4096× 2160@ 60 Hz ●LVDS：1xLVDS，dual channel，24bit System Memory ●Support SO-DIMM DDR4 4/8GB up to 2400MT/s...
  • Page 8 MITX-6110 User's Manual ●2xstandard RJ45 interfaces ● Speed：1000Mbps ● Support 3G/4G、WIFI expansion USB Port ●Provide 8xUSB ports ●4xstandard USB 2.0 ports，4xstandard USB 3.0 ports PCIE Port ●Provide 2xMINI PCIE port and 1x PCIE 1X port. I/0 Functions ●Adopt F81804U chip ●2x COM，COM1 support RS23，COM2 support RS232/485...
  • Page 9 Chapter Install ation Instruc tion...

  • Page 10: Chapter 2 Installation Instructions

    Chapter 2 Installation Instruction 2.1 Interface Location and Dimension Diagram The following picture is the interface index for MITX-6110. When you install your devices, please consult it and read the following guide. During installation please care for some devices. Improper installation will lead to system malfunctions.

  • Page 11: Memory Installation

    MITX-6110 User's Manual 2．Install CPU and memory； 3．Install other expansion cards； 4．Connect all the signal lines, cable, panel-control circuitry and power supply； 5．Start the computer，finish BIOS setup. Key components of this motherboard are Integrated circuit, and these components will be easily damaged by electrostatic influence. So, before installing the motherboard, you should always keep the following precautions in mind：...
  • Page 12 MITX-6110 User's Manual setting of Pin 2 and Pin 3； （3）Turn on the computer, then press DEL key into the BIOS setting and reload the optimized defaults； （4）Save and exit setting. JCC1、JCC2 JCC： Setting Clear CMOS (BIOS renew to initialization)

  • Page 13: Hardware Switch For System Auto Boot Upon Power On（Jat

    MITX-6110 User's Manual 2.4.2 Hardware Switch for System Auto Boot upon Power On （JAT） JAT： Setting Open Disable Auto Boot Close Enable Auto Boot...

  • Page 14: Debug Interface（Db_Uart

    MITX-6110 User's Manual 2.4.3 Debug Interface（DB_UART） DB_UART DB_UART： SINGNAL NAME UART2_TXD UART2_RXD 2.4.4 COM2 Jumper Setting（J1，J2） J1 ， J2 jumper are used to set the transmission mode of COM2 ， COM2 support RS232/RS485 transmission mode，you can choose settings according to your own needs, the...

  • Page 15: Interface Specification

    MITX-6110 User's Manual J1、J2 J1、J2： COM2 RS232（default） COM2 RS485 1-3 2-4 3-5 4-6 3-4 5-6 2.5 Interface Specification When connecting external connectors, please read this manual carefully in order to avoid damage to the motherboard! 2.5.1 SATA Port（SATA1、SATA2、JSATAPWR、MCU_DB） Provide 2x7PIN SATA port，and 1x2.54mm 1X5PIN connector（SATA power supply）port，...
  • Page 16 MITX-6110 User's Manual SATA1 JSATAPWR SATA2 MCU_DB SATA1、SATA2： SINGNAL NAME JSATAPWR： SINGNAL NAME +12V...

  • Page 17: Serial Ports（Hdmi Jcom1、Vga Jcom2

    MITX-6110 User's Manual +3.3V MCU_DB： SINGNAL NAME MCU_TXD MCU_RXD MCU_RST# 2.5.2 Serial Ports （HDMI JCOM1、VGA JCOM2） Provide 2xstandard COM ports， COM1 support RS232 model， COM2 support RS232/485 model. HDMI_COM2 JCOM1 JVGA VGA_COM2 JCOM2 JCOM1： SINGNAL NAME SINGNAL NAME...
  • Page 18 MITX-6110 User's Manual HDCD#1 HDSR#1 HSIN1 HRTS#1 HSOUT1 HCTS#1 HDTR#1 HRI#1 JCOM2： SINGNAL NAME SINGNAL NAME HDCD#2TX-DATA- HDSR#2 HSIN2TX+DATA+ HRTS#2 HSOUT2 HCTS#2 HDTR#2 HRI#2 VGA_COM2： SINGNAL NAME DATA- DATA+ HSOUT2 HDTR#2 HDSR#2 HRTS#2 HCTS#2 HRI#2 COM1： SINGNAL NAME HDCD#1 HSIN1...

  • Page 19: Display Port（Lvds

    MITX-6110 User's Manual HDSR#1 HRTS#1 HCTS#1 HRI#1 JVGA： SINGNAL NAME SINGNAL NAME VGA1_R VGA1_G VGA1_SDA_R VGA1_B VGA1_HSYNC 5V_DDC VGA1_VSYNC VGA1_SCL_R 2.5.3 Display Port（LVDS） Provide 1xdual channel LVDS port. LVDS...
  • Page 20 MITX-6110 User's Manual LVDS： SINGNAL NAME SINGNAL NAME VDD_PANEL VDD_PANEL VDD_PANEL L_BKLTEN_R LVDSA_DATA0# LVDSA_DATA0 LVDSA_DATA1# LVDSA_DATA1 LVDSA_DATA2# LVDSA_DATA2 LVDSA_CLK# LVDSA_CLK LVDSA_DATA3# LVDSA_DATA3 LVDSB_DATA0# LVDSB_DATA0 LVDSB_DATA1# LVDSB_DATA1 LVDSB_DATA2# LVDSB_DATA2 LVDSB_CLK# LVDSB_CLK LVDSB_DATA3# LVDSB_DATA3...

  • Page 21: Lvds Voltage And Backlight Setting Interface （Jlvds、Jlvdsbtn、 Jlvdspwr

    MITX-6110 User's Manual 2.5.4 LVDS Voltage and Backlight Setting Interface （JLVDS、JLVDSBTN、 JLVDSPWR） JLVDS JLVDSPWR JLVDSBTN JLVDS： SINGNAL NAME +3.3V LVDS_VDD JLVDSPWR： SINGNAL NAME LVDS_PWM_OUT_R L_BKLTEN_R VCC12_S...

  • Page 22: Usb Port（Usb12、Usb34、Usb56_Usb3_Lan1、Usb78_Usb_Lan2

    MITX-6110 User's Manual VCC12_S JLVDSBTN： SINGNAL NAME BLUP BLDN PWRDN 2.5.5 USB Port（USB12、USB34、USB56_USB3_LAN1、USB78_USB_LAN2） Provide 2x standard Gigabit RJ45 network interface and 8xUSB port；in which 4x standard USB 2.0 port、4 x standard USB3.0 port. RJ45 Ethernet interface has 1xLED on each side：...
  • Page 23 MITX-6110 User's Manual VCC_USB5 USBD_N USBD_P USBD_N USBD_P VCC_USB5 RJ45 LAN LED state descriptions： LILED（Green） Function ACTLED（Yellow） Function 100/1000M link FLASH Data transfer FLASH 10M link or close Data stop transferring 2.5.6 Keyboard & Mouse Interface（KBMS） One 2x4 Pin 2.0mm pin interface ， converting to standard PS/2 keyboard and mouse interface by switching wiring.

  • Page 24: Programmable I/O Interface（Jgp

    MITX-6110 User's Manual MS_DATA_R KB_DATA_R KB_CLK_R VCC_KBMS 2.5.7 Programmable I/O Interface（JGP） One 2x5Pin 2.0mm pin 8bit GPIO interface，can be customized for input or output use. JGP： SINGNAL NAME SINGNAL NAME SIO_GPIO_135 VCC3P3_A SIO_GPIO_136 SIO_GPIO_141 SIO_GPIO_139 SIO_GPIO_143 SIO_GPIO_140 SIO_GPIO_145 SIO_GPIO_146...

  • Page 25: Power Interface（Pwr1、Pwr2、Pwr3

    MITX-6110 User's Manual 2.5.8 Power Interface（PWR1、PWR2、PWR3） MITX-6110 motherboard provides 3xPWR power interface，supporting only one of three choices. PWR1-3 External power interface PWR1、PWR3： SINGNAL NAME +12V External power interface PWR2： SINGNAL NAME +12V +12V...

  • Page 26: Fan Interface（Sys_Fan、Cpu_Fan

    MITX-6110 User's Manual 2.5.9 Fan Interface（SYS_FAN、CPU_FAN） 1xSYS_FAN interface，1xCPU_FAN interface，two things to note when using fans： (1) Fan current≤350 mA（4.2W，12V）. (2) Make sure that the fan wiring and the outlet wiring match. Power cord (usually red) is in the middle. In addition, ground wire (usually black) and fan speed output pulse signal line (other colors).

  • Page 27: Jlpc Interface（Jlpc

    MITX-6110 User's Manual +12V CPUFANIN CPUFANOUT 2.5.10 Line Input Pin（LINE_IN） One 1x3PIN LINE_IN pin LINE_IN LINE_IN： SINGNAL NAME LINE1*L AGND LINE1*R 2.5.11 JLPC Interface（JLPC） One 2×10Pin 2.54mm JLPC interface，to expand external devices...
  • Page 28 MITX-6110 User's Manual JLPC JLPC： SINGNAL NAME SINGNAL NAME LPC_3V3_CLK1 LPC_FRAME_3V3 CLK_48M_2# JLPC_RESET# VCC5_S_SIO LPC_AD3 LPC_AD2 VCC3P3_SIO LPC_AD1 LPC_AD0 SMB_3P3_CLK SMB_3P3_DAT VCC3P3_A LPC_SERIRQ_3V3 SUS_STAT...

  • Page 29: Audio Port（Audio

    MITX-6110 User's Manual 2.5.12 Audio Port（Audio） Provide 1xaudio port，green is Line-out，red is Mic-in. AUDIO...

  • Page 30: Bios

    MITX-6110 User's Manual 2.5.13 BIOS Write Protection Interface（JME） JME： SINGNAL NAME EMMC BOOT GP_INTD_DSI_TE1 2.5.14 Front Panel Interface （JFP） Provide one 2×5Pin 2.54mm front panel pin. JFP is used to connect function buttons and LED indicator on the front panel.
  • Page 31 MITX-6110 User's Manual JFP： SINGNAL NAME SINGNAL NAME PLED+ GND- HDD_LED+ SATA_LED_N_R BUZZDATA# RSTBTN_N_R PWRBTN_N_R Please follow the table below to connect, pay attention to the anode (+) and cathode (-), otherwise some function cannot be realized. POWER_LED IDE_LED BUZZ...

  • Page 32: Memory Slot（So-Dimm

    MITX-6110 User's Manual 1）System power LED pins（pin 1、pin 2 POWER_LED） Connect system power LED cable with these pins.（pin 1 is LED anode）When system is power on, power LED is on；when system is power off, power LED is off. 2）HDD LED Pins（pin 3、pin 4 HDD_LED）...

  • Page 33: Chapter 3 Bios Setup

    Chapter Three BIOS Set up...

  • Page 34: Ami Bios Reflesh

    MITX-6110 User's Manual Chapter Three BIOS Set up AMI BIOS Refresh BIOS functions as a bridge connecting hardware and operating system. Hardware and software are upgrading all the time, so when your system goes wrong, for example, your system cannot support the newest CPU, you need to upgrade BIOS to keep up with the latest technology.

  • Page 35: Main Menu

    MITX-6110 User's Manual 3、 Use the “←↑→↓” to select the option which you want to modify, press <Enter> to go to the sub-menu. 4、 Use the “←↑→↓” and <Enter> to modify the value; press “ Enter” to modify BIOS options that you choose.

  • Page 36: Advanced

    MITX-6110 User's Manual System Time Format: Hour/Minute/Second. Setting scale is Hour (00-23), Minute (00-59), Second (00-59). 3.2 Advanced ACPI Settings Setting system sleep depth S3 CPU Configuration CPU configuration and common setting SATA Drives HDD mode settings and HDD information...

  • Page 37: Serial Port Console Redirection

    MITX-6110 User's Manual Hardware voltage detection information Serial Port Console Redirection Serial port redirection settings LAN Configuration LAN information and control options Network Stack Configuration Set whether to load on-board UEFI network card boot code CSM Configuration Compatibility support module control options 3.2.1 ACPI Settings...
  • Page 38 MITX-6110 User's Manual 3.2.2 CPU Configuration Socket 0 CPU Information This is the specific information for displaying the CPU EIST Intelligent frequency reduction technology switching on or off settings Turbo Mode Boot performance mode Boot performance mode selection C-States CPU operating mode...
  • Page 39 MITX-6110 User's Manual Read-only items contain CPU details, including CPU manufacturer, model, frequency, L1 Cache size, L2 Cache size, and so on.
  • Page 40 MITX-6110 User's Manual 3.2.3 SATA Drives SATA Drives SATA controller SATA Mode Selection Setting up SATA configuration mode SATA Test Mode SATA Port 0 SATA Port 0 detected storage device Port 0 Configure the opening and closing of SATA port 0...
  • Page 41 MITX-6110 User's Manual This configuration opens and closes SATA port 1 SATA Device Type Setting up SATA device type 3.2.4 USB Configuration Legacy USB Support Legacy USB supports setting. To support USB devices in DOS mode, such as USB FLASH disk, USB keyboard, select this option as [Enabled] or [Auto]. Otherwise, select [Disabled].
  • Page 42 MITX-6110 User's Manual USB Mass Storage Driver Support Mass USB storage on-off USB Transfer time-out Set USB device transfer command, data and time-out (default 20 seconds). Device reset time-out Set USB Devices reset time-out (default 20 seconds). Device Power-up Delay Set USB maxi device power-up delay.
  • Page 43 MITX-6110 User's Manual...
  • Page 44 MITX-6110 User's Manual 3.2.6 Hardware Monitor PC Health Status This is used for hardware security detection; BIOS will display the current CPU temperature, as well as other related voltage values. The above parameters have a certain range, and the system cannot run beyond these ranges.
  • Page 45 MITX-6110 User's Manual 3.2.7 Serial Port Console Redirection Console Reditection Motherboard supports serial ports1, 2 console redirection, default Disable. Enable console redirection just need to turn on COM1 or COM2 console redirection. EMS console redirection is no need to be on.

  • Page 46: Lan Configuration

    MITX-6110 User's Manual 3.2.8 LAN Configuration Launch LAN1 PXE OpROM Launch LAN2 PXE OpROM Onboard LAN1 Controller Onboard LAN2 Controller...

  • Page 47: Network Stack Configuration

    MITX-6110 User's Manual 3.2.9 Network Stack Configuration Network Stack...

  • Page 48: Csm Configuration

    MITX-6110 User's Manual 3.2.10 CSM Configuration CSM Support CSM----Compatibity Support Module，belonging to UEFI. Provide compatibility support for those not support UEFI system. GateA20 Active Option ROM Messages To set OpROM display model Interrupt 19 Capture HDD Connection Order Boot opdtion fildter...

  • Page 49: Chipset Menu

    MITX-6110 User's Manual Storage Choose to support which type of storage OpROM， like Efi OpROM or Legacy OpROM， support both. Video Choose to support which type of display OpROM，like Efi OpROM or Legacy OpROM， support both. Other PCI devices Other PCI devices OpROM implantation strategy 3.3 Chipset Menu...

  • Page 50: North Bridge

    MITX-6110 User's Manual 3.3.1 North Bridge VBT Select Primary IGFX Boot Display Setting up main display device in integrated display card LCD Panel Type This is to set the resolution of the LVDS screen.

  • Page 51: South Bridge

    MITX-6110 User's Manual 3.3.2 South Bridge PCI CLOCK RUN Restore AC Power Loss This item is used to set the boot-up situation after power-up. When power Off is selected, the power button is pressed to boot up. When power On is selected, the boot-up will be started directly after power-up.
  • Page 52 MITX-6110 User's Manual 3.3.2.1 PCI Express Configuration PCI Express Clock Gating Port8xh Decode Switch item decoding 80 ports to PCIE Peer Memory write Enable Peer memory write function Compliance Mode Standard compatibility mode PCI Express Root Port 1/2/3/4/5/6 PCIE Root port...
  • Page 53 MITX-6110 User's Manual...
  • Page 54 MITX-6110 User's Manual...
  • Page 55 MITX-6110 User's Manual...

  • Page 56: Boot Menu

    MITX-6110 User's Manual 3.4 Boot Menu Fast Boot VGA Support USB Support Network Stack Driver Support Boot up Numlock State This function allows users to activate Numlock function when boot up. [ON]: Numlock is activated when system boots up [OFF]: Numlock under cursor control.

  • Page 57: Security Menu

    MITX-6110 User's Manual The system will test the device in the set order until it finds a device that can be started and then starts from the device. Among the startup options, # 1 is the most preferred startup device.

  • Page 58: Exit Menu

    MITX-6110 User's Manual 3.6 Exit Menu Discard Changes and Exit Discard all changes and exit, and continue reboot. Save Changes and Reset Save all BIOS changes and exit, then reboot Discard Changes and Reset Quit changes and exit, then reboot...

  • Page 59: Appendix

    Appendix...

  • Page 60: Appendix 1：Watchdog Programming Guide

    MITX-6110 User's Manual Appendix Appendix 1 ：Watchdog Programming Guide watchdog reference code（ASM） -------------------------------------------------------------------------------------------------------------- Set the port to realize watchdog function through operating ports by writing data to corresponding ports, so that it can carry out Watchdog Timer’s various functions. Port specification：...
  • Page 61 MITX-6110 User's Manual outportb(datap,0x00); outportb(indexp,0x72); outportb(datap,0x80); //set second outportb(indexp,0x73); outportb(datap,0x03); //set 3 seconds outportb(indexp,0xf3); outportb(datap,0x00); //WDT’’s IRQ outportb(indexp,0xf1); outportb(datap,0x44); //wdt enable generate smi,and level trigger outportb(indexp,0xf4); outportb(datap,0x1e); //gpio36 mapping table outportb(indexp,0x71); outportb(datap,0x00); outportb(indexp,0x27); outportb(datap,0x40); outportb(indexp,0x02); outportb(datap,0x02); //exit...

  • Page 62: Appendix 2：Irq And System Memory Map,1St Mb Memory Map

    MITX-6110 User's Manual Appendix 2：IRQ and System Memory Map,1st MB Memory Map IRQ： Priority Interrupt# Interrupt source Parity error detected System timer Available Interrupt from controller 2 (cascade) System CMOS/real time clock Microsoft ACPI-Compliant System Available Communication port (COM3,4,5,6) Available...
  • Page 63 MITX-6110 User's Manual and Graphics Driver DFD00000 – DFD03FFF Realtek PCIe GBE Familly Controller DFD00000 – DFDFFFFF Intel (R) N10/ICH7 Family PCI Express Root Port – 27D2 DFD04000 – DFD04FFF Realtek PCIe GBE Familly Controller DFE00000 – DFE03FFF Realtek PCIe GBE Familly Controller #2 DFE00000 –...

  • Page 64: Appendix 3：Glossary

    MITX-6110 User's Manual Appendix 3：Glossary ACPI Advanced Configuration and Power Management. ACPI specifications allow operating system to control most power of the computer and its add-on. BIOS Basic Input/Output System. It is software including all in/out control code interface in PC. The software will detect hardware when it auto boot, operate OS, and provide an interface between OS and hardware.
  • Page 65 MITX-6110 User's Manual memory bus width. DRAM Dynamic Random Access Memory. It’s a general type of memory for regular computer which usually store 1 bit with a transistor and a capacitance. With the development of the technology, more and more types of DRAM with different specifications exist in computer applications. For example: SDRAM/DDR SDRAM/RDRAM.
  • Page 66 MITX-6110 User's Manual PS/2 A keyboard & mouse connective interface specification developed by IBM. PS/2 is a DIN interface with only 6PIN; it also can connect other devices, like modem. It is the Universal Serial Bus for short. A hardware interface adapts to low speed peripherals, and is always used to connect keyboard, mouse etc.
