DOREL ASIA
Model No:
SWIVEL GLIDER
WM6095
UPC CODE:
0-65857-16300-1
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
___________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSI
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN P
E-MAIL:DAS@DOR
Advertisement
Related Manuals for Dorel Asia WM6095
Summary of Contents for Dorel Asia WM6095
- Page 1 DOREL ASIA Model No: SWIVEL GLIDER WM6095 UPC CODE: 0-65857-16300-1 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ___________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
-
Page 2: Maintenance
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
SWIVEL GLIDER WM6095 HARDWARE LIST Ø5/16" X 63mm Ø25 X 1.8mm Ø12.5 X 1.2mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 6 PCS 6 PCS 6 PCS ALLEN KEY 1 PC PARTS LIST LEFT ARM RIGHT ARM CHAIR BACK... - Page 4 SWIVEL GLIDER WM6095 STEP 1: Place all parts on a clean, smooth surface. Attach left arm (A) to chair back (C) by inserting the metal bracket on left arm (A) into the metal glide on chair back (C). Push the left arm (A) with a downward force to secure it into place.
- Page 5 SWIVEL GLIDER WM6095 STEP 2: Gently turn the assembled unit upside side down and open the fabric lining underneath chair back (C). Secure the chair back (C) to the left arm & the right arm (A & B) with flat washers (2), spring washers (3) and hex socket head bolts (1).
- Page 6 SWIVEL GLIDER WM6095 STEP 3: Place the assembled unit onto the seat base (D). Open the fabric lining underneath seat base (D). Secure the assembled unit to the seat base (D) with flat washers (2), spring washers (3) and hex socket head bolts (1).
- Page 7 SWIVEL GLIDER WM6095 STEP 4: Place the seat cushion (E) onto the chair.
- Page 8 SWIVEL GLIDER WM6095 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust regularly with a soft, dry cloth to prevent soil build up.
- Page 9 C B D MODEL #: WM6095 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com...
