DOREL ASIA
BUNK BED
Model No.:
WM3911-13
WM3921-13
WM3921E2
WM3921B-DC
WM3921W-DC-13
WM3921G-DC
INFORMATION. PLEASE READ AND
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
UPC CODE:
0-65857-15752-9
0-65857-15700-0
0-65857-16529-6
0-65857-16887-7
0-65857-16277-6
0-65857-16785-6
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
KEEP FOR FUTURE REFERENCE.
(TAKEN FROM CARTON)
Date of purchase:
_______ / _______ / _______
Tel # : 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819
Color
PINE
LIGHT CHERRY
MOCHA
BLACK
WHITE
GREY
NOTE:
Lot number:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia BUNK BED WM3911-13
Summary of Contents for Dorel Asia BUNK BED WM3911-13
- Page 1 DOREL ASIA UPC CODE: Model No.: Color 0-65857-15752-9 WM3911-13 PINE BUNK BED 0-65857-15700-0 WM3921-13 LIGHT CHERRY 0-65857-16529-6 WM3921E2 MOCHA 0-65857-16887-7 BLACK WM3921B-DC 0-65857-16277-6 WM3921W-DC-13 WHITE WM3921G-DC 0-65857-16785-6 GREY NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.
-
Page 3: Care And Cleaning
NOTES READ EACH STEP CAREFULLY BEFORE STARTING. IT IS VERY IMPORTANT THAT EACH STEP OF INSTRUCTION IS PERFORMED IN THE CORRECT ORDER. IF THESE STEPS ARE NOT FOLLOWED IN SEQUENCE, ASSEMBLY DIFFICULTIES WILL OCCUR AND CAN RESULT IN INJURY. CAUTION: ADULT ASSEMBLY REQUIRED MAKE SURE ALL PARTS ARE INCLUDED. - Page 4 BUNK BED ALLEN KEY...
- Page 5 BUNK BED...
- Page 6 BUNK BED...
- Page 7 BUNK BED STEP 1 One of the headboard top crosses (F) has a label on it, do not use it in this step. Insert wood dowels (7) into the ends of headboard top cross (F), headboard bottom cross (G), and headboard center cross (S).
- Page 8 BUNK BED STEP 2 Repeat the previous step to assemble the remaining three sets of headboards. Be sure to pair the bottom posts (D) and (E) for one pair; (E) and (D) for another; and the top posts (C) and (A) for the last pair. NOTE: Be sure to use headboard top cross (F) with label attached to it between top posts (A) and (C).
- Page 9 BUNK BED Holes Holes STEP 3 Attach the two headboards with bottom posts (D and E) to bottom side rails (I and K) using joint connectors (1) and barrel nuts (8) as shown. Note: This is the lower bunk.
- Page 10 BUNK BED STEP 4 Insert a wood dowel (7) into each end of the long guardrails (M). Attach two long guardrails (M) and two top side rails (H and J) to top posts (A and B) & (A and C) as shown. Fasten top side rails (H and J) with joint connectors (1) and barrel nuts (8).
- Page 11 BUNK BED STEP 5 Insert two slats (T) into the center slots of the bottom side rails (I and K) of the bottom bunk as shown. NOTE: Once inserted, there should be three empty spaces left on each side.
- Page 12 BUNK BED STEP 6 Insert slat (L) into remaining holes on the bottom side rails (I and K) on the lower bunk. Secure slats (L) to the bottom side rails (1 and K) with flat head wood screws (4) using a phillips head screw driver (not included).
- Page 13 BUNK BED STEP 7 Place four wood dowels (6) into the holes in the bottom posts (D and E). Stack the top bunk onto the bottom bunk with the help of another person. Insert wood dowels (7) in the ends of short guardrails (N). Attach short guardrails (N) to top post (A) with wood joint connectors (3).
- Page 14 BUNK BED 8 PCS 8 PCS STEP 8 To assemble the ladder, insert wood dowels (7) into the ends of the ladder steps (Q). Attach long ladder end (O) and short ladder end (P) to ladder steps (Q) with wood joint connectors (2) and Allen key (9).
- Page 15 BUNK BED Slats are not shown in illustration for clarity 6PCS STEP 9 Attach the ladder to the short guardrails (N), top side rail (H) and bottom side rail (I) with wood joint connectors (2) as shown. NOTE: If slat (L) is covering the ladder mounting holes, remove slat (L) and replace after the ladder is attached.
- Page 16 CONVERTING THE BUNK BED INTO TWO SINGLE BEDS Remove the ladder and all the guardrails. With the help of another person, remove the top bunk from the lower bunk. Disassemble the side rails from all headboards (top and lower bunks). Re-assemble the headboards (with tall posts) and footboards (with short posts) to side rails.
- Page 17 BUNK BED CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. DO NOT ALLOW CHILDREN DO NOT ALLOW HORSEPLAY UNDER 6 YEARS OF AGE TO USE ON OR UNDER THE BED AND...
