DOREL ASIA
Model No:
TUFTED HEADBOARD
WM4015H-FQ
UPC CODE:
0-65857-16020-8
NOTE:
THIS INSTRUCTION BOOKLET
IMPORTANT
CONTAINS
SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR A
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETUR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia WM4015H-FQ
Summary of Contents for Dorel Asia WM4015H-FQ
- Page 1 DOREL ASIA Model No: TUFTED HEADBOARD WM4015H-FQ UPC CODE: 0-65857-16020-8 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
TUFTED HEADBOARD WM4015H-FQ HARDWARE LIST Ø5/16" X 50mm Ø22*1.8mm Ø12.5*1.2mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 8 PCS 16 PCS 12 PCS Ø1/4" X 90mm Ø16*1.8mm Ø10.5*1.2mm FLAT WASHER SPRING WASHER HEX SOCKET HEAD BOLT 2 PCS 2 PCS... -
Page 4: Right Leg
TUFTED HEADBOARD WM4015H-FQ PARTS LIST HEADBOARD LEFT LEG 1 PC 1 PC RIGHT LEG STRETCHER 1 PC 1 PC NOTE: LEGS (B & C) AND STRETCHER (D) ARE PACKED INSIDE THE HEADBOARD (A). PULL BACK THE FABRIC LINING BEHIND THE HEADBOARD TO COLLECT ALL PARTS. - Page 5 TUFTED HEADBOARD WM4015H-FQ STEP 1: Insert stretcher (D) into the left leg (B) and right leg (C) and secure using flat washers (5), spring washers (6) and hex socket head bolts (4). Use Allen Key (9) to tighten the bolts.
- Page 6 TUFTED HEADBOARD WM4015H-FQ STEP 2: Pull back the fabric lining on the back of the headboard (A). Attach the assembled legs to the headboard (A) using flat washers (2), spring washers (3) and hex socket head bolts (1). Use Allen Key (10) to tighten the bolts.
- Page 7 TUFTED HEADBOARD WM4015H-FQ NOTE: THE BED FRAME IS NOT INCLUDED AND MUST BE PURCHASED SEPARATELY. THE FOLLOWING ILLUSTRATIONS ARE FOR REFERENCE ONLY. Attach the bed frame (purchased separately) to bed posts using bolts (7), spring washers (3), flat washers (2) and nuts (8). Use Allen Key (10) to tighten bolts and use the open end wrench (11) to tighten the nuts (8).
- Page 8 TUFTED HEADBOARD WM4015H-FQ CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust regularly with a soft, dry cloth to prevent soil build-up.
- Page 9 MODEL #: WM4015H-FQ (Beige) C B D Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com...
