Instructions for Use for Orthotists or Qualified/
Trained Experts System Knee Joints
NEURO CLASSIC zero
z e r o
NEURO VARIO zero
z e r o
NEURO CLASSIC
Download: www.fior-gentz.com
EN
NEURO VARIO
NEURO VARIO 2
NEURO VARIO-SWING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEURO CLASSIC zero and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FIOR & GENTZ NEURO CLASSIC zero

  • Page 1 Instructions for Use for Orthotists or Qualified/ Trained Experts System Knee Joints NEURO VARIO NEURO CLASSIC zero z e r o NEURO VARIO zero NEURO VARIO 2 z e r o NEURO CLASSIC NEURO VARIO-SWING Download: www.fior-gentz.com...
  • Page 2 Druckdatum: 2020-12 Sie finden diese Gebrauchsanweisung im Download-Bereich unserer Website unter www.fior-gentz.de/downloads. Date printed: 2020-12 You can find these instructions for use in the download section on our website at www.fior-gentz.com/downloads Remarque : Vous trouverez cette notice d’utilisation dans la zone de téléchargement sur notre site web sous www.fior-gentz.de/fr/telechargements. Nota: Le presenti istruzioni per l'uso sono disponibili nell'area download del nostro sito all'indirizzo www.fior-gentz.com/downloads.
  • Page 3: Table Of Contents

    Content Page Instructions for Use for Orthotists or Qualified/Trained Experts System Knee Joints 1. Information 2. Safety Instructions Classification of the Safety Instructions All Instructions for a Safe Handling of the System Knee Joint 3. Use Intended Use Indication Qualification Application Product Range Combination Possibilities with Other System Joints...
  • Page 4 Exploded View Drawing NEURO VARIO 2 15.3 Exploded View Drawing NEURO VARIO-SWING 15.4 Spare Parts for the NEURO CLASSIC zero System Knee Joint 15.5 Spare Parts for the NEURO VARIO zero System Knee Joint 15.6 Spare Parts for the NEURO CLASSIC System Knee Joint 15.7...
  • Page 5: Information

    Instructions for Use for Orthotists or Qualified/Trained Experts System Knee Joints Information These instructions for use are addressed to orthotists or qualified/trained experts and do not contain any notes about dangers which are obvious to them. To achieve maximum safety, please instruct the patient and/or care team in the use and maintenance of the product.
  • Page 6 WARNING Risk of Falling Due to Improper Handling Inform the patient about the correct use of the system joint and potential dangers especially with regards - moisture and water as well as - excessive mechanical stress (e.g. due to sports, increased activity or weight gain). WARNING Risk of Falling Due to Improper Processing Process the system joint according to the information in these instructions for use.
  • Page 7: Use

    The system joint may only be used for one fitting and must not be reused. The NEURO CLASSIC zero and NEURO VARIO zero system knee joints can also be mounted to knee orthoses (KO), if articulated side bars with polycentric knee joints are overloaded.
  • Page 8: Product Range

    Product Range These instructions for use provide information on the following system knee joints: NEURO VARIO NEURO CLASSIC zero z e r o NEURO VARIO 2 NEURO VARIO zero z e r o NEURO VARIO-SWING NEURO CLASSIC Combination Possibilities with Other System Joints The system knee joints can be combined with other system joints from our product range.
  • Page 9: Joint Function

    System Joints with Anatomical Posterior Offset posterior System Width 12mm 14mm 16mm 20mm offset NEURO CLASSIC zero fig. 38 Posterior Offset NEURO VARIO zero of the Joint Axis system width System joints without this addition have an integrated posterior offset (fig. 3). These system joints are suitable for patients with poor muscle strength.
  • Page 10: Scope Of Delivery

    System Joint Function System Component dynamic extension stop: - extending movement against resistance possible, which exceeds the set extension angle (e.g. from 5° downwards NEURO VARIO-SWING to 0°). spring unit - resistance variable by exchanging the spring unit - spring’s range infinitely limitable down to 0° via the motion limiting screw Scope of Delivery Description...
  • Page 11: Assembly Instructions

    System Width Tools for Pan Head Screw for Exchanging the Extension Stops 12mm 14mm 16mm 20mm T8 hexalobular screwdriver T10 hexalobular screwdriver Assembly Instructions The system joint is delivered fully assembled. All functions are checked beforehand. You have to disassemble the system joint for mounting it in the orthosis and for maintenance. To ensure an optimal functioning, follow the assembly instructions below.
  • Page 12: Checking The System Joint's Free Movement

    Mounting the Extension Stop Dampers and the O-Ring Damper The system joints NEURO CLASSIC zero, NEURO CLASSIC, NEURO VARIO zero and NEURO VARIO each have two extension stop dampers. The system joints NEURO VARIO 2 and NEURO VARIO-SWING each have one O-ring damper.
  • Page 13: Mounting The Spring Unit Neuro Vario-Swing

    Mounting the Spring Unit NEURO VARIO-SWING For system knee joints without a spring unit, skip these steps and continue the assembly at paragraph 8.7. 1 Place the stop damper (3) into the guide ring (2). 2 Insert the extension stop (1) and guide ring (2) into the spring duct (fig.
  • Page 14: Adjustment Options On The Orthosis

    Adjustment Options on the Orthosis Adjustment of the Orthosis Alignment via the Extension Stop NEURO VARIO zero and NEURO VARIO If the extension stop is exchangeable, it can be mounted into the system joint depending on the desired extension. Desired Required Extension Stop Work Steps Extension...
  • Page 15: Mounting To The System Side Bar/System Anchor

    9.3.2 Variable Spring Force Insert a spring unit into the spring duct that corresponds with the required spring force. There are five spring units with spring forces ranging from normal to extra strong (fig. 24). Note that the spring unit determines the maximum possible range of motion between 3° and 9°. The NEURO VARIO-SWING is delivered with a premounted green spring unit.
  • Page 16: Converting The System Knee Joints

    11. Converting the System Knee Joints 11.1 Converting Options The following table shows the converting options for the system knee joints. System Knee Joint Convertible into NEURO VARIO 2 NEURO VARIO-SWING NEURO VARIO-SWING NEURO VARIO 2 plug + go modularity The system knee joints with plug + go modularity have identical joint's upper parts and lower parts as well as assembly/lamination dummies and can be easily converted among themselves.
  • Page 17: Maintenance

    12. Maintenance Check the system joint for wear and functionality every 6 months. In particular, check the joint components listed in the following table for the possible problems described and, if necessary, take the appropriate meas- ures. Also check the functionality after every maintenance carried out. It must be possible to move the system joint without problems or unusual noises.
  • Page 18: Documentation Of Maintenance In The Orthosis Service Passport

    12.1 Documentation of Maintenance in the Orthosis Service Passport The patient receives an orthosis service passport from their orthotist or a qualified/trained expert when the orthosis is handed over. The orthosis must be checked every 6 months in order to maintain its function and to ensure the safety of the patient.
  • Page 19: Storage

    15.1 Exploded View Drawing NEURO VARIO zero The exploded view drawing of the NEURO VARIO zero system knee joint also serves as an exemplary illustra- tion for the NEURO CLASSIC zero, NEURO CLASSIC and NEURO VARIO system knee joints. fig. 69...
  • Page 20: Exploded View Drawing Neuro Vario

    15.2 Exploded View Drawing NEURO VARIO 2 fig. 70 15.3 Exploded View Drawing NEURO VARIO-SWING fig. 71...
  • Page 21: Spare Parts For The Neuro Classic Zero System Knee Joint

    The assignment of the items as shown in the exploded view drawing of the NEURO VARIO zero system knee joint serves as guidance. The spare parts of the NEURO CLASSIC zero system knee joint are not identical to the picture.
  • Page 22 Article Number for System Width Item 12mm 14mm 16mm 20mm Description lower part with sliding bushing, SJ0111-L/TI SJ0112-L/TI SJ0113-L/TI SJ0115-L/TI left lateral or right medial, straight, titanium lower part with sliding bushing, SJ0111-R/TI SJ0112-R/TI SJ0113-R/TI SJ0115-R/TI left medial or right lateral, straight, titanium lower part with sliding bushing, SJ0131-L/ST...
  • Page 23: Spare Parts For The Neuro Vario Zero System Knee Joint

    15.5 Spare Parts for the NEURO VARIO zero System Knee Joint Article Number for System Width Item 12mm 14mm 16mm 20mm Description SB8559-L0840 SB9669-L0840 SB1069-L0960 SB1069-L1020 bearing nut upper part, left lateral or right SJ0141-L/ST SJ0142-L/ST SJ0143-L/ST SJ0145-L/ST medial, straight, steel upper part, left medial or right SJ0141-R/ST SJ0142-R/ST...
  • Page 24 Article Number for System Width Item 12mm 14mm 16mm 20mm Description lower part with sliding bushing, SJ0131-L/ST SJ0132-L/ST SJ0133-L/ST SJ0135-L/ST left lateral or right medial, bent inwards, steel lower part with sliding bushing, SJ0131-R/ST SJ0132-R/ST SJ0133-R/ST SJ0135-R/ST left medial or right lateral, bent inwards, steel lower part with sliding bushing, SJ0131-L/TI...
  • Page 25: Spare Parts For The Neuro Classic System Knee Joint

    15.6 Spare Parts for the NEURO CLASSIC System Knee Joint The assignment of the items as shown in the exploded view drawing of the NEURO VARIO zero system knee joint serves as guidance. The spare parts of the NEURO CLASSIC system knee joint are not identical to the picture.
  • Page 26 Article Number for System Width Item 12mm 14mm 16mm 20mm Description lower part with sliding bushing, SL0111-L/TI SL0112-L/TI SL0113-L/TI SL0115-L/TI left lateral or right medial, straight, titanium lower part with sliding bushing, SL0111-R/TI SL0112-R/TI SL0113-R/TI SL0115-R/TI left medial or right lateral, straight, titanium lower part with sliding bushing, SL0131-L/ST...
  • Page 27: Spare Parts For The Neuro Vario System Knee Joint

    15.7 Spare Parts for the NEURO VARIO System Knee Joint The assignment of the items as shown in the exploded view drawing of the NEURO VARIO zero system knee joint serves as guidance. The spare parts of the NEURO VARIO system knee joint are not identical to the picture.
  • Page 28 Article Number for System Width Item 12mm 14mm 16mm 20mm Description lower part with sliding bushing, SL0111-R/TI SL0112-R/TI SL0113-R/TI SL0115-R/TI left medial or right lateral, straight, titanium lower part with sliding bushing, SL0131-L/ST SL0132-L/ST SL0133-L/ST SL0135-L/ST left lateral or right medial, bent inwards, steel lower part with sliding bushing, SL0131-R/ST...
  • Page 29: Spare Parts For The Neuro Vario 2 System Knee Joint

    15.8 Spare Parts for the NEURO VARIO 2 System Knee Joint Article Number for System Width Item 20mm Description SB1069-L1220 bearing nut SL0205-L/TI upper part, left lateral or right medial, straight, titanium SL0205-R/TI upper part, left medial or right lateral, straight, titanium SL0225-L/TI upper part, left lateral or right medial, bent inwards, titanium SL0225-R/TI...
  • Page 30: Spare Parts For The Neuro Vario-Swing System Knee Joint

    15.9 Spare Parts for the NEURO VARIO-SWING System Knee Joint Article Number for System Width Item 20mm Description SB1069-L1220 bearing nut SL0205-L/TI upper part, left lateral or right medial, straight, titanium SL0205-R/TI upper part, left medial or right lateral, straight, titanium SL0225-L/TI upper part, left lateral or right medial, bent inwards, titanium SL0225-R/TI...
  • Page 31: Spare Parts For Spring Units

    Article Number for System Width Item 20mm Description countersunk flat head screw with hexalobular socket (axle SC1406-L14 screw) SL2955-L functional unit plug + go modularity, left lateral or right medial SL2955-R functional unit plug + go modularity, left medial or right lateral 15.10 Spare Parts for Spring Units Article Number for System Width Item 20mm...
  • Page 32: Disposal

    16. Disposal Dispose of the system joint and its individual parts properly. The product must not be disposed of with the residual waste (fig. 34). Please comply with the applicable national laws and local regulations for the proper recycling of recyclable materials. For proper disposal, it is necessary to demount the system joint from the orthosis.
