Pro-face PRO-iO2 Installation Manual page 6

PRO-iO2 module Models
1
The features of each PRO-iO2 module (I/O points, LCD screen, etc.) will vary
depending on the model. Some modules can be connected to the I/O extension
module.
For how to identify your PRO-iO2 module's model number,
PRO-iO2 User Manual
Model
Number
DR2-B121BD
DR2-B201BD
DR2-D101BD
DR2-D201BD
DR2-B121FU
DR2-B201FU
DR2-D101FU
DR2-D201FU
DR3-B101BD
DR3-B261BD
DR3-B101FU
DR3-B261FU
*1 For details about the I/O Extension Module,
PRO-iO2 User Manual, PRO-iO2 I/O Extension Module Installation Guide
*2 The figures in parentheses indicate the maximum number of input/output points when the
I/O Extension Module is connected.
• Even though LCD display-equipped PRO-iO2 modules can be programmed using
only the screen display, the easy-to-use PRO-iO2 Editor software (sold sepa-
rately) is recommended for programming.
• You can test and debug logic programs via the PRO-iO2 Editor's simulation
feature before actually downloading the program to your PRO-iO2 module.
Voltage
24VDC
24VDC
24VDC
24VDC
100VAC to 240VAC
100VAC to 240VAC
100VAC to 240VAC
100VAC to 240VAC
24VDC
24VDC
16/10 (24/16)
100VAC to 240VAC
100VAC to 240VAC
16/10 (24/16)
No.of Input/ LCD Display
Output Points Screen
8/4
12/8
6/4
12/8
8/4
12/8
6/4
12/8
*2
6/4 (14/10)
*2
*2
6/4 (14/10)
*2
-6-
I/O Extension
Module
Yes Not connectable
Yes Not connectable
No Not connectable
No Not connectable
Yes Not connectable
Yes Not connectable
No Not connectable
No Not connectable
Yes Connectable
Yes Connectable
Yes Connectable
Yes Connectable
*1
