Relay Output
Output
Rated Output Voltage
No. of Output Points
Load Current
Common
Mechanical Lifetime
Electrical Lifetime
Min. Open/Close Load
Built-in Fuse
Voltage Endurance
Output Signal Display
Short Circuit Protection
Overvoltage and
Overcurrent Protection
OFF -> ON
Output Delay
ON -> OFF
*1Only the DR3-B261** module's Q8, Q9, and QA share a single common terminal.
Analog Comparator Input
No. of Input Channels
Input Voltage Range
Resolution
Accuracy
Absolute Max Input
Input Filter
Conversion Time
Input Impedance
Insulation Method
Cable Length
*1This accuracy may not be possible in an environment with high noise levels.
Q1 to Q8
5VDC to 30VDC, 24VAC to 250VAC
4 Points (DR*-*1*1**)
8 Points (DR2-*201**)
10 Points (DR3-B261**)
8A/1 Point
Independent Common
10 million operations
100,000 operations at contact rated load
12V, 10mA
4kV (IEC60947-1, IEC60664-1)
via LCD (Models DR*-B***** only)
10ms or less
5ms or less
DR2-D201BD
DR*-B1*1BD
DR*-B2*1BD
0V to 10V
Full-scale value ±5% (at 25ºC)
Full-scale value ±6.2% (at 55ºC)
30VDC (Voltage)
Unit cycle time
No insulation between analog input points,
and between analog input section and power supply
10 m max. (Shielded cable)
