• When connecting the power cord terminals to the GP, be sure the cord
has first been unplugged from the power outlet to prevent the possibil-
ity of an electric shock.
• With the exception of changing the GP's backlight, do NOT open the
GP's case, since high voltage runs through the GP and touching an in-
ternal part can lead to an electric shock.
• Do not use power beyond the GP's specified voltage range. Doing so
may cause a fire or an electric shock.
• Do not modify the GP's design, since it may lead to a fire or an electric
shock.
• Do not use the GP in an environment where flammable gases are present,
since operating the GP may cause an explosion.
• The GP uses a lithium battery for backing up its internal clock data. If
the battery is incorrectly replaced (i.e. its + and — sides are reversed),
the battery may explode. When changing the battery, please contact
your local GP distributor.
• Do not use GP touch panel switches in life-related or important disaster
prevention situations. For safety related switches, such as an emer-
gency switch, be sure to use a separate mechanical switch.
• To prevent operator injury or machine damage, be sure to design your
machine operation system so that the machine will not malfunction due
to a communication fault between the GP and its host controller.
• Do not strike the GP's touch panel with a hard or heavy object, or press
on the touch panel too strongly since it may damage the display.
• Do not install the GP where the temperature will exceed its specified range.
• Be sure that water, liquids or metal particles do not enter the GP, since
it may cause a malfunction or a short circuit.
• Avoid installing the GP where sudden, large changes in temperature
may occur. These changes may cause condensation to form inside the
unit, possibly causing a malfunction.
• To prevent excessive heat from building up inside the GP, do not in-
stall it where its ventilation holes may be blocked.
• Do not install or store the GP :
- Where direcdt sunlight or or high levels of dust exist.
- Where either strong shocks or excessive vibration may occur.
- In an area containing chemicals or chemical fumes.
- Near high temperature equipment.
• Do not use paint thinner or organic solvents to clean the GP's case or
screen.
• Due to the danger of unforeseeable accidents, be sure to back up all data
regularly.
• After turning the GP OFF, be sure to wait a few seconds before turning
it ON again. If the GP is re-started too quickly, it may not start up cor-
rectly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-377 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pro-face GP-377 Series

  • Page 1 • When connecting the power cord terminals to the GP, be sure the cord has first been unplugged from the power outlet to prevent the possibil- ity of an electric shock. • With the exception of changing the GP's backlight, do NOT open the GP's case, since high voltage runs through the GP and touching an in- ternal part can lead to an electric shock.
  • Page 2: Package Contents

    This unit has been carefully packed, with special attention to quality. However, should you find anything damaged or missing, please contact your local GP distributor imme- diately. GP Options (Made by Digital) GP-377 Series Cables User’s Manual Adapters (Sold Separately) Screen editor software, etc.
  • Page 3 GP-377 Parts Names and Functions A: Display Displays User-created screens and host (PLC) data. GP377-SC11-24V : Color LCD GP377-LG11-24V : Monochrome LCD B: Touch Panel Performs screen change operations and sends data to the host (PLC). C: Status LED GP Status Not Lit Power cord is not connected.
  • Page 4: Serial Interface

    Serial Interface This interface is for connecting the GP to the host (PLC), via either an RS-232C or RS-422 cable. Pin # Signal Name Meaning Frame Ground Send Data (RS-232C) Receive Data (RS-232C) Request to Send (RS-232C) Clear to Send (RS-232C) No Connection Signal Ground Carrier Detect (RS-232C)
  • Page 5 • Since pin #14 (VCC) is not protected, be sure to use it only within its rated range. • Be sure to connect pin #7 (SG) to the other unit's Signal Ground terminal. When making a cable, please be aware of the following: <For RS-232C Connectors>...
  • Page 6: Installation

    Installation Confirm the Installation Gasket’s Seating It is strongly recommended that you use the gasket. Place the GP on a level surface with the display panel facing downward. Check that the GP’s installation gasket is seated securely into the gasket’s groove, which runs around the perimeter of the panel’s frame.
  • Page 7 Wiring • To prevent an electric shock, be sure the GP's Power Cord is un- plugged from the power outlet prior to connecting the cord's termi- nals to the GP. • The GP377Series are designed to use only DC24V input. Any other power level can damage both the GP and the power supply.
  • Page 8: Power Supply Precautions

    Power Supply Precautions Be aware of the following items when attaching the power cord terminals to the GP's power terminal block. • When operating the GP where large power fluctuations will occur, install a constant voltage transformer. • To reduce wire-to-wire or wire-to-earth noise as much possible, use a low-noise power supply.
  • Page 9: Changing The Backlight

    When the unit's backlight burns out, the unit's status LED will turn orange. If the "USE TOUCHPANEL AFTER BACKLIGHT BURNSOUT" feature is set to "NO", the GP's touch panel will be disabled. Check you have the proper backlight for the GP-377 Series. Backlight Model GP377-SC11-24V...
  • Page 10 Cord Power Connector 4) Disconnect backlight power connec- tor on the upper side of the GP's front panel. Do not pull the cord. (See fig- ure C) 5) Push the Lock Tab to the right and pull it upward, and then remove the backlight. (See figure C) 6) Insert the new Backlight into the slot from the opposite side of the Lock...

This manual is also suitable for:

Gp377-sc11-24vGp377-lg11-24v
