6A
1
Multi-location wiring
Individually pair each of the wall controls with the fan
receiver using the pairing instruction. See page 27
Wall Controller 1
HOT IN
Maximum of 2 fans can operate on a circuit through the wall transmitter. Maximum of 12 fans can operate
on a circuit through an on/off switch or breaker when utilizing the app for the fan control (without the wall
control in the circuit).
FH-W 1 8 1 1
2
3
4
Wall Controller 2
Green
5
if Applicable
Wall Controller 3
1.
Wall Outlet
2. Wall Control
3. Wall Mounting
4. Mounting
5. Wallplate
Aviator Flush Instructions 17
